2021。数据如有更改，恕不另行通知。2021 4月在美国印刷。XBRD-9060 XVME-9640 AVME9630 VMEbus 3U，非智能IP载体卡AVME963是一个非智能从板，将IP模块连接到VMEbus。半高（3U）板容纳两个IP模块。所有现场I/O连接均连接至承载板。功能3U型号可容纳两个模块工业标准IP模块接口用于现场I/O信号的前面板连接器每个IP支持两个中断通道提供单独隔离和过滤的+5V、+12V、，和-12V直流电源线连接到每个IP模块接受其他制造商的IP模块锁定前面板连接器优点完全IP模块数据访问可方便地配置和控制IP模块。前面板LED通过成功IP访问的可视指示简化了调试。前面板连接器提供带状电缆接入现场I/O，而不会干扰相邻插槽中的板。操作Acromag的载体板提供对IP模块I/O、ID和内存空间的完整数据访问。通过完全访问可编程寄存器，您可以从VMEbus轻松配置和控制IP模块的操作。每个IP模块最多支持两个中断请求。VMEbus中断级别是软件可编程的。每个IP模块电源线上的单独无源滤波器在IP模块和载体板之间提供最佳滤波和电源隔离。规范IP符合性（ANSI/VITA 4）符合ANSI/VITA 4-1995的IP规范。电气/机械接口：支持单或双尺寸IP模块。不支持32位IP模块。支持I/O空间和ID空间。内存空间：每个IP模块支持1MB到8MB。中断：支持每个IP模块两个中断请求和中断确认周期，D16/D08（O）。VMEbus合规性符合1985年10月第C.1版、IEC 821-1987和IEEE 1014-1987的VME规范。数据传输总线：A24/A16:D16/D08（EO）DTB从站；支持读取-修改-写入周期。中断：创建I（1-7）个可编程请求级别（最多两个来自每个IP模块的请求）。D16/D08（O）中断器（中断向量来自IP模块）。载波寄存器用于控制和状态监控。中断释放机制为寄存器访问释放（RORA）类型。环境工作温度：0至70℃（AVME9630/60）或-40至85℃（AVME 9630E/60E型号）。储存温度：-25至85°C（AVME9630/60）或-40至85°F（AVME-9630E/60E型号）。相对湿度：5至95%，无冷凝。功率：+5V（±5%）：最大275mA。±12V（±5%）：0mA（未使用）。加上IP模块负载。不适用于新设计MTBF：25°C时453851小时，MIL-HDBK-217F，通知2。订购信息产业包装载体AVME9630：不适用于新设计的3U载体。容纳两个IP模块。AVME9630E：不适用于与AVME9630相同的新设计以及扩展的温度范围。不适用于新设计软件（有关详细信息，请参阅软件文档）软件库适用于Linux、VxWorks和Windows。请联系工厂了解更多信息。附件（详见附件文件）5025-550：电缆，非屏蔽，两端50针插头
.2021. Data subject to change without notice. Printed in USA 4/2021. XBRD-9060 XVME-9640 AVME9630 VMEbus 3U, Non-intelligent, IP Carrier Cards The AVME9630 is a non-intelligent slave board that interfaces IP modules to the VMEbus. The half-height (3U) board holds two IP modules. All field I/O connections are made to the carrier board. Features 3U model holds two modules Industry-standard IP module interface Front panel connectors for field I/O signals Supports two interrupt channels per IP Provides individually isolated and filtered +5V, +12V,and -12V DC power lines to each IP module Accepts other manufacturers’IP modules Locking front panel connectors Benefits Full IP module data access enables convenient software configuration and control of the IP modules. Front panel LEDs simplify debugging with a visual indication of successful IP accesses. Front panel connectors provide ribbon cable access to field I/O without interference from boards in adjacent slots. Operation Acromag’s carrier boards provide full data access to the IP module’s I/O, ID and memory spaces. With full access to the programmable registers, you can easily configure and control the operation of the IP modules from the VMEbus. Up to two interrupt requests are supported for each IP module. The VMEbus interrupt level is software programmable. Individual passive filters on each IP module power supply line provide optimum filtering and power isolation between the IP modules and the carrier board. Specifications IP Compliance (ANSI/VITA 4) Meets IP specifications per ANSI/VITA 4-1995. Electrical/mechanical interface: Supports single or double size IP modules. 32-bit IP modules are not supported. I/O space and ID space supported. Memory space: Supports 1MB to 8MB per IP module. Interrupts: Supports two interrupt requests per IP module and interrupt acknowledge cycles, D16/D08(O). VMEbus Compliance Meets VME specifications per revision C.1 dated October 1985, IEC 821-1987 and IEEE 1014-1987. Data transfer bus: A24/A16:D16/D08(EO) DTB slave; supports Read-Modify-Write cycles. Interrupts: Creates I(1-7) programmable request levels (up to two requests sourced from each IP module). D16/D08(O) interrupter (interrupt vectors come from IP modules). Carrier registers are for control and status monitoring. Interrupt release mechanism is Release on Register Access (RORA) type. Environmental Operating temperature: 0 to 70°C (AVME9630/60) or -40 to 85°C (AVME9630E/60E models). Storage temperature: -25 to 85°C (AVME9630/60) or -40 to 85°C (AVME9630E/60E models). Relative humidity: 5 to 95% non-condensing. Power: +5V (±5%): 275mA maximum. ±12V (±5%): 0mA (not used). Plus IP module load. not available for new designs MTBF: 453,851 hrs. at 25°C,MIL-HDBK-217F,notice 2. Ordering Information Industry Pack Carriers AVME9630: not available for new designs 3U carrier. Holds two IP modules. AVME9630E: not available for new designs Same as AVME9630 plus extended temperature range. not available for new designs Software (see software documentationfor details) Software libraries are available for Linux, VxWorks, and Windows. Please contact the Factory for more information. Accessories (see accessories documentationfor details) 5025-550: Cable, unshielded,50-pin header both ends
