IS200HFPAG2ADC IS200HFPAG2模拟量输入模块
电压传感器+V A C B A或B电压/电流传感器电压传感器电压传感器电流传感器总线Xcvr总线Xcv总线Xcvr双端口RAMµProc双端口RAM？Proc点寄存器点寄存器数字输出模块103 Tricon v9–v10系统的规划和安装指南此图显示了3611E型的前面板。图43 3611E前面板115 VAC 115 VAV数字输出3611E深绿色条纹通过故障激活1 PWR LOAD 2 PWR LOAD3 PWR LOAD4 PWR LOAD5 PWR LOAD6 PWR LOAD7 PWR LOAD8 PWR LOAD104第2章Tricon v9–v10系统的系统组件规划和安装指南3611E规范本表列出了3611E型的规范，它是一个标称电压为115VDC的TMR数字输出模块。切换功率切换无功负载时，应将输出的切换功率降到最大值的25%，即500 VAC应用。此限制不适用于感应负载，因为所有受监控的数字输出都受到保护，防止感应反冲（反EMF）。当切换白炽灯时，涌入电流可以是灯的额定额定负载电流的10至15倍。在计算所需的输出开关功率时，必须使用涌入电流。有关涌入幅度和持续时间的详细规范，请联系灯具制造商。表38 3611E数字输出规格特性规格颜色代码深绿色输出信号数量8，公共输入频率范围47-63 Hz电压范围90–155 VAC载流额定值，最大2安培/点，10安培浪涌/1个交流周期开关电源，最大值参见第104页上的开关电源2000 VA（电阻）最大输出循环率<20次/秒最大额定负载下的预期寿命>10000次最小所需负载1 50 mA负载漏电电流（关闭状态）4 mA最大机箱漏电电流@60 Hz 1 mA最大保险丝（现场终端模块上）每个输出1个（2.5安培快速动作）状态指示器：打开或关闭状态点点状态指示器：每个点的电源警报电源状态指示器：每点的负载警报负载状态指示器：模块状态通过、故障、，有源点隔离1500 VDC最小逻辑功率<15瓦关闭状态下的短路负载检测不适用数字输出模块105 Tricon v9–v10系统的规划和安装指南输出诊断故障范围2：最大输出切换率最小输出切换率每100毫秒加一次扫描不适用诊断故障持续时间不适用打开状态电压降：对于外部终端，10英尺电缆<2 VAC典型@100m<6 VAC最大@2A开启状态电压降：对于外部终端而言，99英尺电缆<3 VAC典型@100 m<12 VAC最大@2 A感应反冲保护（反EMF）Tranzorb位于终端面板1上。只有遵守所有安装指南和限制条件，才能确保该模块正常运行。有关更多信息，请参阅IPS全球客户支持（GCS）中心提供的应用程序注释8“受监控的数字输出模块”。2.最大输出切换率可实现I/O诊断的正确操作和所有正常可检测故障的检测。最小切换率提供了模块计算平均故障间隔时间（MTBF）10%内正常不可检测故障的故障覆盖率。表38 3611E数字输出规格（续）功能规格106第2章Tricon v9–v10系统28-120 VDC监控数字输出模块的系统组件规划和安装指南本图为8点TMR监控数字输出模件的简化示意图。图44 3613E、3614E、3615E和3617E简化示意图总线Xcvr双端口RAM点寄存器总线XcvrDualPortedRAM点寄存器母线Xcvr DualPorted RAM点寄存器输出开关驱动电路A A或B输出开关驱动线路输出开关驱动电路B输出开关驱动器电路3613E型号规格，其为标称范围为120VDC的TMR监控数字输出模块。切换功率切换无功负载时，应将输出的切换功率降到最大值的25%，即直流应用的37.5瓦。当切换白炽灯时，涌入电流可以是灯的额定额定负载电流的10至15倍。有关涌入幅度和持续时间的详细规范，请联系灯具制造商。在计算所需的输出开关功率时，必须使用涌入电流。表39 3613E监控数字输出规格特性规格颜色代码钢蓝色输出信号数量8，公共电压范围90至155 VDC载流额定值，最大0.5安培/点，4安培浪涌/10毫秒开关功率，最大值参见第108页开关功率150瓦（电阻）最大输出循环率<20次/秒预期寿命a
Voltage Sensor +V A C B A or B Voltage/ Current Sensor Voltage Sensor Voltage/ Current Sensor Bus Xcvr Bus Xcvr Bus Xcvr DualPorted RAM µProc DualPorted RAM µProc DualPorted RAM µProc Point Register Point Register Point Register Digital Output Modules 103 Planning and Installation Guide for Tricon v9–v10 Systems This figure shows the front panel of model 3611E. Figure 43 3611E Front Panel 115 VAC 115 VAV DIGITAL OUTPUT 3611E Deep Green Stripe PASS FAULT ACTIVE 1 PWR LOAD 2 PWR LOAD 3 PWR LOAD 4 PWR LOAD 5 PWR LOAD 6 PWR LOAD 7 PWR LOAD 8 PWR LOAD 104 Chapter 2 System Components Planning and Installation Guide for Tricon v9–v10 Systems 3611E Specifications This table lists the specifications for model 3611E, which is a TMR Digital Output Module with a nominal voltage of 115 VDC. Switching Power When switching reactive loads, you should de-rate the switching power of the outputs to 25 percent of maximum, which is 500 VAC applications. This restriction does not apply to inductive loads because all supervised digital outputs are protected against inductive kick-back (reverse EMF). When switching incandescent lamps, the inrush current can be 10 to 15 times the rated nominal load current of the lamp. The inrush current must be used when calculating the required output switching power. For detailed specifications regarding inrush amplitude and duration, contact the lamp manufacturer. Table 38 3611E Digital Output Specifications Feature Specification Color code Deep green Number of output signals 8, commoned Input frequency range 47-63 Hz Voltage range 90–155 VAC Carry current ratings, maximum 2 amps/point, 10 amps surge/ 1 AC cycle Switching power, maximum See Switching Power on page 104 2000 VA (resistive) Maximum output cycle rate < 20 cycles per second Expected life at maximum rated load > 10,000 cycles Minimum required load1 50 mA Leakage current to load (Off state) 4 mA maximum Leakage current to chassis @ 60 Hz 1 mA maximum Fuses (on field termination module) 1 per output (2.5 amps fast-acting) Status indicator: On or Off state per point Point Status indicator: Power alarm per point Power Status indicator: Load alarm per point Load Status indicator: Module status Pass, Fault, Active Point isolation 1500 VDC minimum Logic power < 15 watts Shorted load detection in Off state Not applicable Digital Output Modules 105 Planning and Installation Guide for Tricon v9–v10 Systems Output diagnostic fault coverage2: Maximum output toggle rate Minimum output toggle rate Every 100 ms plus one scan Not applicable Diagnostic glitch duration Not applicable On-state voltage drop: With external termination, 10-foot cable < 2 VAC typical @ 100m < 6 VAC maximum @ 2A On-state voltage drop: With external termination, 99-foot cable < 3 VAC typical @ 100m < 12 VAC maximum @ 2A Inductive kick-back protection (reverse EMF) Tranzorb on termination panel 1. Proper operation of this module can be assured only if all installation guidelines and restrictions are observed. For more information, see Application Note 8, Supervised Digital Output Modules available from the IPS Global Client Support (GCS) center. 2. The maximum output toggle rate enables proper operation of I/O diagnostics and detection of all normally detectable faults. The minimum toggle rate provides fault coverage of normally undetectable faults within 10% of the calculated mean-time-between-faults (MTBF) for the module. Table 38 3611E Digital Output Specifications (continued) Feature Specification 106 Chapter 2 System Components Planning and Installation Guide for Tricon v9–v10 Systems 28—120 VDC Supervised Digital Output Modules This figure is a simplified schematic for 8-point TMR Supervised Digital Output Modules. Figure 44 3613E, 3614E, 3615E, and 3617E Simplified Schematic Bus Xcvr DualPorted RAM Point Register Bus Xcvr DualPorted RAM Point Register Bus Xcvr DualPorted RAM Point Register Output Switch Drive Circuitry A A or B Output Switch Drive Circuitry Output Switch Drive Circuitry B Output Switch Drive Circuitry specifications for model 3613E, which is a TMR Supervised Digital Output Module with a nominal range of 120 VDC. Switching Power When switching reactive loads, you should de-rate the switching power of the outputs to 25 percent of maximum, which is 37.5 watts for DC applications. When switching incandescent lamps, the inrush current can be 10 to 15 times the rated nominal load current of the lamp. For detailed specifications regarding inrush amplitude and duration, contact the lamp manufacturer. The inrush current must be used when calculating the required output switching power. Table 39 3613E Supervised Digital Output Specifications Feature Specification Color code Steel blue Number of output signals 8, commoned Voltage range 90 to 155 VDC Carry current ratings, maximum 0.5 amps/point, 4 amps surge/10 ms Switching power, maximum See Switching Power on page 108 150 watts (resistive) Maximum output cycle rate < 20 cycles per second Expected life at maximum rated load > 10,000 cycles Minimum required load1 50 mA Leakage current to load (Off state without secondary power supply) 4 mA maximum Primary fuse on field termination module (2 per output) 1.0 amp, fast-acting Secondary fuse on field termination module (2 per output) 0.125 amp, fast-acting Status indicator: On or Off state per point Point Status indicator: Power alarm per point Power
