IS200HFPAG1模拟量输入模块
尺寸A-3 A面板安装详图对于过度振动是一个因素的安装，DIN导轨安装托架也应安装在面板上。安装尺寸见下页。200英寸5.1毫米170英寸4.3毫米170英寸4.3mm 2。1.1-1.4Nm（10-12 IN.LBS）的扭矩应为M3.5（#6-32）钢螺钉，该螺钉拧入含有内螺纹的材料中，最小厚度为2.4mm（.093 IN）。注：1。所有尺寸的公差均为±0.1mm（0.005IN）非累积公差。见注2。M3.5（#6）螺钉.62 IN REF 15.9mm分体式锁紧垫圈平垫圈托架面板A-4 VersaMax模块螺纹孔，电源和运营商用户手册GFK-1504N A模块空间要求132.6mm（5.20in）2 6 66.8mm（2.63in）132.6mm（1.50in）b 5 66.8mm（2.63英寸）132.6mm（5.20英寸）132.6 mm（5.20in）3 CPUE05:127mm（5.00in）c a b 4 a 163.5mm（6.45英寸）CPU005:106.7mm（4.20英寸）66.8mm（2.63 in）GFK-1504N附录a面板安装尺寸a-5 a模块尺寸上图显示了VersaMax模块的长度和宽度。在规划系统布局时，应考虑某些模块的物理间隙要求。模块托架的左侧有一个突出的连接器，该连接器安装在前一个托架中。该连接器的间隙必须包含在设备总宽度中，以便将来可能移除/插入载体。每个托架所需的间隙约为6.4毫米（.25英寸）。1个扩展发射机模块a在NIU站内，允许电缆通过串行端口b留出足够的空间用于扩展电缆2 CPU001或002，带电源模块的a允许打开CPU门以接近运行/停止开关的间隙b允许有足够的空间用于串行端口电缆c允许有足够空间用于电源布线3 CPU005/CPUE05带电源模块a允许有足够间隙用于打开CPU门以便接近运行/停停开关b允许有充足的空间用于串口电缆c允许有为电源布线4紧凑型端子载体a为设备布线留出足够的空间5扩展接收器模块、通信模块或电源增压器载体a（扩展接收器模块）为扩展电缆留出足够空间b（增压器载体）为电源布线留出足够空间6连接器类型载体a为电缆留出足够的。插入载体的使用是可选的。7网络接口单元a允许打开NIU门。b为电缆留出足够的间隙8插入端子b为布线留出足够的空间9辅助端子a可使用多个辅助端子。b为设备接线留出足够的空间10终端式载体a为设备接线a-6 VersaMax模块、电源和载体用户手册GFK-1504N CPU或扩展接收器模块至连接器式载体（如图所示）、紧凑型终端式载体、，或通信载体。340in.000 8.6mm.000 1.819in 46.2mm。689in REF 17.5mm IC200CPU001 CPU或扩展接收器模块至终端型载体。340in.8.6mm.000 1.859in 46.2mm，689in REF 17.5 mm IC200CHS002.000 4.010in 101.9mm IC200CPU01 GFK-1504N附录A面板安装尺寸A-7 A NIU至连接器型载体（如图所示），或紧凑型终端式托架.000IC200GBI001.000.689英寸REF 17.5mm 1.819英寸46.2mm 2.419英寸61.4mm。
Dimensions A-3 A Panel-Mounting Details For installations where excessive vibration is a factor, the DIN-rail mounted carriers should also be installed on a panel. Mounting dimensions are provided on the following pages. .200in 5.1mm .170in 4.3mm .170in 4.3mm 2. 1.1-1.4Nm (10-12 IN. LBS) OF TORQUE SHOULD BE TO M3.5 (#6-32) STEEL SCREW THREADED INTO MATERIAL CONTAINING INTERNAL THREADS AND HAVING A MINIMUM THICKNESS OF 2.4mm (.093 IN). NOTES: 1. TOLERANCES ON ALL DIMENSIONS ARE ±0.1mm (0.005IN) NON-CUMULATIVE. SEE NOTE 2. M3.5 (#6) SCREW .62in REF 15.9mm SPLIT LOCK WASHER FLAT WASHER CARRIER TAPPED HOLE IN PANEL A-4 VersaMax Modules, Power Supplies and Carriers User's Manual GFK-1504N A Module Space Requirements 132.6mm (5.20in) 2 6 66.8mm (2.63in) 132.6mm (5.20in) 8 110.5mm (4.35in) 97.8mm (3.85in) 105.4mm (4.15in) b a 10 110.5mm (4.35in) 132.6mm (5.20in) 110.5mm (4.35in) 33.0mm (1.30in) 9 139.7mm (5.5in) a a a 66.8mm (2.63in) c a b 7 85.9mm (3.38in) 132.6mm (5.20in) a b 132.6mm (5.20in) 1 a b 38.1mm (1.50in) b 5 66.8mm (2.63in) 132.6mm (5.20in) a 132.6mm (5.20in) 3 CPUE05: 127mm (5.00in) c a b 4 a 163.5mm (6.45in) CPU005: 106.7mm (4.20in) 66.8mm (2.63in) GFK-1504N Appendix A Panel Mounting Dimensions A-5 A Module Sizes The previous diagram shows the length and width of VersaMax Modules. Some modules have physical clearance requirements that should be considered when planning the layout of the system. Module carriers have a projecting connector on the left side that fits into the previous carrier. Clearance for this connector must be included in the overall equipment width allowed for potential future removal/insertion of a carrier. The clearance required per carrier is approximately 6.4mm (.25 in). 1 Expansion Transmitter Module a In NIU Station, allow clearance for cable to pass-through serial port b Allow adequate space for expansion cable 2 CPU001 or 002, with Power Supply Module a Allow clearance for opening CPU door to access Run/Stop switch b Allow adequate space for serial port cables c Allow adequate space for power wiring 3 CPU005 / CPUE05 with Power Supply Module a Allow clearance for opening CPU door to access Run/Stop switch b Allow adequate space for serial port cables c Allow adequate space for power wiring 4 Compact Terminal Style Carrier a Allow adequate space for device wiring 5 Expansion Receiver Module, Communications Module, or Power Supply Booster Carrier a (Expansion Receiver Module) Allow space for expansion cables b (Booster Carrier) Allow adequate space for power wiring 6 Connector-Style Carrier a Allow adequate space for cable. Use of Interposing Carrier is optional. 7 Network Interface Unit a Allow clearance for opening NIU door. b Allow adequate clearance for cables 8 Interposing Terminals b Allow adequate space for wiring 9 Auxiliary Terminals a Multiple Auxiliary Terminals may be used. b Allow adequate space for device wiring 10 Terminal-Style Carrier a Allow adequate space for device wiring A-6 VersaMax Modules, Power Supplies and Carriers User's Manual GFK-1504N A CPU or Expansion Receiver Module to Connector-Style Carrier (Shown), Compact Terminal-Style Carrier, or Communications Carrier .340in .000 8.6mm .000 1.819in 46.2mm .689in REF 17.5mm IC200CPU001 CPU or Expansion Receiver Module to Terminal-Style Carrier .340in 8.6mm .000 1.819in 46.2mm .689in REF 17.5mm IC200CHS002 .000 4.010in 101.9mm IC200CPU001 GFK-1504N Appendix A Panel Mounting Dimensions A-7 A NIU to Connector-Style Carrier (Shown), or Compact Terminal-Style Carrier .000 IC200GBI001 .000 .689in REF 17.5mm 1.819in 46.2mm 2.419in 61.4mm .
