IS200BAIAH1B输出卡件,DCS模块卡件
如果密码正确且安装了设置点访问跳线，则显示以下消息：现在可以输入设置点。按下退出PASSCODE（密码）组并编程相应的设定点。如果5分钟内没有按键，将不再允许编程访问，并且必须重新输入密码。移除设置点访问跳线或在setpoint access（设置点访问）消息中选择“Restricted”（受限）也将立即禁用设置点访问。如果需要新的密码，则通过如上所述输入有效密码来获得设置点访问权限。然后按下以显示CHANGE PASSCODE（更改密码）信息并遵循指示。如果输入了无效的密码，则可以通过按键查看加密的密码。如果当前编程的密码未知，请使用此号码咨询工厂服务部门。使用解密程序，可以确定密码。❙ 密码❙ [ENTER]更多信息，请输入密码：范围：1到8个数字。仅当密码不为0且设置点访问受限时，才会显示此消息。设置点访问：允许范围：允许，受限只有当密码为0或允许访问设置点时，才会显示此消息。更改密码：否范围：否，是。仅当密码为0或允许访问设置点时，才会显示此消息。更改密码？无需输入新密码访问：再次输入新密码：输入密码访问：设置点访问：允许的输入密码退出信息退出信息退出消息退出信息帮助GE Power Management 469电机管理继电器4-5 4设置点编程4.2 S1 469设置4 4.2.2首选项某些特性可以针对不同情况进行修改。通常，此子组不需要更改。•默认消息循环时间：如果选择了多个默认消息，则显示会自动循环显示这些消息。可以更改显示时间以适应不同的用户偏好。•默认消息超时：如果在一段时间内没有按下任何键，则继电器将自动扫描一组编程的默认消息。可以修改此时间，以确保在编程或读取实际值期间消息在屏幕上保留足够长的时间。默认扫描开始后，按任意键将返回屏幕上查看的最后一条消息。•平均电机负载计算周期：该设置点调整计算平均电机负载的时间周期。该计算是一个滑动窗口，在电机启动期间被忽略。•温度显示：温度测量值可以以摄氏度或华氏度显示。每个温度值显示为°C或°F。RTD设定值始终以摄氏度显示。•跟踪存储器触发器位置：设置波形捕获的触发器位置。该值表示触发（跳闸）之前捕获并记录在跟踪内存缓冲区中的周期百分比。
If the passcode is correct and the setpoint access jumper is installed, the following message appears: Setpoints can now be entered. Press to exit the PASSCODE group and program the appropriate setpoints. If no keys are pressed for 5 minutes, programming access will no longer be allowed and the passcode must be re-entered. Removing the setpoint access jumper or selecting "Restricted" at the SETPOINT ACCESS message will also disable setpoint access immediately. If a new passcode is required, gain setpoint access by entering the valid passcode as described above. Then press to display the CHANGE PASSCODE message and follow directions. If an invalid passcode is entered, an encrypted passcode may be viewed by pressing the key. Consult the factory service department with this number if the currently programmed passcode is unknown. Using a deciphering program, the passcode can be determined. ❙ PASSCODE ❙ [ENTER] for more ENTER PASSCODE FOR ACCESS: Range: 1 to 8 numeric digits. This message is seen only if the passcode is not 0 and setpoint access is restricted. SETPOINT ACCESS: Permitted Range: Permitted, Restricted This message is seen only if the passcode is 0 or setpoint access is permitted. CHANGE PASSWORD: No Range: No, Yes. This message is seen only if the passcode is 0 or setpoint access is permitted. CHANGE PASSCODE? No ENTER NEW PASSCODE FOR ACCESS: ENTER NEW PASSCODE AGAIN: ENTER PASSCODE FOR ACCESS: SETPOINT ACCESS: Permitted ENTER ESCAPE ð ð MESSAGE ESCAPE MESSAGE ESCAPE ENTER MESSAGE ESCAPE MESSAGE HELP GE Power Management 469 Motor Management Relay 4-5 4 SETPOINT PROGRAMMING 4.2 S1 469 SETUP 4 4.2.2 PREFERENCES Some characteristics can be modified for different situations. Normally this subgroup will not require changes. • DEFAULT MESSAGE CYCLE TIME: If multiple default messages are chosen, the display automatically cycles through those messages. The display time can be changed to accommodate different user preferences. • DEFAULT MESSAGE TIMEOUT: If no keys are pressed for a period of time then the relay will automatically scan a programmed set of default messages. This time can be modified to ensure messages remain on the screen long enough during programming or reading actual values. Once default scanning starts, pressing any key will return the last message viewed to the screen. • AVERAGE MOTOR LOAD CALCULATION PERIOD: This setpoint adjusts the period of time over which the average motor load is calculated. The calculation is a sliding window and is ignored during motor starting. • TEMPERATURE DISPLAY: Temperature measurements may be displayed in either Celsius or Fahrenheit. Each temperature value is displayed as °C or °F. RTD setpoints are always displayed in degrees Celsius. • TRACE MEMORY TRIGGER POSITION: Sets the trigger position for waveform capture. This value represents the percentage of cycles captured and recorded in the trace memory buffer prior to the trigger (trip).
