IS200GDDDG1ABA自动化模块备件,工控备件机器人模块
KIndustry Pack：软件。Windows 64位和32位。与工业包装和VME运营商一起使用时，适用于型号XVME6500和XVME6700 SBC的软件包。只读光盘存储器IPSW-VME-WIN行业包：软件。用于工业包的64位和32位Windows驱动程序软件包。VME运营商的DLL和演示程序。与TSI148芯片组（包括XVME-6300和XVME-6400）配合使用。只读光盘存储器美国制造ISO9001 AS9100 844-878-2352solutions@acromag.comwww.acromag.com 30765 Wixom Rd，Wixom，MI 48393 USA Industry Pack Carriers Bulletin#8401046b说明AVME9670A和AVME9675A是非智能从板，最多可连接四个IP模块至VMEbus。唯一的区别是AVME9675A增加了完全实现的地理寻址。这两种都是全高（6U）IP承载卡，使用VME64兼容连接器，以增加后部I/O连接的数量，超过标准VME。当与VME64背板一起使用时，AVME967xA将所有200个I/O点引出后部P0和P2连接器。这种方便消除了杂乱的电缆挂在笼子的前部。除了更干净的机架设计外，将板插入和更换到系统中也更容易。Acromag的载体板提供对IP模块I/O、ID和内存空间的完整数据访问。通过完全访问可编程寄存器，您可以从VMEbus轻松配置和控制IP模块的操作。每个IP模块最多支持两个中断请求。VMEbus中断级别是软件可编程的。每个IP模块电源线上的单独无源滤波器在IP模块和承载板之间提供最佳的滤波和隔离。主要功能和优点四个行业标准IP模块插槽（AVME967xA-2E型号上有两个IP插槽）n 200个I/O点，带后部访问n VME64x高密度后部连接器n全地理寻址（仅限AVME9675A）n每个IP模块有两个中断n每个IP都有单独的过滤和熔断电源n前面板状态LED可容纳四个IP模块◆ VME64高密度后部连接器◆ 地理地址或用户定义地址AVME967xA VME64 6U，非智能，IP载体卡请访问www.acromag.com/industrypack了解美国制造的工业包模块ISO9001 AS9100 844-878-2352solutions@acromag.comwww.acromag.com 30765 Wixom Rd，Wixom，MI 48393 USA所有商标均为其各自所有者的财产。版权所有©Acromag，Inc.2022。数据如有更改，恕不另行通知。2022年4月在美国印刷。工业封装运营商AVME967xA VME64 6U，非智能，IP运营商卡性能规范IP符合性（ANSI/VITA 4）符合ANSI/VITA 4-1995和ANSI/VITA 4.1-1996中I/O映射的IP规范。电气/机械接口：支持单或双尺寸IP模块。不支持32位IP模块。支持I/O空间和ID空间。内存空间：每个IP模块支持1MB到8MB。中断：支持每个IP模块两个中断请求和中断确认周期，D16/D08（O）。VMEbus合规会议
KIndustry Pack: Software. Windows 64-bit and 32-bit. Software package for models XVME6500 and XVME6700 SBCs when used with Industry Packs and VME carriers. CD-ROM. IPSW-VME-WIN Industry Pack: Software. 64-bit and 32-bit Windows driver software package for Industry Packs. DLLs and demonstration programs for VME carriers. Works with TSI148 chipset including the XVME-6300 and XVME-6400. CD-ROM. MADE IN USA ISO9001 AS9100 844-878-2352 solutions@acromag.com www.acromag.com 30765 Wixom Rd, Wixom, MI 48393 USA Industry Pack Carriers Bulletin #8401046b Description The AVME9670A and AVME9675A are nonintelligent slave boards that interface up to four IP modules to the VMEbus. The only difference is that the AVME9675A adds fully implemented geographical addressing. Both are full-height (6U) IP carrier cards that use VME64-compliant connectors to increase the quantity of rear I/O connections beyond that of standard VME. When used with a VME64 backplane, the AVME967xA brings all 200 I/O points out the rear P0 and P2 connectors. This convenience eliminates messy cables from hanging out the front of the cage. In addition to a cleaner cage design, it is also much easier to insert and replace boards into the system. Acromag’s carrier boards provide full data access to the IP module’s I/O, ID and memory spaces. With full access to the programmable registers, you can easily configure and control the operation of the IP modules from the VMEbus. Up to two interrupt requests are supported for each IP module. The VMEbus interrupt level is software programmable. Individual passive filters on each IP module power supply line provide optimum filtering and isolation between the IP modules and the carrier board. Key Features & Benefits Four industry-standard IP module slots (two IP slots on AVME967xA-2E models) n 200 I/O points with rear access n VME64x high-density rear connectors n Full geographical addressing (AVME9675A only) n Two interrupts per IP module n Individually filtered and fused power to each IP n Front panel status LEDs Holds four IP modules ◆ VME64 high-density rear connectors ◆ Geographical or user-defined addressing AVME967xA VME64 6U, Non-intelligent, IP Carrier Cards See www.acromag.com/industrypack for Industry Pack modules MADE IN USA ISO9001 AS9100 844-878-2352 solutions@acromag.com www.acromag.com 30765 Wixom Rd, Wixom, MI 48393 USA All trademarks are property of their respective owners. Copyright © Acromag, Inc. 2022. Data subject to change without notice. Printed in USA 4/2022. Industry Pack Carriers AVME967xA VME64 6U, Non-intelligent, IP Carrier Cards Performance Specifications IP Compliance (ANSI/VITA 4) Meets IP specifications per ANSI/VITA 4-1995 and ANSI/VITA 4.1-1996 for I/O mapping. Electrical/mechanical interface: Supports single or double size IP modules. 32-bit IP modules are not supported. I/O space and ID space supported. Memory space: Supports 1MB to 8MB per IP module. Interrupts: Supports two interrupt requests per IP module and interrupt acknowledge cycles, D16/D08(O). VMEbus Compliance Meets
