IS200HFPAG1机械设备卡件
储存温度-55至85°C。60°C时相对湿度5%至95%，无冷凝。背板四核i7 5V（仅5V背板）的电源输入：最大89W，典型53W。5V（5V+3.3V背板）：最大86W，典型50W。3.3V（可选）：3W+/-12V：仅用于PMC/XMC。订购信息转到在线订购页面>XVME-6520-1160-LF 6U VME SBC，P0 XVME-6530-1160E-LF 6U VME SBC，P0，扩展工作温度XVME-6510-1161-LF 6U VME SBC、无P0 XVME-6520-1161E-LF 6U VME SBC、无Po、扩展工作温度X VME-6520-10162-LF 6U-VME SBC和P0，无电池XVME-6560-1162E-LF 6U-VME SBC，无P0，无电池XVME-6520-1163E-LF 6U VME SBC无P0（外部工作温度），无电池附件XBRD-9060-LF扩展I/O载体模块，适用于XVME-6500 XVME-9640-1-LF 6U VMSbus后部转换模块，带P0连接器XVME-96-2-LF 6U VM总线后部转换模块无P0连接器电缆组5028-568电缆适配器：RJ点5公插头到RJ45母插头，6英寸5028-572电缆适配器：26针到2个USB，VGA，串行，18英寸软件开发工具BSP包括驱动程序和集成方向。XVME-6500/6700-BSP-LNX Linux板支持包XVME-6500/6700-BSP-VXW VxWorks板支持包XVME-6500/7700-BSP-WIN Windows板支持包IPSW-A7VME-LNX Linux示例库。IPSW-A7VME-VXW VxWorks®7.0 64位软件支持包。IPSW-A7VME-WIN 64位和32位Windows软件包。单板计算机电话844-878-2352solutions@acromag.comwww.acromag.com 30765 Wixom Rd，Wixom，MI 48393 USA XVME-6500 6U VME Intel®Core™ i7风冷处理器板所有商标均为其各自所有者的财产。版权所有©Acromag，Inc.2021。数据如有更改，恕不另行通知。2021 4月在美国印刷。XBRD-9060 XVME-9640单板计算机公告#8401060b说明如果您是成千上万依赖VMEbus系统继续使用的人之一，您可以放心Acromag会为您服务。这款单板计算机使用Intel处理器更新您的传统系统，该处理器将提供增强的微体系结构、集成的图形和扩展的内存性能，具有8 GB高带宽DDR3L内存和ECC内存控制器。XVME-6700将使用现代技术为您的系统增加7至10年的寿命。该高性能SBC具有基于FPGA的VME到PCIe桥接器，解决了TSI148 VME接口芯片的寿命终结问题。坚固耐用的SODIMM可移动存储器由散热片材料包围，以提供强大的压紧机制。SODIM由四个螺钉固定，因此很容易更换故障存储器。操作系统软件Linux、VxWorks和Windows 7+Advanced Vector Extensions 2.0可增强浮点密集型应用程序的性能，并支持“超线程技术”，使每个内核可以使用两个软件线程，以更高效地使用CPU。
Storage temperature -55 to 85°C. Relative humidity 5% to 95% at 60°C non-condensing. Power Inputs from backplane Quad Core i7 5V (5V only backplane): 89W maximum, 53W typical. 5V (5V +3.3V backplane): 86W max., 50W typical. 3.3V (optional): 3W. +/-12V: Used only for PMC/XMC. Ordering Information Go to on-line ordering page > XVME-6520-1160-LF 6U VME SBC, P0 XVME-6520-1160E-LF 6U VME SBC, P0, extended operating temperature XVME-6520-1161-LF 6U VME SBC, no P0 XVME-6520-1161E-LF 6U VME SBC no P0, extended operating temperature XVME-6520-1162-LF 6U VME SBC, P0, no battery XVME-6520-1162E-LF 6U VME SBC, P0, ext. operating temp., no battery XVME-6520-1163-LF 6U VME SBC, no P0, no battery XVME-6520-1163E-LF 6U VME SBC no P0, ext. operating temp., no battery Accessories XBRD-9060-LF Expansion I/O Carrier Module for XVME-6500 XVME-9640-1-LF 6U VMEbus Rear Transition Module with P0 connector XVME-9640-2-LF 6U VMEbus Rear Transition Module no P0 connector Cable Set 5028-568 Cable adapter: RJ Point 5 Male to RJ45 Female, 6 in 5028-572 Cable adapter: 26-pin to 2 USB, VGA, Serial, 18 in Software Development Tools BSP includes driver and integration directions. XVME-6500/6700-BSP-LNX Linux board support package XVME-6500/6700-BSP-VXW VxWorks board support package XVME-6500/6700-BSP-WIN Windows board support package IPSW-A7VME-LNX Linux example libraries. IPSW-A7VME-VXW VxWorks® 7.0 64-bit, software support package. IPSW-A7VME-WIN 64-bit and 32-bit Windows software package. Single Board Computers Tel 844-878-2352 solutions@acromag.com www.acromag.com 30765 Wixom Rd, Wixom, MI 48393 USA XVME-6500 6U VME Intel® Core™ i7 Air Cooled Processor Board All trademarks are property of their respective owners. Copyright © Acromag, Inc. 2021. Data subject to change without notice. Printed in USA 4/2021. XBRD-9060 XVME-9640 Single Board Computers Bulletin #8401060b Description If you’re one of the thousands who depends on the continued use of your VMEbus systems you can feel confident that Acromag is there for you. This single board computer updates your legacy systems with an Intel processor that will deliver an enhanced microarchitecture, integrated graphics, and expanded memory performance with 8 GB of high-bandwidth DDR3L memory and ECC memory controllers. The XVME-6700 will add 7 to 10 years of life to your system with modern technology. This highperformance SBC features a FPGA-based VME to PCIe-bridge that solves the end of life issue with the TSI148 VME interface chip. Ruggedized SODIMM removable memory is surrounded by heat sink material to provide a robust hold-down mechanism. The SODIMM is secured with four screws so it is easy to replace faulty memory. Operating System Software Linux, VxWorks and Windows 7+ Advanced Vector Extensions 2.0 for enhanced performance on floating point-intensive applications and Hyper-Threading Technology that enables each core to use two software threads for more efficient use of the CPU.
