IS200GGXIG1AFE脉冲输入卡件
（XMC模块P16连接器I/O可选P0连接器，请咨询工厂）。XMC是PCIe x8。用XBRD-9060替换PMC/XMC#2的选项。系统完整性两位LED显示屏可用于开机自检（POST）代码，以检查引导操作期间的问题。然后，它可以用于应用软件用户代码，以帮助软件调试。外形尺寸6U VMEbus 9.2“（233mm）x 6.3”（160mm）。可选扩展XBRD-9060允许为前面板添加更多I/O，以及为存储添加mSATA SSD模块。可用的前面板I/O有Gb以太网、RS-232串行端口和两个USB端口。XBRD-9060还包含两个mSATA插槽，允许添加两个SSD驱动器，同时仍保留在单个VME插槽中。使用QM87 PCH的软件RAID功能，如果需要冗余或额外速度，这些驱动器甚至可以设置为RAID 0/1阵列。XVME-9640安装在XVME-6700后面的后插槽上，以便轻松访问P2上的所有可用I/O，以及可选的P0连接器，并允许添加mSATA SSD模块用于存储。前面板I/O有两个Gb以太网端口、一个VGA端口、一一个DVI-D端口和两个USB端口。内部连接器也可用。有关详细信息，请参阅用户手册。环境工作温度标准温度型号：0至70°C*。扩展温度型号：-40至75°C*.*取决于应用程序-有关详细信息，请参阅手册。储存温度-55至85°C。60°C时相对湿度5%至95%，无冷凝。背板电源输入：双核赛扬。5V（仅5V背板）：53W（典型值）至53W（最大值），37.5W（典型）。5V（5V+3.3V背板）：50W典型值至50.5W最大值，35W典型值。3.3V（可选）：3W+/-12V：仅用于PMC/XMC。订购信息转到在线订购页面>XVME-6720-7080-LF 6U VME SBC，P0 XVME-6700-7082-LF 6U VM E SBC，PO，无电池XVME-6740-7080E-LF 6U VMware SBC，P0，延长工作温度XVME-6780-7082E-LF 6U VME SBC，P0.，外部工作温度，无电池，XVME-0720-7081-LF 6U VMM SBC，延长工作温度XVME-6720-7083E-LF 6U VME SBC无P0，外部工作温度，无电池注：请联系工厂了解传导冷却型号。附件有关更多信息，请访问www.acromag.com。XBRD-9060-LF扩展I/O载体模块XVME-9640-1-LF 6U VMEbus后部转换模块，带P0连接器XVME-96-2-LF 6U VM Ebus后部过渡模块，不带P0接头电缆组5028-568电缆适配器：RJ点5公头到RJ45母头，6 in 5028-572电缆适配器：26针到2 USB，VGA，串行，18软件开发工具板支持包包括驱动程序和集成方向。XVME-6500/6700-BSP-LNX Linux板支持包XVME-6500/6700-BSP-VXW VxWorks板支持包XVME-6500/7700-BSP-WIN Windows板支持包IPSW-A7VME-LNX Linux示例库。IPSW-A7VME-VXW VxWorks®7.0 64位软件支持包。IPSW-A7VME-WIN 64位和32位Windows软件包。单板计算机电话：248-295-0310solutions@acromag.comwww.acromag.com 30765 Wixom Rd，Wixom，MI 48393 USA XVME-6700 6U VME Intel®Celeron®2002E风冷处理器板所有商标均为其各自所有者的财产。版权所有©Acromag，Inc。
(XMC module P16 connector I/O optionally available on P0 connector, please consult the factory). XMCs are PCIe x8. Option to replace PMC/XMC #2 with the XBRD-9060. System Integrity A two-digit LED display is available for power-on self test (POST) codes for problems during the boot operation. It can then be used for application software user codes to aid in software debugging. Form Factor 6U VMEbus 9.2” (233mm) x 6.3” (160mm). Optional Expansion XBRD-9060 Allows more I/O to the front panel, as well as mSATA SSD modules to be added for storage. Front panel I/O available are Gb Ethernet, RS-232 serial port, and two USB ports. The XBRD-9060 also contains two mSATA sockets that allow two SSD drives to be added while still remaining within a single VME slot. Using the software RAID functionality of the QM87 PCH, these drives can even be setup as a RAID 0/1 array if redundancy or extra speed is desired. XVME-9640 Installed onto the rear slot directly behind the XVME-6700 to easily access all of the available I/O on the P2, and optionally P0 connectors, as well as allow mSATA SSD modules to be added for storage. Front panel I/O available are two Gb Ethernet ports, one VGA port, one DVI-D port, and two USB ports. Internal connectors are also available. Please see the user manual for more information. Environmental Operating temperature Standard temperature models: 0 to 70°C*. Extended temperature models: -40 to 75°C*. * application dependent - see manual for details. Storage temperature -55 to 85°C. Relative humidity 5% to 95% at 60°C non-condensing. Power Inputs from backplane: Dual Core Celeron. 5V (5V only backplane): 53W typical to 53W maximum, 37.5W typical. 5V (5V +3.3V backplane): 50W typical to 50.5W maximum, 35W typical. 3.3V (optional): 3W. +/-12V: Used only for PMC/XMC. Ordering Information Go to on-line ordering page > XVME-6720-7080-LF 6U VME SBC, P0 XVME-6720-7082-LF 6U VME SBC, P0, no battery XVME-6720-7080E-LF 6U VME SBC, P0, extended operating temperature XVME-6720-7082E-LF 6U VME SBC, P0, ext. operating temp., no battery XVME-6720-7081-LF 6U VME SBC, no P0 XVME-6720-7083-LF 6U VME SBC, no P0, no battery XVME-6720-7081E-LF 6U VME SBC no P0, extended operating temperature XVME-6720-7083E-LF 6U VME SBC no P0, ext. operating temp., no battery Note: Please contact the factory regarding conduction-cooled models. Accessories For more information, see www.acromag.com. XBRD-9060-LF Expansion I/O Carrier Module XVME-9640-1-LF 6U VMEbus Rear Transition Module with P0 connector XVME-9640-2-LF 6U VMEbus Rear Transition Module without P0 connector Cable Set 5028-568 Cable adapter: RJ Point 5 Male to RJ45 Female, 6 in 5028-572 Cable adapter: 26-pin to 2 USB, VGA, Serial, 18 in Software Development Tools Board support package includes driver and integration directions. XVME-6500/6700-BSP-LNX Linux board support package XVME-6500/6700-BSP-VXW VxWorks board support package XVME-6500/6700-BSP-WIN Windows board support package IPSW-A7VME-LNX Linux example libraries. IPSW-A7VME-VXW VxWorks® 7.0 64-bit, software support package. IPSW-A7VME-WIN 64-bit and 32-bit Windows software package. Single Board Computers Tel 248-295-0310 solutions@acromag.com www.acromag.com 30765 Wixom Rd, Wixom, MI 48393 USA XVME-6700 6U VME Intel® Celeron® 2002E Air-Cooled Processor Board All trademarks are property of their respective owners. Copyright © Acromag, Inc.
