IS200GGXIG1 IS200GGXIG1AFE工业自动化卡件
5025-552：终端面板，50针连接器，50个螺钉端子TRANS-GP：转换模块Acromag，股份有限公司•Wixom，MI 48393•电话：248-295-0310•solutions@acromag.com•www.acromag.com Industry Pack Carriers混合和匹配具有不同I/O功能的插件模块，以快速创建具有数百个通道的自定义I/O板。Industry Pack Carriers Industry Pack Carriers 8400408c美国印刷4/22版权所有©2022 Acromag，Inc.数据如有更改，恕不另行通知。所有商标均为其各自所有者的财产。844-878-2352 solutions@acromag.comwww.acromag.com 30765 Wixom Rd，Wixom，MI 48393 USA Industry Pack Carriers Bulletin#8400942e说明AVME9660A是一个非智能从板，将Industry Pack（IP）模块连接到VMEbus。全高（6U）板可容纳四个IP模块。所有现场I/O连接均连接至承载板。Acromag的载体板提供对IP模块I/O、ID和内存空间的完整数据访问。通过完全访问可编程寄存器，您可以从VMEbus轻松配置和控制IP模块的操作。每个IP模块最多支持两个中断请求。VMEbus中断级别是软件可编程的。每个IP模块电源线上的单独无源滤波器在IP模块和载体板之间提供最佳滤波和电源隔离。关键功能和优点全IP模块数据访问可方便地配置和控制IP模块。n前面板LED通过成功IP访问的可视指示简化调试。n前面板连接器提供带状电缆接入现场I/O，而不会干扰相邻插槽中的板。容纳四个IP模块◆ 每个IP模块支持1MB-8MB内存◆ 前面板连接器AVME9660A VMEbus 6U，非智能，IP载波卡终端面板和电缆工业包装模块-12+5标准杆数+12 STOP#SERR#PERR#LOCK#AD（0:31）DEVSEL#IRDYi#IDSEL INTA#RST#P1 VME总线+3.3 IP内存空间寄存器-12 IP D CONTROL+5 IP B CONTROL+5 IP A CONTROL+5-12 IP模块D+5 IP模块C+5-12 IP模块B+5 IP组件A+5 IP-D现场I/O IP-B现场I/O P2未使用TRDY#机架J1：短地址选择载波控制寄存器中断控制和状态寄存器IP模块错误状态电源故障低电压监视器（+5V）载波状态寄存器FPGA+12-12-12+12+12+12+12-12+12+12+12+12ip-C字段I/O IP-A字段I/O C/BE（0:3）#电源滤波器电源滤波器电源滤波IP数据（0:15）&IP地址（1:6）844-878-2352solutions@acromag.comwww.acromag.com 30765 Wixom Rd，Wixom，MI 48393 USA所有商标均为其各自所有者的财产。版权所有©Acromag，Inc.2022。数据如有更改，恕不另行通知。2022年4月在美国印刷。工业封装载体AVME9660A VMEbus 6U，非智能，IP载体卡性能规范IP符合性（ANSI/VITA 4）符合ANSI/VITA 4-1995的IP规范。电气/机械接口：支持单或双尺寸IP模块。不支持32位IP模块。支持I/O空间和ID空间。内存空间：每个IP模块支持1MB到8MB。中断：每个IP模块支持两个中断请求和中断确认周期，D16/D08（O）。VMEbus合规性符合1985年10月第C.1版、IEC 821-1987和IEEE 1014-1987的VME规范。数据传输总线：A24/A16:D16/D08（EO）DTB从站；支持读取-修改-写入周期。中断：创建I（1-7）个可编程请求级别（最多两个来自每个IP模块的请求）。
5025-552: Termination panel,50-pin connector, 50 screw terminals TRANS-GP: Transition module Acromag, Inc. • Wixom, MI 48393 • Phone: 248-295-0310 • solutions@acromag.com • www.acromag.com Industry Pack Carriers Mix and match plug-in modules with different I/O functions to quickly create custom I/O boards with hundreds of channels. Industry Pack Carriers Industry Pack Carriers 8400408c Printed in USA 4/22 Copyright © 2022 Acromag, Inc. Data subject to change without notice All trademarks are the property of their respective owners. 844-878-2352 solutions@acromag.com www.acromag.com 30765 Wixom Rd, Wixom, MI 48393 USA Industry Pack Carriers Bulletin #8400942e Description The AVME9660A is a non-intelligent slave board that interfaces Industry Pack (IP) modules to the VMEbus. The full-height (6U) board holds four IP modules. All field I/O connections are made to the carrier board. Acromag’s carrier boards provide full data access to the IP module’s I/O, ID and memory spaces. With full access to the programmable registers, you can easily configure and control the operation of the IP modules from the VMEbus. Up to two interrupt requests are supported for each IP module. The VMEbus interrupt level is software programmable. Individual passive filters on each IP module power supply line provide optimum filtering and power isolation between the IP modules and the carrier board. Key Features & Benefits Full IP module data access enables convenient software configuration and control of the IP modules. n Front panel LEDs simplify debugging with a visual indication of successful IP accesses. n Front panel connectors provide ribbon cable access to field I/O without interference from boards in adjacent slots. Holds four IP modules ◆ Supports 1MB-8MB memory per IP module ◆ Front panel connectors AVME9660A VMEbus 6U, Non-intelligent, IP Carrier Cards Termination panel & cable Industry Pack modules -12 +5 PAR +12 STOP# SERR# PERR# LOCK# AD(0:31) DEVSEL# IRDYi# IDSEL INTA# RST# P1 VME BUS +3.3 IP MEMORY SPACE REGISTERS -12 IP D CONTROL +5 IP C CONTROL +5 IP B CONTROL +5 IP A CONTROL +5 -12 IP MODULE D +5 IP MODULE C +5 -12 IP MODULE B +5 IP MODULE A +5 IP-D FIELD I/O IP-B FIELD I/O P2 NOT USED TRDY# FRAME# J1: SHORT ADDRESS SELECTION CARRIER CONTROL REGISTERS INTERRUPT CONTROL AND STATUS REGISTERS IPMODULE ERROR STATUS POWER FAILURE LOW VOLTAGE MONITOR (+5V) CARRIER STATUS REGISTER FPGA +12 -12 -12 +12 +12 -12 +12 +12 -12 +12 +12 -12 +12 IP-C FIELD I/O IP-A FIELD I/O C/BE(0:3)# POWER SUPPLY FILTERS POWER SUPPLY FILTERS POWER SUPPLY FILTERS POWER SUPPLY FILTERS IP DATA(0:15) & IP ADDRESS(1:6) 844-878-2352 solutions@acromag.com www.acromag.com 30765 Wixom Rd, Wixom, MI 48393 USA All trademarks are property of their respective owners. Copyright © Acromag, Inc. 2022. Data subject to change without notice. Printed in USA 4/2022. Industry Pack Carriers AVME9660A VMEbus 6U, Non-intelligent, IP Carrier Cards Performance Specifications IP Compliance (ANSI/VITA 4) Meets IP specifications per ANSI/VITA 4-1995. Electrical/mechanical interface: Supports single or double size IP modules. 32-bit IP modules are not supported. I/O space and ID space supported. Memory space: Supports 1MB to 8MB per IP module. Interrupts: Supports two interrupt requests per IP module & interrupt acknowledge cycles, D16/D08(O). VMEbus Compliance Meets VME specifications per revision C.1 dated October 1985, IEC 821-1987 and IEEE 1014-1987. Data transfer bus: A24/A16:D16/D08(EO) DTB slave; supports Read-Modify-Write cycles. Interrupts: Creates I(1-7) programmable request levels (up to two requests sourced from each IP module).
