5.按4、6和9键，然后按。显示以下闪烁信息：显示屏返回至6。按退出子组。多次按下将始终将光标返回到页面顶部。❙❙ 设定点❙❙ S1 469设置❙ 密码❙ [ENTER]了解更多信息，请输入访问密码：新的设定点已存储设定点访问：允许的设定点消息消息输入消息消息值输入输入退出进入退出退出GE Power Management 469电机管理继电器4-1 4设定点编程4.1概述4设定点程序4.1概述4.1.1跳闸/报警/阻塞定义469电机控制继电器具有三种基本类型的保护元件。它们是TRIPS、ALARMS和BLOCKS。a） 除R1跳闸继电器外，469跳闸功能可分配给两个辅助继电器R2和R3的任何组合。如果跳闸激活，469面板上的相应LED（指示灯）将点亮，以显示哪个输出继电器已运行。除跳闸继电器外，跳闸将始终操作块启动继电器。跳闸功能可编程为锁定或解锁。一旦继电器通过闭锁跳闸操作，当条件不再存在时，必须执行复位以清除跳闸。如果有锁定时间，闭锁启动继电器将不会复位，直到锁定时间结束。如果未锁定跳闸功能激活，一旦导致跳闸的条件停止，该跳闸将自动复位（以及相关输出继电器）。在发出跳闸之前，469立即对电机参数进行快照，并将其存储为跳闸前值，以便在跳闸发生后进行故障排除。最后一次跳闸的原因信息将更新为当前跳闸，469显示默认为该信息。所有跳闸功能都会自动记录，并在发生时标记日期和时间。此外，所有行程都作为统计数据进行统计和记录，以便确定任何长期趋势。b） 报警469报警功能可用于操作R4报警、R3辅助和R2辅助三个输出继电器的任意组合。当报警激活时，当输出继电器工作时，469面板上的相应LED（指示灯）将点亮。每个报警功能可编程为锁定或解锁。锁定报警功能激活后，必须按下重置键以重置该报警。如果导致报警的条件仍然存在（例如热RTD），则报警继电器将不会重置，直到该条件不再存在。另一方面，如果未锁定报警功能激活，则一旦导致报警的条件停止，该报警将自动复位（以及相关的输出继电器）。一旦发生警报，警报消息就会更新以反映警报，469显示默认为该消息。由于可能不希望将所有报警记录为事件，因此可以将每个报警功能编程为记录为事件或不记录为事件。如果报警被编程为记录为事件，当其激活时，它将自动记录为日期和时间戳事件。c） 阻止启动469阻止启动是一种功能，可根据某些情况阻止或禁止电机启动
5. Press the 4, 6, and 9 keys, then press . The following flash message is displayed: and the display returns to 6. Press to exit the subgroup. Pressing numerous times will always returns the cursor to the top of the page. ❙❙ SETPOINTS ❙❙ S1 469 SETUP ❙ PASSCODE ❙ [ENTER] for more ENTER PASSCODE FOR ACCESS: NEW SETPOINT HASE BEEN STORED SETPOINT ACCESS: PERMITTED SETPOINT MESSAGE MESSAGE MESSAGE ENTER MESSAGE MESSAGE VALUE VALUE ENTER ENTER ESCAPE ENTER ESCAPE ESCAPE GE Power Management 469 Motor Management Relay 4-1 4 SETPOINT PROGRAMMING 4.1 OVERVIEW 4 4 SETPOINT PROGRAMMING 4.1 OVERVIEW 4.1.1 TRIPS/ALARMS/BLOCKS DEFINED The 469 Motor Management Relay has three basic categories of protection elements. They are TRIPS, ALARMS, and BLOCKS. a) TRIPS An 469 trip feature may be assigned to any combination of the two Auxiliary relays, R2 and R3, in addition to the R1 Trip Relay. If a Trip becomes active, the appropriate LED (indicator) on the 469 faceplate will illuminate to show which of the output relays has operated. In addition to the Trip relay(s), a trip will always operate the Block Start relay. Trip features are may be programmed as latched or unlatched. Once a relay has been operated by a latched trip, a reset must be performed to clear the trip when the condition is no longer present. If there is a lockout time, the Block Start relay will not reset until the lockout time has expired. If an unlatched trip feature becomes active, that trip will reset itself (and associated output relays) as soon as the condition that caused the trip ceases. Immediately prior to issuing a trip, the 469 takes a snapshot of motor parameters and stores them as pre-trip values which will allow for troubleshooting after the trip occurs. The cause of last trip message is updated with the current trip and the 469 display defaults to that message. All trip features are automatically logged and date and time stamped as they occur. In addition, all trips are counted and logged as statistics such that any long term trends may be identified. b) ALARMS An 469 alarm feature may be assigned to operate any combination of three output relays, R4 Alarm, R3 Auxiliary, and R2 Auxiliary. When an Alarm becomes active, the appropriate LED (indicator) on the 469 faceplate will illuminate when an output relay(s) has operated. Each alarm feature may be programmed as latched or unlatched. Once a latched alarm feature becomes active, the reset key must be pressed to reset that alarm. If the condition that has caused the alarm is still present (e.g. hot RTD) the Alarm relay(s) will not reset until the condition is no longer present. If on the other hand, an unlatched alarm feature becomes active, that alarm will reset itself (and associated output relay(s)) as soon as the condition that caused the alarm ceases. As soon as an alarm occurs, the alarms messages are updated to reflect the alarm and the 469 display defaults to that message. Since it may not be desirable to log all alarms as events, each alarm feature may be programmed to log as an event or not. If an alarm is programmed to log as an event, when it becomes active, it is automatically logged as a date and time stamped event. c) BLOCK START An 469 Block Start is a feature that prevents or inhibits the start of the motor based on some
