IS200HFPAG1ADC通用电气卡件
采用现代技术，XVME-6500将为您的系统增加7至10年的使用寿命。该高性能SBC具有基于FPGA的VME到PCIe桥接器，解决了TSI148 VME接口芯片的寿命终结问题。尖端技术具有可编程的功率限制，允许用户在热敏应用中“调低”CPU的最大功耗。坚固的SODIM 16GB可移动存储器由散热片材料包围，以提供机械和热鲁棒机制。SODIM由四个螺钉固定，因此很容易更换故障存储器。XVME-6500还利用Intel Advanced Vector Extensions 2.0增强浮点密集型应用程序的性能，并利用“超线程技术”使每个内核都可以使用两个软件线程，从而更高效地使用CPU。扩展功能除了全面的前面板和背板I/O功能外，XVME6500还通过板上的两个PMC/XMC站点提供了增强的扩展功能。可以安装可选的XBRD-9060扩展I/O载体模块代替一个PMC/XMC模块。XBRD-9060允许两个SSD mSATA驱动器，以及另一个千兆以太网端口、RS-232端口和两个USB 2.0端口。XVME-9640后部转换模块还可用于进一步存储、联网和轻松访问P2连接器I/O。操作系统软件VxWorks、Linux和Windows广泛支持凭借超过60年的经验，其中35年从事国防和军事合同，我们专注于提供嵌入式计算解决方案，以实现行业最佳长期价值。在美国设计和制造，标准保修期为2年。主要功能和优点第四代Intel Core：-四核i7 CPU，用于高性能（47W）可编程CPU电源，用于热敏应用基于FPGA的VME到PCIe桥接Intel 8系列QM87 PCH芯片组多达16GB高速DDR3L内存，带SODIMM锁定机制前面板I/O包括：-双USB 2.0端口-VGA（带后切换）-通过RJ Point 5的双Gb以太网端口连接器-RS-232端口背板I/O包括：-双千兆以太网（可选P0上）-双SATA端口和双USB端口-DVI-D-RS-232/422/485-
The XVME-6500 will add 7 to 10 years of life to your system with modern technology. This high-performance SBC features a FPGA-based VME to PCIe-bridge that solved the end of life issue with the TSI148 VME interface chip. Cutting-edge technology features programmable power limits allowing the user to “dial-down” the maximum power consumption of the CPU in heat sensitive applications. Ruggedized SODIMM 16GB removable memory is surrounded by heat sink material to provide a mechanically and thermally robust mechanism. The SODIMM is secured with four screws so it is easy to replace faulty memory. The XVME-6500 also takes advantage of Intel Advanced Vector Extensions 2.0 for enhanced performance on floating point-intensive applications and HyperThreading Technology that enables each core to use two software threads for more efficient use of the CPU. Expansion Capabilities In addition to a comprehensive range of front panel and backplane I/O features, the XVME6500 offers increased expansion capabilities through two PMC/XMC sites on the board. In lieu of one PMC/XMC module, the optional XBRD-9060 expansion I/O carrier module may be installed. The XBRD-9060 allows for two SSD mSATA drives, as well as another Gigabit Ethernet port, RS-232 port, and two USB 2.0 ports. The XVME-9640 rear transition module is also available for further storage, networking, and easy access to the P2 connector I/O. Operating System Software VxWorks, Linux and Windows Extensive Support With over 60 years experience, more than 35 of those years working with defense and military contracts, we are focused on providing embedded computing solutions for the best long term value in the industry. Designed and manufactured in the USA, with a 2-year standard warranty. Key Features & Benefits 4th Generation Intel Core: - Quad Core i7 CPU for high performance (47W) Programmable CPU power for heat sensitive applications FPGA-based VME to PCIe bridge Intel 8-Series QM87 PCH chipset Up to 16GB of high-speed DDR3L memory with SODIMM lock-down mechanism Front panel I/O includes: - dual USB 2.0 ports - VGA (switched w/ rear) - dual Gb Ethernet ports thru RJ Point 5 connector - RS-232 port Backplane I/O includes: - dual Gigabit Ethernet (on optional P0) - dual SATA ports & dual USB ports - DVI-D - RS-232/422/485 -
