IS200HFPAG2ADC/IS200HFPAG1ADC通用电气
2： 最大输出切换率最小输出切换率每100毫秒不适用诊断故障持续时间3最大2毫秒，500μsec典型导通状态电压降：在背板上，典型值<1.0 VDC@250mA<1.0 VDC最大值@1A导通状态压降：带外部终端，10英尺电缆<2.0 VDC典型@250 mA<2.5 VDC最大@1A数字输出模块101 Tricon v9–v10系统3624规格规划和安装指南本表列出了3624型号的规格，该型号为TMR监控数字输出模块，标称电压为24 VDC。接通状态电压降：带外部终端，99英尺电缆<2.5 VDC，典型@250 mA<6.0 VDC，最大@1A感应反冲保护（反EMF）I/O模块1上的反向二极管。必须向所有点供电，包括非公用面板上未使用的点。2.最大输出切换率可实现I/O诊断的正确操作和所有正常可检测故障的检测。最小切换率提供了模块计算平均故障间隔时间（MTBF）10%内正常不可检测故障的故障覆盖率。3.无法禁用OVD故障。表37 3624监控数字输出规格功能规格颜色代码绿松石绿输出信号数量16，常见推荐电压范围16–30 VDC最大电压36 VDC逻辑功率<10瓦额定电流，最大0.7安培/点，4.8安培浪涌/10 ms最小所需负载30 mA负载漏电流4 mA，最大保险丝（现场终端）不需要；输出开关对过压、过温和过电流进行自我保护状态指示器：每点开或关状态1状态指示器：模块状态通过、故障、活动状态指示器：现场报警1电源，负载（每点1个）点隔离1500 VDC最小短路检测阈值处于关闭状态<5Ω输出诊断故障覆盖率2：最大输出切换率最小输出切换率每100毫秒加一次扫描不需要诊断故障持续时间3最大2毫秒，500μs典型表36 3623和3623T监控数字输出规格（续）功能规格102第2章Tricon v9–v10系统115 VAC监控数字输出模块的系统组件规划和安装指南本图为3611E型的简化示意图，该型号为标称电压范围为115 VAC的TMR数字输出模块。图42 3611E简化的导通状态压降示意图：在背板<1.0 VDC典型@500mA<1.0 VDC@1A导通状态下的压降：带外部终端，10英尺电缆<2.0 VDC典型@500 mA<2.5 VDC@1A的导通电压降：带外部端接，99英尺电缆<2.5 VDC典型@500mA<6.0 VDC@1A感应反冲保护（反EMF）I/O模块1上的反向二极管。必须向所有点供电，包括非公用面板上未使用的点。2.最大输出切换率可实现I/O诊断的正确操作和所有正常可检测故障的检测。最小切换率提供了模块计算平均故障间隔时间（MTBF）10%内正常不可检测故障的故障覆盖率。3.无法禁用OVD故障。表37 3624监控数字输出规格（续）功能规格输出开关驱动电路A A或B输出开关驱动回路输出开关驱动线路B输出开关控制回路C A B C三重I/O总线智能I/O控制器（S）现场电路8点–LD RTN***所有输出开关均电隔离。
2: Maximum output toggle rate Minimum output toggle rate Every 100 ms Not applicable Diagnostic glitch duration3 2 ms maximum, 500 μsec typical On-state voltage drop: At backplane < 1.0 VDC typical @ 250mA < 1.0 VDC maximum @ 1A On-state voltage drop: With external termination, 10-foot cable < 2.0 VDC typical @ 250mA < 2.5 VDC maximum @ 1A Digital Output Modules 101 Planning and Installation Guide for Tricon v9–v10 Systems 3624 Specifications This table lists the specifications for model 3624, which is a TMR Supervised Digital Output Module with a nominal voltage of 24 VDC. On-state voltage drop: With external termination, 99-foot cable < 2.5 VDC typical @ 250mA < 6.0 VDC maximum @ 1A Inductive kick-back protection (reverse EMF) Reverse diode on I/O module 1. Power must be supplied to all points, including unused points on non-commoned panels. 2. The maximum output toggle rate enables proper operation of I/O diagnostics and detection of all normally detectable faults. The minimum toggle rate provides fault coverage of normally undetectable faults within 10% of the calculated mean-time-between-faults (MTBF) for the module. 3. OVD glitching cannot be disabled. Table 37 3624 Supervised Digital Output Specifications Feature Specification Color code Turquoise green Number of output signals 16, commoned Recommended voltage range 16–30 VDC Maximum voltage 36 VDC Logic power < 10 watts Current ratings, maximum 0.7 amps/point, 4.8 amps surge/10 ms Minimum required load 30 mA Leakage current to load 4 mA, maximum Fuses (field termination) Not required; output switches are self-protected against over-voltage, over-temperature, and overcurrent Status indicator: On or Off state 1 per point Status indicator: Module status Pass, Fault, Active Status indicator: Field alarm1 Power, Load (1 per point) Point isolation 1500 VDC minimum Short-circuit detection threshold in Off state < 5 Ω Output diagnostic fault coverage2: Maximum output toggle rate Minimum output toggle rate Every 100 ms plus one scan Not required Diagnostic glitch duration3 2 ms maximum, 500 μs typical Table 36 3623 and 3623T Supervised Digital Output Specifications (continued) Feature Specification 102 Chapter 2 System Components Planning and Installation Guide for Tricon v9–v10 Systems 115 VAC Supervised Digital Output Modules This figure is a simplified schematic for model 3611E, which is a TMR Digital Output Module with a nominal voltage range of 115 VAC. Figure 42 3611E Simplified Schematic On-state voltage drop: At backplane < 1.0 VDC typical @ 500mA < 1.0 VDC @ 1A On-state voltage drop: With external termination, 10-foot cable < 2.0 VDC typical @ 500mA < 2.5 VDC @ 1A On-state voltage drop: With external termination, 99-foot cable < 2.5 VDC typical @ 500mA < 6.0 VDC @ 1A Inductive kick-back protection (reverse EMF) Reverse diode on I/O module 1. Power must be supplied to all points, including unused points on non-commoned panels. 2. The maximum output toggle rate enables proper operation of I/O diagnostics and detection of all normally detectable faults. The minimum toggle rate provides fault coverage of normally undetectable faults within 10% of the calculated mean-time-between-faults (MTBF) for the module. 3. OVD glitching cannot be disabled. Table 37 3624 Supervised Digital Output Specifications (continued) Feature Specification Output Switch Drive Circuitry A A or B Output Switch Drive Circuitry Output Switch Drive Circuitry B Output Switch Drive Circuitry C A B C TRIPLICATED I/O BUS INTELLIGENT I/O CONTROLLER(S) FIELD CIRCUITRY 8 POINTS – LD RTN * * * * * All output switches are galvanically isolated.
