电路出现警告时，接地IIS已知存在：除非区域无危险，否则不要断开电源。IC698PSA100/350系统噪声抗扰度的H N G L2/N输入电源+端子板连接必须采取以下步骤使PLC系统正确接地，以减少因电噪声而发生错误的可能性。1.确保电源安装螺钉正确固定。2.电源上的GND端子必须使用AWG#12（3.33 mm2）导线连接到机架任一侧的GND终端。建议使用环形端子和星形垫圈。3.机架上的GND端子必须连接到良好的接地。注：每个RX7i模块在面板右侧都有一个降噪垫圈，可与相邻模块或机架保持接触。（RX7i电源的两侧都有防噪条。）安装没有防噪条的模块会使机架系统更容易受到电气噪声的影响。RX7i电源5 GFK-2237A规格额定电压：120/240 VAC，125VDC输入电压范围：85至264 VAC 47至63 Hz，100-150 VDC输入功率100W电源：125瓦（典型值），150瓦（最大值）输入功率350W电源：440瓦（典型），500瓦（最大）输入要求100W电源浪涌电流（冷启动–115VAC）15安培最大浪涌电流（热启动–230VAC）30安培最大输入要求350W电源浪涌电压（冷启动-115VAC）30安培最小浪涌电流（冷却启动–230VVAC）60安培最大功率因数0.99分钟（仅在90VAC和260VAC之间有效）输出要求（100 W电源）输出功率：最大100瓦（所有3个输出的总功率）输出电压：+5 VDC：4.875至5.25伏，0-20安培+12 VDC：11.64至12.6伏，0-2安培-12 VDC：-12.60至-11.64伏，0-1安培输出要求（350 W电源）输出功率：最高350瓦（所有三个输出的最大功率），0至12安培–12 VDC：–12.6至–11.64伏特，0至4安培隔离，输入至所有输出1500 VDC保护限值：过压限值：+5 VDC输出：5.7至6.7伏特过电流限值：+5VDC输出：21A（典型100W；66A（典型350W）+12 VDC输出：2.5A（典型100 W）；15A（典型350W）–12 VDC输出：3.5A（典型100W）；4.6A（典型350W）穿越（允许交流输入损失而不影响直流输出的时间）15毫秒min保持时间（从ACFAIL#系统故障信号激活到任何直流输出超出规格的时间）5毫秒min工作温度：100W电源350W电源0°C至60°C（32°F至140°F）0°C到60°C容量请参阅“订购信息”。*有关环境规范和标准（例如FCC或欧盟指令）的符合性，请参阅PACSystems RX7I安装手册GFK-2223的附录A。6 RX7i电源GFK-2237A订购信息描述目录号RX7i供电：85至264 VAC，47至63 Hz，125VDC输入，100瓦输出IC698PSA100B和更高版本RX7i电力供应：85至264VAC，47到63 Hz，125 VDC输入，350瓦输出IC698PSA350B和更高版本的120VAC输入机架/风扇组件IC697ACC721 240VAC输入机架和风扇组件IC69ACC724对于I类Div 2危险场所，需要出现以下声明。1.标有I类A、B、C和D组2区危险位置的设备仅适用于I类2区A、B，C、D组或非危险位置。2.警告-爆炸危险-更换部件可能会影响I类2类的适用性。3.警告–爆炸危险–除非电源已关闭或该区域已知无危险，否则不要断开设备。PACSystems*RX7i IC698PSA100E、IC698PSA350E GFK-2237F电源2010年8月PACSystems*RX7i电源提供+5 VDC、+12 VDC和-12 VDC电源，逻辑电平
Earth Ground IIS KNOWN TO BE WHILE CIRCUIT IS WARNING: DO NOT DISCONNECT ALIVE UNLESS AREA NONHAZARDOUS H N G L2/N Input Power + - Terminal Board Connections for IC698PSA100/350 System Noise Immunity The following steps must be taken to properly ground the PLC system to reduce the possibility of errors due to electrical noise. 1. Make sure that the power supply mounting screws are properly secured. 2. The GND terminal on the power supply must be connected to the GND terminal on either side of the rack using AWG #12 (3.33 mm2 ) wire. Use of a ring terminal and star washer is recommended. 3. The GND terminal on the rack must be connected to a good earth ground. Note: Each RX7i module has a noise reduction gasket on the right side of the faceplate that maintains contact with the adjacent module or the rack. (RX7i power supplies have the noise strip on both sides.) Installing modules that do not have this strip makes the rack system more susceptible to electrical noise. RX7i Power Supplies 5 GFK-2237A Specifications Nominal Rated Voltage: 120/240 VAC, 125VDC Input Voltage Range: 85 to 264 VAC 47 to 63 Hz, 100-150VDC Input Power 100W Supply: 125 watts (typical), 150 watts (maximum) Input Power 350W Supply: 440 watts (typical), 500 watts (maximum) Input Requirements 100W Supply Inrush current (cold start – 115VAC) 15 amps maximum Inrush current (cold start – 230VAC) 30 amps maximum Input Requirements 350W Supply Inrush current (cold start – 115VAC) 30 amps maximum Inrush current (cold start – 230VAC) 60 amps maximum Power Factor 0.99 min (only valid between 90VAC and 260VAC) Output Requirements (100 W Supply) Output Power: 100 watts maximum (total for all 3 outputs) Output Voltage: +5 VDC: 4.875 to 5.25 volts, 0—20 amps +12 VDC: 11.64 to 12.6 volts,, 0—2 amps –12 VDC: –12.60 to –11.64 volts, 0—1 amps Output Requirements (350 W Supply) Output Power: 350 watts maximum (total for all 3 outputs) Output Voltage: +5 VDC: 4.875 to 5.25 volts, 0 to 60 amps +12 VDC: 11.64 to 12.6 volts, 0 to 12 amps –12 VDC: –12.6 to –11.64 volts, 0 to 4 amps Isolation, input to all outputs 1500 VDC Protective Limits: Overvoltage Limit: +5 VDC Output: 5.7 to 6.7 volts Overcurrent Limit: +5 VDC output: 21A (typical 100W; 66A (typical 350W) +12 VDC output: 2.5A (typical 100W); 15A (typical 350W) –12 VDC output: 3.5A (typical 100W); 4.6A (typical 350W) Ride-through (time allowed for loss of AC input without affecting DC outputs) 15 milliseconds min Holdup Time (time from ACFAIL# system failure signal activated to when any DC output drops out of specification) 5 milliseconds min Operating Temperature: 100W Supply 350W Supply 0°C to 60°C (32° to 140°F) 0°C to 60°C (32°F to 140°F) Fan tray attachment required for full capacity. See “Ordering Information.” * For environmental specifications and compliance to standards (for example, FCC or European Union Directives), refer to Appendix A of the PACSystems RX7I Installation Manual, GFK-2223. 6 RX7i Power Supplies GFK-2237A Ordering Information Description Catalog Number RX7i Power Supply: 85 to 264 VAC at 47 to 63 Hz, 125VDC Input, 100 watt output IC698PSA100B and later RX7i Power Supply: 85 to 264 VAC at 47 to 63 Hz, 125VDC Input, 350 watt output IC698PSA350B and later 120VAC Input Rack/Fan Assembly IC697ACC721 240VAC Input Rack/Fan Assembly IC697ACC724 The following statements are required to appear for Class I Div 2 Hazardous Locations. 1. EQUIPMENT LABELED WITH REFERENCE TO CLASS I, GROUPS A, B, C, and D, DIV. 2 HAZARDOUS LOCATIONS IS SUITABLE FOR USE IN CLASS I, DIVISION 2, GROUPS A, B, C, D OR NON–HAZARDOUS LOCATIONS ONLY. 2. WARNING – EXPLOSION HAZARD – SUBSTITUTION OF COMPONENTS MAY IMPAIR SUITABILITY FOR CLASS I, DIVISION 2. 3. WARNING – EXPLOSION HAZARD – DO NOT DISCONNECT EQUIPMENT UNLESS POWER HAS BEEN SWITCHED OFF OR THE AREA IS KNOWN TO BE NON–HAZARDOUS.PACSystems* RX7i IC698PSA100E, IC698PSA350E GFK-2237F Power Supplies August 2010 The PACSystems* RX7i power supplies provide +5 VDC, +12 VDC, and -12 VDC power, logic level
