卸下预接线电缆要安装预接线连接电缆，请将电缆连接器放在托架上的连接器上，然后向下按压，直到闩锁与连接器上的卡舌接合。闩锁电缆要卸下电缆，请握住电缆连接器并向上按压闩锁以释放连接器。拆卸电缆时，请记住操作设备可能非常热，尤其是在较高的环境温度下。如果设备很热，请勿直接触摸。如果系统正在运行，请勿触摸暴露的连接器引脚。连接器套件连接器套件（零件号IC200ACC304）可用于构建定制电缆或直接从现场设备连接电线。该套件包括两个连接器和盖子、四个螺钉、27个小触点和12个大触点。以下设备也是必需的，但不包括在套件中：压接工具小触点Molex 11-01-0008大触点Molex 11-101-0084提取工具小触点Molex 11-03-0002大触点Molex11-03-0006端子编号下图显示了从上方观察的连接器引脚的端子分配。A1 A2 A3 A4 A5 B5 B6 B3 B1 B2 A6 A7 A8 A9 A10 B12 B9 B10 B7 B8 A11 A12 A13 A14 A15 A16 B15 B16 B13 B14 B11 B17 B18 A18 A端子B端子电缆2-26 VersaMax模块、电源和托架用户手册GFK-1504N 2电缆IC200CBL230的端子分配下表显示了电缆IC200CB L230的终端分配和电线标记方案。彩色编码电线（IC200CBL230C及更早版本）的标记方案数字编码电线（IC 200CBL230-D及更高版本）的标识方案接线板位置端子#电线#基础色第1点/条纹第2点/条纹端子#电线#White电线基础色用黑色墨水A1 36 32黑色-1 1-ONE A2 35 34黑色-红色-2 2-TWO A3 34 23黑色-白色-绿色3 3-THREE A4 33标记11橙红-4 4-四A5 32 36红绿-5 5-五A6 25 16蓝红-6 6-六A7 24 22黑白橙7 7-七A8 23 38绿白-8 8-八A9 22 10红黑绿9 9-九A10 21 13蓝白-10 10-TEN A11 15 37蓝白橙11 11-ELEVEN A12 14 21橙黑绿12 12-TWELVE A13 13 9绿黑橙13 13-THIREEN GFK-1504N第2章安装2-27 2颜色编码电线（IC200CBL230C及更早版本）的标记方案编号-文本编码电线（IC 200CBL230-D及更高版本）的编号标记方案接线端子位置端子#电线#第一个点/条第二个点/线端子#电线#白色电线基本颜色用黑色墨水标记以下内容纯色/无标记注：为了适应普通连接的较大电流，IC200CBL230C和更早版本为端子1-4（导线1-8）提供了两条颜色编码的22AWG导线，而IC200CBL2 30D和更晚版本为每个端子33-36提供了一条颜色编码18AWG导线。小心不要将测试探针插入触点。将导致触点永久损坏。连接器导线触点探针（插入触点）2-28 VersaMax模块、电源和托架用户手册GFK-1504N 2安装插入端子IC200TBM011、IC200TBM912、IC200TBM014、IC200TB M015插入端子用于为连接器型托架（IC200CHS003）提供现场接线连接。本节介绍了几种类型的插入式端子的安装和接线。下图所示的插入式端子可用于箱式端子（IC200TBM002）、弹簧夹式端子（IC200 TBM005）或屏障式端子（IC 200TBM001）。
Removing a Prewired Cable To install a prewired connecting cable, place the cable connector over the connector on the carrier and press downward until the latch engages the tab on the connector. Latch Cable To remove the cable, hold the cable connector and press up on the latch to release the connector. When removing the cable, remember that operating equipment may be very hot, especially at higher ambient temperatures. If the equipment is hot, do not touch it directly. DO NOT TOUCH exposed connector pins if the system is operating. Connector Kit A connector kit (part number IC200ACC304) is available for building custom cables or for connecting wires directly from field devices. The kit includes two connectors and covers, four screws, 27 small contacts, and 12 large contacts. The following equipment is also required but not included in the kit: Crimping Tools small contact Molex 11-01-0008 large contact Molex 11-01-0084 Extraction Tools small contact Molex 11-03-0002 large contact Molex 11-03-0006 Terminal Numbering The following illustration displays the terminal assignments of the connector pins as viewed from above. A1 A2 A3 A4 A5 B5 B6 B3 B4 B1 B2 A6 A7 A8 A9 A10 B12 B9 B10 B7 B8 A11 A12 A13 A14 A15 A16 B15 B16 B13 B14 B11 B17 B18 A17 A18 A terminals B terminals Cable 2-26 VersaMax Modules, Power Supplies and CarriersUser Manual GFK-1504N 2 Terminal Assignments for Cable IC200CBL230 The table below shows terminal assignments and wire marking schemes for cable IC200CBL230. Marking Scheme for Color-coded Wire (IC200CBL230C and earlier) Marking Scheme for NumberText coded wire (IC200CBL230D and later) Terminal Block Position Terminal # Wire # Bas color 1st spot/ stripe 2nd spot /stripe Terminal # Wire # White wire base color marked with the following in black ink A1 36 32 Black — — 1 1-ONE A2 35 34 Black Red — 2 2-TWO A3 34 23 Black White Green 3 3-THREE A4 33 11 Orange Red — 4 4-FOUR A5 32 36 Red Green — 5 5-FIVE A6 25 16 Blue Red — 6 6-SIX A7 24 22 Black White Orange 7 7-SEVEN A8 23 38 Green White — 8 8-EIGHT A9 22 10 Red Black Green 9 9-NINE A10 21 13 Blue White — 10 10-TEN A11 15 37 Blue White Orange 11 11-ELEVEN A12 14 21 Orange Black Green 12 12-TWELVE A13 13 9 Green Black Orange 13 13-THIRTEEN GFK-1504N Chapter 2 Installation 2-27 2 Marking Scheme for Color-coded Wire (IC200CBL230C and earlier) Marking Scheme for Number- Text coded wire (IC200CBL230D and later) Terminal Block Position Terminal # Wire # Bas color 1st spot/ stripe 2nd spot /stripe Terminal # Wire # White wire base color marked with the following in black ink Solid color/no markings Note: To accommodate larger currents for common connections, IC200CBL230C and earlier provide two color-coded 22AWG wires each for terminals 1-4 (wires 1-8) while IC200CBL230D and later provide one color-coded 18 AWG wire for each terminal 33-36. Caution Do not insert a test probe into the contacts. Permanent damage to the contacts will result. Connector Wire Contact Probe (Inserted into Contact) 2-28 VersaMax Modules, Power Supplies and CarriersUser Manual GFK-1504N 2 Installing Interposing Terminals IC200TBM011, IC200TBM012, IC200TBM014, IC200TBM015 Interposing Terminals are used to provide field-wiring connections to a Connector-style Carrier (IC200CHS003). Installation and wiring for several styles of Interposing Terminals is described in this section. The Interposing Terminals illustrated below are available with box-style terminals (IC200TBM002), spring-clamp style terminals (IC200TBM005), or barrier-style terminals (IC200TBM001).
