在本文中，仅支持VMIVME-7700目标板。开发PC和目标所需的所有软件、文档和脚本都存储在ftp站点上。与本文档一起提供ftp站点的目的是：1。以为所有必要的软件2创建单个位置。以提供设置一致开发环境3的指令。提供安装和使用开发PC和目标硬件的说明所有软件和软件文档都存储在Akamina Technologies ftp服务器上。NRC工作人员只能进入该现场。ftp站点可以访问ftp://www.akamina.com.用户ID和密码已在单独的电子邮件中提供。我们发现使用命令行ftp比尝试使用Mozilla更有效。ftp站点的目录结构如下所示：development |--host |--docs |--fedora |--scripts |--tools |--x86_tools |--target |--VMIVME-7700 |--demo以下各节中的说明提供了有关开发PC设置和目标设置的详细信息。然后提供了构建定制Linux内核和根文件系统以及将应用程序软件添加到目标负载的详细说明。最后一节提供了如何将主机调试会话连接到目标上执行的软件的说明。NRC_Dev_Env_Setup_Guide_v1.0状态：已发布3 2。开发PC设置开发PC的设置包括以下步骤：1。下载并安装Fedora Core 2主机发行版2。下载和安装Java，3。下载和安装Eclipse以及C/C++插件和4。Eclipse是基于Java的框架，在该框架上构建集成开发环境；Eclipse需要Java。2.1第一步–Fedora Core 2安装Fedora Core 2映像可以在Akamina Technologies ftp站点的目录下找到：/development/host/fedeora/fedeora2/ISO。这些图像应下载到任何PC上并刻录到CD上。一旦创建了所有CD，选择了您的开发主机并将其配置为在CD上查找引导扇区，您就可以开始安装过程了。通过将CD 1插入主机CD驱动器并重新启动电脑开始安装。请注意，下面定义的安装配置只需要Fedora Core 2 CD 1、2和3。加载内核后，将提示您选择终端模式进行安装。此时，只需按Enter键选择图形模式。将出现一个屏幕，询问您是否要执行媒体测试–选择“跳过”以跳过媒体测试。然后将提示您以下屏幕：屏幕操作欢迎使用Fedora Core单击下一步按钮语言选择单击下一个
of this writing, only the VMIVME-7700 target board is supported. All of the software, documentation and scripts required for the development PC and for the target have been stored on an ftp site. The objectives of providing this ftp site together with this document are: 1. to create a single location for all of the necessary software 2. to provide the instructions to setup a consistent development environment 3. to provide the instructions to setup and use both the development PC and the target hardware All of the software and software documentation has been stored on the Akamina Technologies ftp server. Access to this site is restricted to NRC staff. The ftp site can be accessed at ftp://www.akamina.com. The userid and password have been provided in a separate email. We have found that using the command-line ftp is more effective than attempting to use Mozilla. The directory structure of the ftp site is shown below: develop |-- host |-- docs |-- fedora |-- scripts |-- tools |-- x86_tools |-- target |-- VMIVME-7700 |-- demo The instructions in the sections that follow provide detailed information on the setup of the development PC and the setup of the target. Detailed instructions are then provided for building a custom Linux kernel and root filesystem as well as for adding application software to the target load. A final section provides instructions on how to connect a host debug session to software executing on the target. NRC_Dev_Env_Setup_Guide_v1.0 Status: Released 3 2. Development PC Setup The setup of the development PC includes the following steps: 1. download and installation of the Fedora Core 2 host distribution, 2. download and installation of Java, 3. download and installation of Eclipse along with C/C++ plugin and 4. completion of the setup Eclipse is the Java-based framework on which the integrated development environment is built; Java is required for the Eclipse. 2.1. Step One – Fedora Core 2 Installation The Fedora Core 2 images can be found on the Akamina Technologies ftp site under the directory: /develop/host/fedora/fedora2/ISO. These images should be downloaded to any PC and burned onto CDs. Once all of the CDs have been created, your development host has been selected and it is configured to look for a boot sector on the CD, you are ready to begin the installation process. Start the installation by inserting CD 1 into the host CD drive and restarting the PC. Note that the installation configuration defined below only requires Fedora Core 2 CDs 1, 2 and 3. Once the kernel is loaded you will be prompted to choose the terminal mode for installation. At this point just press Enter to select the graphical mode. A screen will appear asking if you would like to perform a media test – select Skip to skip the media test. You will then be prompted with the following screens: Screen Action Welcome to Fedora Core Click on the Next button Language Selection Click on the Next
