IS200EMIOH1A/IS200EMIOH1ACA机器人模块卡件
保证GE Fanuc控制器和I/O解决方案229 VersPoint配件IC220ACC001模块标签窄，数量10 IC220ACC002模块标签宽，数量10个IC220ACC003点标签编号1-100，数量10 IC 220ACC004点标签空白，数量1000 IC220ACC005模块键控标签，数量100 IC220ACC100电机起动器制动模块DC IC220ACC101电机起动器制动组件AC/DC IC220ACC 103电机起动器电源连接器IC220ACC104电机起动器电源桥IC220ACC105电机电路连接器数量10 IC220ACC201继电器模块隔离套件（需要1个IC220TBK206）IC220DEM001 VersPoint演示案例、DEVICENET NIU IC220DEM002 VersPoint演示案例、，PROFIBUS NIU IC220DEM011 VersPoint静态演示，DEVICENET NIU IC220 DEM012 VersPPoint静态演示，PROFIBUS NIU IC 220TBK061 I/O带屏蔽，6位弹簧型，数量5个IC220TBK062 I/O端子条带双屏蔽，6位置弹簧型，5个IC220 TBK082 I/O端子条，8位置弹簧型，数量10 IC220TBK084输入/输出端子条，8位弹簧式，交流输出，数量10 IC220 TBK085输入/输出接线条，8位置弹簧式，继电器，数量10 IC 220TBK087电源端子条，八位弹簧式，弹簧式，DEVICENET NIU IC220TBK202端子排组，弹簧式，编码器IC220TBK203端子排组。。。保证VersaPoint配置指南配置VersaPoint时，应考虑以下指南：1。每个网络接口单元的VersPoint限制为63个模块。2.每个模块需要一个接线板。3.每个电压都需要一个电源端子来分离电压。4.段端子可用于轻松地对电压段内的点进行分组。5.连接器的内部功率/电流额定值为2安培。如果超过此额定值，则需要电源端子。用于本地控制的控制器典型应用配置的电缆选择示例（需要（120）24 VDC输入和（80）继电器输出AC电源的示例应用）。系统还具有五个远程机柜，每个机柜需要（8）24 VDC输入，（4）24 VDC 0.5 Amp，电源输出，（2）电流输入和（2）Profibus DP上的电流输出（24 VDC电源）。控制柜背板插槽所需电源数量零件号描述所需电流（mA）2 1250mA@3.3 VDC；1000mA@5 VDC 1 IC695CPU310 CPU，带两个内置串行端口2 1 IC695PSA040 120/240 VAC，125 VDC电源，电流9安培@3.3 VDC；6安培@5 VDC；1.6安培@24 VDC 600mA@3.3 VDC；240 mA@5 VDC 1 IC695CHS016 16槽通用底座4 1200mA@5V 4 IC694MDL660离散输入模块，24 VDC正逻辑，32点（需要接线板）5 35mA@5V；110mA@24 VDC继电器5 IC694MDL940离散输出模块，继电器2.0A每点形式A，16点（包括接线板）。4个IC694TBB032接线盒，盒型1 420 mA@5 VDC 1 IC695PBM300 Genius总线控制器（GBC），支持Genius总线上最多32个设备，以控制远程I/O、全局数据和数据报1 BC646MPP001逻辑开发人员-PLC标准-带编程电缆14所需电源总电流：2895mA@5V；1850@3.3V；110mA@24 VDC继电器。
Guaranteed GE Fanuc Controller and I/O Solutions 229 VersaPoint Accessories IC220ACC001 Module Labels Narrow, Qty 10 IC220ACC002 Module Labels Wide, Qty 10 IC220ACC003 Point Labels Numbered 1-100, Qty 10 IC220ACC004 Point Labels Blank, Qty 1000 IC220ACC005 Module Keying Tabs, Qty 100 IC220ACC100 Motor Starter Brake Module DC IC220ACC101 Motor Starter Brake Module AC/DC IC220ACC103 Motor Starter Power Connector IC220ACC104 Motor Starter Power Bridge IC220ACC105 Motor Circuit Connector, Qty 10 IC220ACC201 Relay Module Isolation Set (Requires 1 IC220TBK206) IC220DEM001 VersaPoint Demo Case, DEVICENET NIU IC220DEM002 VersaPoint Demo Case, PROFIBUS NIU IC220DEM011 VersaPoint Static Demo, DEVICENET NIU IC220DEM012 VersaPoint Static Demo, PROFIBUS NIU IC220TBK061 I/O W/Shield, 6 Position Spring Style, Qty 5 IC220TBK062 I/O Terminal Strip W/Dual Shield, 6 Position Spring Style, Qty 5 IC220TBK082 I/O Terminal Strip, 8 Position Spring Style, Qty 10 IC220TBK083 I/O Terminal Strip, 8 Position Spring Style, AC Input, Qty 10 IC220TBK084 I/O Terminal Strip, 8 Position Spring Style, AC Output, Qty 10 IC220TBK085 I/O Terminal Strip, 8 Position Spring Style, Relay, Qty 10 IC220TBK087 Power Terminal Strip, 8 Position Spring Style, Qty 10 IC220TBK122 I/O Terminal Strip, 12 Position Spring Style, Input, Qty 10 IC220TBK123 I/O Terminal Strip, 12 Position Spring Style, Output, Qty 10 IC220TBK201 Terminal Strip Set, Spring Style, DEVICENET NIU IC220TBK202 Terminal Strip Set, Spring Style, Encoder IC220TBK203 Terminal Strip Set, Spring Style, Analog Out/HSC IC220TBK204 Terminal Strip Set, Spring Style, AC Power Terminal IC220TBK206 Terminal Strip Set, Spring Style, Relay Isolation Artisan Techlogy Group - Quality Instrumentation ... Guaranteed VersaPoint Configuration Guidelines When configuring a VersaPoint the following guidelines should be considered: 1. VersaPoint is limited to 63 modules per Network Interface Unit. 2. Each module requires a terminal strip. 3. Each voltage requires a Power Terminal to separate voltages. 4. Segment Terminals can be used to easily group points within a voltage segment. 5. Internal power/current rating of connectors is 2 amps. A power terminal is required if this rating is exceeded. Cable Selection Examples of Typical Application Configuration for Controller (Example application requiring (120) 24 VDC inputs and (80) Relay outputs AC power supply) for local control. System also has five remote cabinets, with each cabinet requiring (8) 24 VDC Inputs, (4) 24 VDC 0.5 Amp, Source Outputs and (2) current inputs and (2) current outputs (24 VDC power source) over Profibus DP. Control Cabinet Backplane Slots Required Power Supply Qty Part Number Description Current Required (mA) 2 1250mA@ 3.3 VDC; 1000mA@ 5 VDC 1 IC695CPU310 CPU with two built-in serial ports 2 1 IC695PSA040 120/240 VAC, 125 VDC Power Supply, current available 9 Amps @ 3.3 VDC; 6 Amps @ 5 VDC; 1.6 Amps @ 24 VDC 600mA@ 3.3 VDC; 240 mA@ 5 VDC 1 IC695CHS016 16 Slot Universal Base 4 1200mA @ 5V 4 IC694MDL660 Discrete Input Module, 24 VDC Positive Logic, 32 points (Requires terminal block) 5 35mA @ 5V; 110mA @ 24 VDC Relay 5 IC694MDL940 Discrete Output Module, Relay 2.0 A per point Form A, 16 points (Terminal block included). 4 IC694TBB032 Terminal Block, Box Style 1 420 mA @ 5 VDC 1 IC695PBM300 Genius Bus Controller (GBC), supports up to 32 devices on a Genius Bus to control remote I/O, Global Data and Datagrams 1 BC646MPP001 Logic Developer - PLC Standard - w/Programming Cable 14 Total current from power supply required: 2895mA @ 5V; 1850 @ 3.3V; 110mA @ 24 VDC Relay .
