MAC地址无效。CONN表示模块是否已从RX3i CPU接收到其配置。ACTIVE表示IED连接的状态。USB表示USB端口上的活动。1、2、3、4表示与四个外部以太网端口对应的链路速度、链路连接和链路活动。16.11.1.2连接器16.11.1.2.1安全数字（SD）卡插槽SD卡插槽设计为支持标准容量（SD）和高容量（SDHC）格式的非易失性存储卡。它是为将来使用而提供的。16.11.1.2.2交换式以太网端口ECM850通过其四个交换式外部以太网端口中的一个或多个连接到IEC 61850网络。它们位于模块的下侧。两个8芯RJ-45屏蔽双绞线10/100/1000 Mbps铜接口和两个小型可插拔（SFP）笼提供了介质选择的灵活性。模块分配了五个以太网MAC地址：四个外部以太网端口各一个，内部交换机各一个。图395:ECM850以太网连接（位于模块下方）PACSystems*RX3i系统手册第16节GFK-2314T 2019年9月专用模块750 16.11.1.2.3 Micro USB端口ECM850具有USB Micro-B插座，用于连接到运行Windows Vista或Windows 7的计算机。USB端口可用于使用终端仿真应用程序（如超级终端）访问ECM850的命令行界面（CLI）功能。命令行接口功能可用于监测ECM850并检查其操作。如果出现问题，可以使用命令行界面帮助确定原因。提供了一个驱动程序安装应用程序，用于配置Windows计算机通过其USB端口与ECM850通信。有关更多详细信息，请参阅PACSystems RX3i IEC 61850以太网通信模块用户手册GFK-2849。16.11.1.3重启按钮ECM850上的重启按钮可用于手动重启模块，无需重启电源。释放按钮后，重启操作开始。PACSystems*RX3i系统手册第16节GFK-2314T 2019年9月专用模块751 16.12以太网接口模块：IC695ETM001图396：IC695ET M001图397：IC69ETM001-Kxxx以太网接口模块IC695ETM901 Jx和IC695ETM1 Kxxx用于将PACSystems RX3i控制器连接到以太网网络。它使RX3i控制器能够与其他PACSystems设备以及90系列和VersaMax控制器通信。以太网接口提供与其他PLC、运行主机通信工具包或编程器软件的主机以及运行TCP/IP版本编程软件的计算机的TCP/IP通信。这些通信通过四层TCP/IP（Internet）堆栈使用SRTP和以太网全球数据（EGD）协议。RX3i以太网接口模块的功能包括：▪ 完整的PLC编程和配置服务▪ 使用以太网全局数据（EGD）进行定期数据交换▪ 用于读写PLC和EGD的EGD命令通过网络交换内存。▪ 使用SRTP的TCP/IP通信服务▪ 综合站点管理和诊断工具▪ 通过IEEE 802.3 CSMA/CD 10Mbps和100Mbps以太网LAN端口连接器扩展PLC连接。▪ 具有自动协商、感知、速度和交叉检测的网络交换机。▪ 直接连接到BaseT（双绞线）网络交换机、集线器或中继器，无需外部收发器。该模块可以安装在任何可用的RX3i I/O插槽中。模块支持插入和取出通电的RX3i通用背板。参见第2.6.4.1节热插拔。模块支持使用WinLoader软件实用程序（如果主机CPU具有串行端口）或使用基于Web的工具（如果主机没有串行端口）进行固件升级。固件升级工具包中包含说明。有关此模块的更多信息，请参阅以下出版物：▪ PACSystems RX3i和RSTi EP TCP/IP以太网通信用户手册，GFK-2224▪ PACSystems TCP/IP以太网
the MAC addresses are invalid. CONN Indicates whether the module has received its configuration from the RX3i CPU. ACTIVE Indicates the status of IED connections. USB Indicates activity on the USB port. 1, 2, 3, 4 Indicates link speed, link connection and link activity corresponding to each of the four external Ethernet ports. 16.11.1.2 Connectors 16.11.1.2.1 Secure Digital (SD) Card Slot The SD card slot is designed to support non-volatile memory cards in both standard capacity (SD) and highcapacity (SDHC) formats. It is provided for future use. 16.11.1.2.2 Switched Ethernet Ports The ECM850 connects to an IEC 61850 network by means of one or more of its four switched external Ethernet ports. These are located on the underside of the module. Two 8-conductor RJ-45 shielded twisted pair 10/100/1000 Mbps copper interfaces and two Small Form-factor Pluggable (SFP) cages provide flexibility in media selection. The module is assigned five Ethernet MAC addresses: one for each of the four external Ethernet ports and one for the internal switch. Figure 395: ECM850 Ethernet Connections (Located Underneath Module) PACSystems* RX3i System Manual Section 16 GFK-2314T Sept. 2019 Special Purpose Modules 750 16.11.1.2.3 Micro USB Port The ECM850 has a USB Micro-B socket for connection to a computer running Windows Vista or Windows 7. The USB port can be used to access the Command Line Interface (CLI) function for the ECM850, using a terminal emulation application such as HyperTerminal. The Command Line Interface function can be used to monitor an ECM850 and check its operation. If a problem occurs, the Command Line Interface can be used to help determine the cause. A driver installation application is provided to configure a Windows computer to communicate with the ECM850 through its USB port. Refer to PACSystems RX3i IEC 61850 Ethernet Communication Module User Manual, GFK-2849 for more details. 16.11.1.3 Restart Pushbutton The Restart pushbutton on an ECM850 can be used to manually restart the module without cycling power. The restart operation begins when the pushbutton is released. PACSystems* RX3i System Manual Section 16 GFK-2314T Sept. 2019 Special Purpose Modules 751 16.12 Ethernet Interface Module: IC695ETM001 Figure 396: IC695ETM001 Figure 397: IC695ETM001- Kxxx The Ethernet Interface Module, IC695ETM001-Jx and IC695ETM001-Kxxx, is used to connect a PACSystems RX3i controller to an Ethernet network. It enables the RX3i controller to communicate with other PACSystems equipment and with Series 90 and VersaMax controllers. The Ethernet interface provides TCP/IP communications with other PLCs, host computers running the Host Communications Toolkit or programmer software, and computers running the TCP/IP version of the programming software. These communications use the SRTP and Ethernet Global Data (EGD) protocols over a four-layer TCP/IP (Internet) stack. Features of the RX3i Ethernet Interface Module include: ▪ Full PLC programming and configuration services ▪ Periodic data exchange using Ethernet Global Data (EGD) ▪ EGD Commands to read and write PLC and EGD exchange memory over the network. ▪ TCP/IP communication services using SRTP ▪ Comprehensive station management and diagnostic tools ▪ Extended PLC connectivity via IEEE 802.3 CSMA/CD 10Mbps and 100Mbps Ethernet LAN port connectors. ▪ Network switch that has Auto-negotiate, Sense, Speed, and crossover detection. ▪ Direct connection to BaseT (twisted pair) network switch, hub, or repeater without an external transceiver. This module can be installed in any available RX3i I/O slot. Module supports insertion into and removal from an RX3i Universal Backplane which is under power. Refer to Hot Insertion and Removal, Section 2.6.4.1. Module supports firmware upgrades using the WinLoader software utility (if the host CPU has a serial port) or using a Web-based tool (if the host CPU has no serial port). Instructions are included with the firmware upgrade kit. For more information about this module, please refer to the following publications: ▪ PACSystems RX3i and RSTi-EP TCP/IP Ethernet Communications User Manual, GFK-2224 ▪ PACSystems TCP/IP Ethernet
