IS200GGXDG1ABB工控模块卡件
表56 HART接口模块型号接口模块描述2770H型HART模拟输入接口模块3700A、3721 TMR 2870H HART模拟输出接口模块3805E、3805H TMR表57 Tricon底盘用于HART通信如果您的原始系统版本是…升级到…在底盘中安装HART接口模块。。。Tricon v10.4.x或更高版本（高密度）n/a•8121型增强型低密度扩展机箱Tricon v10.0.x–10.3.x（高密度版）Tricon v10.4 x•8121型号增强型低浓度扩展机箱Trion v9.x（高密度型）Tricon v40.4 x•81 21型增强低密度扩展底盘Tricon v6.x–v10.x（低密度版）Tricon v10.4.x•8100-x型主底盘•8101型低密度扩展机箱•8102型低密度RXM机箱•8121型增强型低密度扩展底盘HART接口模块143 Tricon v9–v10系统HART模拟输入接口模块规划和安装指南这是2770H型HART模拟输入模块从现场设备到HART控制器的简化示意图。图60 2770H简化示意图4-20 mA HART现场设备24V HART控制器RS-485 HART控制器250 7模拟输入3700A或3721 2770H HART AI接口模块终端A至D转换器2071H HART MUX模块144第2章Tricon v9–v10系统的系统组件规划和安装指南此图显示2770H型HART模拟输入接口的前面板单元图61 2770H前面板AI 1-16 HART MUX FAULT PWR主机HART 4850 OUT IN A B A B HART RS-485 AI 17-32 2770H HART AI TRICONEX 2071H终端用连接器Tricon 2071H HART MUX模块HART RS-485终端用连接器HART接口模块145 Tricon v9–v10系统规划和安装指南2770H规范本节包括型号规范2770H，它是一个模拟输入接口模块，为连接至3700A和3721模拟输入模块的现场设备提供HART通信。HART模拟输出接口模块这是2870H型HART模拟输出模块从AO模块到现场设备的简化示意图。图62 2870H简化示意图58 2770H HART模拟输入接口模块规格特性规格兼容模拟输入模块3700A，3721输入信号数量32输入类型4-20 mA，0至5 VDC HART MUX模块1 1。有关Triconex 4850 HART多路复用器的更多信息，包括PC软件安装和配置，请参阅Triconex 485 0 HART多路转换器说明手册INM4850-TR。2071H（包括Triconex 4850 HART多路复用器）状态指示器：HART MUX模块1 PWR、故障、主机、HART HART协议HART现场通信协议、，版本5.0–7.0逻辑功率<5瓦RS-485 HART控制器HART控制器终端HART现场设备4-20 mA D/A转换器2071H HART MUX模块模拟输出3805E或3805H 2870H HART AO接口模块146第2章Tricon v9–v10系统的系统组件规划和安装指南此图显示了2870H型HART模拟输出接口的前面板单元图63 2870H前面板AO HART MUX故障PWR主机HART 4850 TRICONEX 2071H OUT IN A B A B HART RS-485 2870H终端用HART AO连接器Tricon 2071H HART MUX模块HART RS-485连接器HART接口模块147 Tricon v9–v10系统规划和安装指南2870H规范本节包括型号2870H的规范，它是一个模拟输出接口模块，为连接到3805E或3805H模拟输出模块的现场设备提供HART通信。表59 2870H HART模拟输出接口模块规格特性规格兼容模拟输出模块3805E、3805H输出信号数量8输出类型4-20 mA、0至5 VDC HART MUX模块1 1。有关Triconex 4850 HART多路复用器的更多信息，包括PC软件安装和配置，请参阅Triconex 485 0 HART多路转换器说明手册INM4850-TR。2071H（包括Triconex 4850 HART多路复用器）状态指示器：HART MUX模块1 PWR、故障、主机、HART HART协议HART现场通信协议，版本5.0–7.0逻辑功率<5瓦148第2章Tricon v9–v10系统组件规划和安装指南
Table 56 HART Interface Modules Model Interface Module Description Compatible I/O Modules Type 2770H HART Analog Input Interface Module 3700A, 3721 TMR 2870H HART Analog Output Interface Module 3805E, 3805H TMR Table 57 Tricon Chassis Usage for HART Communication If Your Original System Version Is... Upgrade to... Install HART Interface Modules in Chassis... Tricon v10.4.x or later (High-Density) n/a • Model 8121 Enhanced Low-Density Expansion Chassis Tricon v10.0.x – 10.3.x (High-Density) Tricon v10.4.x • Model 8121 Enhanced Low-Density Expansion Chassis Tricon v9.x (High-Density) Tricon v10.4.x • Model 8121 Enhanced Low-Density Expansion Chassis Tricon v6.x – v10.x (Low-Density) Tricon v10.4.x • Model 8100-x Main Chassis • Model 8101 Low-Density Expansion Chassis • Model 8102 Low-Density RXM Chassis • Model 8121 Enhanced Low-Density Expansion Chassis HART Interface Modules 143 Planning and Installation Guide for Tricon v9–v10 Systems HART Analog Input Interface Modules This is a simplified schematic of the Model 2770H HART Analog Input Interface Module from the field device to the HART controller. Figure 60 2770H Simplified Schematic 4-20 mA HART FIELD DEVICE 24V HART Controller RS-485 HART Controller 250 7 ANALOG INPUT 3700A or 3721 2770H HART AI INTERFACE MODULE TERMINATION A to D Converter 2071H HART MUX Module 144 Chapter 2 System Components Planning and Installation Guide for Tricon v9–v10 Systems This figure shows the front panel of the Model 2770H HART Analog Input Interface Module. Figure 61 2770H Front Panel AI 1-16 HART MUX FAULT PWR HOST HART 4850 OUT IN A B A B HART RS-485 AI 17-32 2770H HART AI TRICONEX 2071H Connector for Terminations Tricon 2071H HART MUX Module HART RS-485 Connector Connector for Terminations HART Interface Modules 145 Planning and Installation Guide for Tricon v9–v10 Systems 2770H Specifications This section includes specifications for model 2770H, which is an Analog Input Interface Module that provides HART communication to field devices connected to 3700A and 3721 Analog Input Modules. HART Analog Output Interface Modules This is a simplified schematic of the Model 2870H HART Analog Output Interface Module from the AO module to the field device. Figure 62 2870H Simplified Schematic Table 58 2770H HART Analog Input Interface Module Specifications Feature Specification Compatible Analog Input Modules 3700A, 3721 Number of input signals 32 Input type 4-20 mA, 0 to 5 VDC HART MUX Module1 1. For more information about the Triconex 4850 HART Multiplexer, including PC software installation and configuration, see the Triconex 4850 HART Multiplexer Instruction Manual, INM4850-TR. 2071H (includes the Triconex 4850 HART Multiplexer) Status indicator: HART MUX module1 PWR, FAULT, HOST, HART HART protocol HART Field Communication Protocol, Revision 5.0–7.0 Logic power < 5 Watts RS-485 HART CONTROLLER HART Controller TERMINATION HART FIELD DEVICE 4-20 mA D to A Converter 2071H HART MUX Module ANALOG OUTPUT 3805E or 3805H 2870H HART AO INTERFACE MODULE 146 Chapter 2 System Components Planning and Installation Guide for Tricon v9–v10 Systems This figure shows the front panel of the Model 2870H HART Analog Output Interface Module. Figure 63 2870H Front Panel AO HART MUX FAULT PWR HOST HART 4850 TRICONEX 2071H OUT IN A B A B HART RS-485 2870H HART AO Connector for Terminations Tricon 2071H HART MUX Module HART RS-485 Connector HART Interface Modules 147 Planning and Installation Guide for Tricon v9–v10 Systems 2870H Specifications This section includes specifications for model 2870H, which is an Analog Output Interface Module that provides HART communication to field devices connected to 3805E or 3805H Analog Output Modules. Table 59 2870H HART Analog Output Interface Module Specifications Feature Specification Compatible Analog Output Modules 3805E, 3805H Number of output signals 8 Output type 4-20 mA, 0 to 5 VDC HART MUX Module1 1. For more information about the Triconex 4850 HART Multiplexer, including PC software installation and configuration, see the Triconex 4850 HART Multiplexer Instruction Manual, INM4850-TR. 2071H (includes the Triconex 4850 HART Multiplexer) Status indicator: HART MUX module1 PWR, FAULT, HOST, HART HART protocol HART Field Communication Protocol, Revision 5.0–7.0 Logic power < 5 Watts 148 Chapter 2 System Components Planning and Installation Guide for Tricon v9–v10
