IS200GGXIG1AFE/IS200DSPXH2CAA处理器模块
扩展功能除了全面的前面板和背板I/O功能外，XVME-6700还通过板上的两个PMC/XMC站点提供了增强的扩展功能。可以安装可选的XBRD9060扩展I/O载体模块代替一个PMC/XMC模块。XBRD-9060允许两个SSD mSATA驱动器，以及另一个千兆以太网端口、RS-232端口和两个USB 2.0端口。XVME-9640后部转换模块还可用于存储、联网和轻松访问P2连接器I/O。广泛的支持凭借超过60年的经验，其中超过35年从事国防和军事合同，我们致力于为行业提供最佳长期价值的嵌入式解决方案。该产品在美国设计和制造，保修期为2年。主要功能和优点基于赛扬的板，适用于成本敏感的应用程序基于FPGA的VME到PCIe桥接Intel 8系列QM87 PCH芯片组8GB高速DDR3L内存，带SODIMM锁定机制标准（16GB可选）前面板I/O包括：-双USB 2.0端口-VGA（带后切换）-通过RJ Point 5连接器的双Gb以太网端口-RS-232端口背板I/O包括：千兆以太网（可选P0上）-双SATA端口和双USB端口-DVI-D-RS-232/422/485-VGA（前置切换）XBRD-9060扩展模块增加：-双USB 2.0端口-千兆以太网端口（后置切换）-RS-232端口-双mSATA驱动器开机自检（POST）代码LCD显示XVME-6700 6U VME Intel®Celeron®2002E风冷处理器板Intel®Celron中央处理器◆ 每分钟2.0◆ 8GB DDR3L ECC RAM◆ BIOS可选字节交换电话248-295-0310solutions@acromag.comwww.acromag.com地址：30765 Wixom Rd，Wixom，MI 48393美国后部VME连接器INTEL 8系列芯片QM87平台控制器集线器8GB DDR3L INTEL 82580EB四位千兆以太网前面板TPM NCT6106D SUPER I/O 8GB DDR1L（ECC SODIMM）CRT视频开关（64）PMC I/O（1）DVI-D（64）XMC/PMC I/O（2）GbE VME PCIe x4（ECC SODIMM）（2）3GB/s SATA音频（线路输入/输出）（2个USB 2.0（1）GbE VGA（1）千兆PCIX（1）RS-232/422/485串行（软件可选择）PCIe x8 HDA（1）GbE PCIe x4 DDR3通道。A（2）GbE DDR3通道。B PCIe x8 PCIe x4 PCIe x4 LPC PCIe x8（2）RS-232（2）USB 2.0（2）GbE（1）RS-232 VGA XBRD-9060（可选（2）USB2.0）（1）RS232（1）GbE）GbE PCIX 3Gb/s SATA SPI VGA Artix-7 PCIX-VME桥接器PCIe PCIX桥接器PCIe MUX形状系数：6U VME ALC892 CODEC以太网MUX PCIX 128Mb闪存（BIOS）基于SATA的NAND闪存SSD（2）6GB/s SATA DMI/FDI（2）下USB 2.0（1）RS-232EXP站点（仅一个）XMC PMC这是一个很好的例子UPPER EXP SITE（仅一个）XMC PMC XBRD-9060 Intel®Celeron®2002E CPU ARTIXTM-7基于FPGA的VMEbus接口性能规格处理器和内存处理器Intel®Celtron®处理器2002E（2M缓存，1.50 GHz）。芯片组Intel 8系列QM87 PCH芯片组。Intel DH82QM87平台控制器集线器。内存8GB，1600 DDR3L ECC内存。闪存8GB标准。软件支持VxWorks、Linux和Windows 7+。总线合规性VMEbus接口P1和P2连接器使用基于FPGA的VME到PCIe桥接器与VME67x VME主/从兼容。A32/A24/A16/D32/D16/D8、MBLT64、2eVME/2eSST。双PMC/XMC站点32/64位，33/66/133MHz站点（IEEE P1386/P1386.1）。可选P0后连接器和P2连接器上的前面板I/O挡板和P4模块用户I/O。
Expansion Capabilities In addition to a comprehensive range of front panel and backplane I/O features, the XVME- 6700 offers increased expansion capabilities through two PMC/ XMC sites on the board. In lieu of one PMC/XMC module, the optional XBRD9060 expansion I/O carrier module may be installed. The XBRD-9060 allows for two SSD mSATA drives, as well as another Gigabit Ethernet port, RS-232 port, and two USB 2.0 ports. The XVME-9640 rear transition module is also available for storage, networking, and easy access to the P2 connector I/O. Extensive Support With over 60 years’ experience, more than 35 of those years working with defense and military contracts, we are committed to providing embedded solutions for the best long term value in the industry. Designed and manufactured in the USA, this product comes with a 2-year warranty. Key Features & Benefits Celeron-based board for cost-sensitive applications FPGA-based VME to PCIe bridge Intel 8-Series QM87 PCH chipset 8GB of high-speed DDR3L memory with SODIMM lock-down mechanism standard (16GB optional) Front panel I/O includes: - dual USB 2.0 ports - VGA (switched w/ rear) - dual Gb Ethernet ports thru RJ Point 5 connector - RS-232 port Backplane I/O includes: - dual Gigabit Ethernet (on optional P0) - dual SATA ports & dual USB ports - DVI-D - RS-232/422/485 - VGA (switched with front) XBRD-9060 expansion module adds: - dual USB 2.0 ports - Gigabit Ethernet port (switched with one of the rear ports) - RS-232 port - dual mSATA drives Power-on self-test (POST) code LCD display XVME-6700 6U VME Intel® Celeron® 2002E Air-Cooled Processor Board Intel® Celeron CPU ◆ TPM 2.0 ◆ 8GB DDR3L ECC RAM ◆ BIOS Selectable Byte Swapping Tel 248-295-0310 solutions@acromag.com www.acromag.com 30765 Wixom Rd, Wixom, MI 48393 USA REAR VME CONNECTORS INTEL 8 SERIES CHIPSET QM87 PLATFORM CONTROLLER HUB 8GB DDR3L INTEL 82580EB QUAD GIGABIT ETHERNET FRONT PANEL TPM NCT6106D SUPER I/O 8GB DDR3L (ECC SODIMM) CRT VIDEO SWITCH (64) PMC I/O (1) DVI-D (64) XMC/PMC I/O (1) GbE VME PCIe x4 (ECC SODIMM) (2) 3GB/s SATA AUDIO (LINE-IN/OUT) (2) USB 2.0 (1) GbE VGA (1) GbE PCIX (1) RS-232/422/485 SERIAL (SOFTWARE SELECTABLE) PCIe x8 HDA (1) GbE PCIe x4 DDR3 CH. A (2) GbE DDR3 CH. B PCIe x8 PCIe x4 PCIe x4 LPC PCIe x8 (2) RS-232 (2) USB 2.0 (2) GbE (1) RS-232 VGA XBRD-9060 (OPTIONAL (2) USB 2.0 ) (1) RS-232 (1) GbE (1) GbE PCIX 3Gb/s SATA SPI VGA Artix-7 PCIX-VME BRIDGE PCIe-PCIX BRIDGE PCIe MUX FORM FACTOR: 6U VME ALC892 CODEC ETHERNET MUX PCIX 128Mb FLASH (BIOS) SATA-BASED NAND FLASH SSD (2) 6GB/s SATA DMI/FDI (2) USB 2.0 LOWER (1) RS-232 EXP SITE (one only) XMC PMC UPPER EXP SITE (one only) XMC PMC XBRD-9060 Intel® Celeron® 2002E CPU ARTIXTM-7 FPGA-Based VMEbus Interface Performance Specifications Processor and Memory Processor Intel® Celeron® Processor 2002E (2M Cache, 1.50 GHz). Chipset Intel 8-Series QM87 PCH chipset. Intel DH82QM87 Platform Controller Hub. Memory 8GB of 1600 DDR3L ECC memory. Flash Memory 8GB standard. Software Support VxWorks, Linux and Windows 7+. Bus Compliance VMEbus Interface P1 and P2 connectors are compatible with VME67x VME Master/Slave using FPGA-based VME to PCIe bridge. A32/A24/A16/D32/D16/D8, MBLT64, 2eVME/2eSST. Dual PMC/XMC Sites 32/64-bit, 33/66/133MHz sites (IEEE P1386/P1386.1). Front panel I/O bezel and P4 module user I/O on optional P0 rear connector and P2 connector.
