IS200ICBDH1BAA工控自动化卡件
这种连接可以使用IC690ACC901电缆套件（包括电缆和微型转换器）进行，也可以根据特定应用的需要构建电缆。有关串行通信、电缆和转换器的更多信息，请参阅IC697 PLC安装手册。编程器连接，以太网TCP/IP通过以太网TCP/IP网络连接编程器需要在PLC中安装以太网接口模块。这可以是以太网控制器IC697CMM741或以太网接口（类型2）IC697CMM742。在将编程器和PLC连接到以太网TCP/IP网络之前，必须在以太网接口中设置IP地址。设置IP地址后，将PLC和运行Windows软件的编程器连接到以太网接口。有关通过以太网TCP/IP连接编程器的更多详细信息，请参阅TCP/IP以太网通信（类型2）用户手册和Windows编程手册GFK-1295。配置IC697 CPU和I/O系统配置有MS-DOS或基于Windows的编程软件，尽管MS-DOS软件不支持所有功能，如大容量内存区域（BMA），这需要Windows软件2.2版或更高版本。有关编程软件功能支持的详细信息，请参阅此模块附带的IPI。没有DIP开关或跳线用于配置系统。CPU在通电时和运行期间定期验证实际模块和机架配置。实际配置必须与编程配置相同。偏差报告给CPU报警处理器功能，以获得配置的故障响应。有关配置功能的说明，请参阅适用的编程软件用户手册。96 MHz，32位，浮点，6 Mbyte（中型）内存中央处理单元GFK-1433E 6 PLC CPU 1999年11月系列90-70可编程控制器数据表手册GFK-0600F 21-6电池A锂电池（IC697ACC701）安装如图2所示。该电池在断电时保持程序和数据存储器，并操作日历时钟。在拆卸旧电池之前，务必安装新电池。适用的可编程控制器参考手册中详细说明了低电量状态的具体指示。卸下模块从机架中的插槽中卸下模块时，应遵循以下说明。用拇指在板盖的前部，手指在板盖背面的塑料夹上，牢牢抓住板盖的顶部和底部。用手指挤压机箱盖背面的机架卡夹，使卡夹与机架导轨分离，然后用力拉动电路板，将其从背板连接器上卸下。沿卡导轨滑动电路板，然后将其从机架中取出。表3。IC697CPX928电池规格：20 C（68 F）时的保质期为5年电池：在未通电的情况下，标称记忆保留时间为6个月。5V总线所需电流3.1安培标称工作温度0至60C（32F至140F）；70 CFM强制空气需要0至50C（32F至122F）；无强制通风时钟精度“每天3.5秒最大运行时间时钟（内部定时）精度”。01%最大串行端口端口1:RS-232兼容端口2:RS-485兼容（光耦隔离）端口3:RS-485兼容（非隔离）编程器串行附件，或其他受支持的串行设备协议：设计用于支持VME标准C.1的SNP仅从VME兼容性系统。有关产品标准和通用规范，请参阅GFK-0867B或更高版本。对于需要符合更严格要求（例如FCC或欧盟指令）的安装，请参阅安装
This connection can be made with the IC690ACC901 cable kit (includes cable and miniconverter) or you may build cables to fit the needs of your particular application. See the IC697 PLC Installation Manual for more information on serial communications, cables, and converters. Programmer Connection, Ethernet TCP/IP Connecting your programmer via an Ethernet TCP/IP network requires installation of an Ethernet Interface module in the PLC. This can be either the Ethernet Controller, IC697CMM741, or Ethernet Interface (Type 2), IC697CMM742. Before connecting your programmer and PLC to the Ethernet TCP/IP network you must set the IP address in the Ethernet Interface. After setting the IP address, connect the PLC and the programmer running Windows software to the Ethernet Interface. For more detailed information on the programmer connection via Ethernet TCP/IP, refer to the TCP/IP Ethernet Communications (Type 2) User’s Manual, and the Windows programming manual, GFK-1295. Configuration The IC697 CPU and I/O system is configured with MS-DOS or Windows based programming software, although the MS-DOS software does not support all features, such as Bulk Memory Area (BMA), which requires the Windows software version 2.2 or later. See the IPI shipped with this module for programming software feature support details. There are no DIP switches or jumpers used to configure the system. The CPU verifies the actual module and rack configuration at power-up and periodically during operation. The actual configuration must be the same as the programmed configuration. Deviations are reported to the CPU alarm processor function for configured fault response. Refer to the applicable Programming Software User‘s Manual for a description of configuration functions. 96 MHz, 32-Bit, Floating Point, 6 Mbyte (Medium) Memory Central Processing Unit GFK-1433E 6 PLC CPUs November 1999 Series 90-70 Programmable Controller Data Sheet Manual GFK-0600F 21-6 Battery A lithium battery (IC697ACC701) is installed as shown in Figure 2. This battery maintains program and data memory when power is removed and operates the calendar clock. Be sure to install the new battery before removing the old battery. Specific indication of a low battery state is detailed in the applicable Programmable Controller Reference Manual. Removing a Module The instructions listed below should be followed when removing a module from its slot in a rack. Grasp the board firmly at the top and bottom of the board cover with your thumbs on the front of the cover and your fingers on the plastic clips on the back of the cover. Squeeze the rack clips on the back of the cover with your fingers to disengage the clip from the rack rail and pull the board firmly to remove it from the backplane connector. Slide the board along the card guide and remove it from the rack. Table 3. Specifications for IC697CPX928 Battery: Shelf life 5 years at 20 C (68 F) Battery: Memory retention 6 months nominal without applied power. Current required from 5V bus 3.1 Amps nominal Operating Temperature 0 to 60C (32F to 140F); 70 CFM forced air required 0 to 50C (32F to 122F); without forced air Time of Day Clock accuracy " 3.5 seconds per day maximum Elapsed Time Clock (internal timing) accuracy " .01% maximum Serial Ports Port 1: RS-232 compatible Port 2: RS-485 compatible (optocoupler isolated) Port 3: RS-485 compatible (not isolated) Programmer Serial Attachment, or other serial devices Protocols supported: SNP Slave only VME Compatibility System designed to support the VME standard C.1 Refer to GFK-0867B, or later for product standards and general specifications. For installations requiring compliance to more stringent requirements (for example, FCC or European Union Directives), refer to Installation
