IS200IGPAG2A模块备件
System BIOS Setup Utility（系统BIOS设置实用程序）在系统引导期间，按F2键访问Phoenix BIOS主屏幕。在此屏幕中，用户可以选择Phoenix（系统）BIOS的任何部分进行配置，例如软盘驱动器配置或系统内存。本节中显示的参数为默认值。帮助窗口每个菜单右侧的帮助窗口显示当前选定字段的帮助文本。当您将光标移动到每个字段时，它会更新。按任何菜单上的F1或ALT-H将显示“常规帮助”窗口，该窗口描述图例键及其替代键。任何窗口右侧的滚动条指示窗口中有多页信息。使用PGUP和PGDN显示每个页面。按HOME（主页）和END（结束）显示第一页和最后一页。按ENTER键显示每页。按ESC键退出当前窗口。C 98 C VMIVME-7750产品手册首次引导VMIVME-7720具有“首次引导”菜单，使用户可以一次性选择要从中引导的驱动器设备。从可启动磁盘安装时，此功能非常有用。例如，当从CD安装Windows NT时，进入First Boot（首次启动）菜单，并使用箭头键突出显示ATAPI CD-ROM驱动器。按ENTER继续系统引导。在启动周期的最开始按ESC键可访问此功能。在此屏幕上所做的选择仅适用于当前启动，不会在系统下次启动时使用。如果访问此功能时遇到问题，请在主BIOS设置屏幕中禁用QuickBoot模式。退出，保存更改并重试访问第一次启动菜单。时钟和日历，记录磁盘驱动器参数，并设置键盘的选定功能。QuickBoot启用后，将省略POST期间通常执行的某些检查，从而减少运行POST所需的时间。默认设置为“启用”。设置时间时间格式基于24小时军事时钟。例如，下午1点是13:00:00。按向左或向右箭头键将光标移动到所需字段（小时、分钟、秒）。按PGUP或PGDN键以逐步选择可用选项，或键入信息。设置日期按向左或向右箭头键将光标移动到所需字段（月、日、年）。按PGUP或PGDN键以逐步选择可用选项，或键入信息。
System BIOS Setup Utility During system bootup, press the F2 key to access the Phoenix BIOS Main screen. From this screen, the user can select any section of the Phoenix (system) BIOS for configuration, such as floppy drive configuration or system memory. The parameters shown throughout this section are the default values. Help Window The help window on the right side of each menu displays the help text for the currently selected field. It updates as you move the cursor to each field. Pressing F1 or ALT-H on any menu brings up the General Help window that describes the legend keys and their alternates. The scroll bar on the right of any window indicates that there is more than one page of information in the window. Use PGUP and PGDN to display each page. Pressing HOME and END displays the first and last page. Pressing ENTER displays each page. Press ESC to exit the current window. C 98 C VMIVME-7750 Product Manual First Boot The VMIVME-7750 has a First Boot menu enabling the user to, on a one time basis, select a drive device to boot from. This feature is useful when installing from a bootable disk. For example, when installing Windows NT from a CD, enter the First Boot menu and use the arrows keys to highlight ATAPI CD-ROM Drive. Press ENTER to continue with system boot. This feature is accessed by pressing the ESC at the very beginning of the boot cycle. The selection made from this screen applies to the current boot only, and will not be used during the next boot-up of the system. If you have trouble accessing this feature, disable the QuickBoot Mode in the Main BIOS setup screen. Exit, saving changes and retry accessing the First Boot menu. clock and calendar, record disk drive parameters, and set selected functions for the keyboard. QuickBoot When enabled, certain checks normally performed during the POST are omitted, decreasing the time required to run the POST. The default is Enabled. Setting The Time The time format is based on the 24-hour military-time clock. For example, 1 PM is 13:00:00. Press the left or right arrow key to move the cursor to the desired field (hour, minute, seconds). Press the PGUP or PGDN key to step through the available choices, or type in the information. Setting The Date Press the left or right arrow key to move the cursor to the desired field (month, day, year). Press the PGUP or PGDN key to step through the available choices, or type in the information.
