块或电路的故障导致适当的块诊断LED指示和故障记录到每个PLC的故障表中。TMR模拟输入继续与输入组的剩余块或“支路”一起工作。出现故障的TMR模拟输入块可在不干扰输入组的功能部分或系统的任何其他部分的情况下热更换（通电）。所有模拟输入模块提供各种诊断功能。此外，这些模块执行内部电路的自动自校准。请参考Genius用户手册了解更多详情。AC型号#（IC660）BBA100 BBA104 BBA106 BBA101 BBA103 DC型号#a 4–20maJ、K、T、E、B、R、S型铂镍铜线型，N标称P.S.电压（AC）115 115 115 115标称P.S.电流（DC）125（24/48）125（24-48）125循环10ms DC块隔离1500V 1500V 1500V 1500V 1500伏共模抑制60dB 0–1Khz 45dB 50，60Hz 45dB 50、60Hz 45dB 50、60V共模电压+/-170V输入分辨率12位（+符号）1µa 1µa 0.1°C 2000欧姆n/a n/a输出负载（电流模式）0–300欧姆0–850欧姆0–850ohms诊断LED–单元正常（块或点故障指示）–启用（在线和强制点指示）可用诊断：块丢失/超出范围反馈错误是是否是是是是重量4磅（1.8千克）–4-26 Genius®模块冗余灵活三模块冗余（TMR）系统GFT-177A技术产品概述–1998年2月4 Genius手持式监视器手持式监视器（HHM）是一种方便的维护工具，配置和操作员界面工具，用于Genius块、现场控制站和网络。其在GMR系统中的主要功能是初始配置每个Genius块和现场控制站，协助验证接线和每个点的操作，并监控网络的性能。它可以用作维护和故障排除工具，以跟踪故障并从任何模块或现场控制模块读取详细的故障信息。它通常是临时使用的，而不是永久连接到系统。HHM连接到任何块、现场控制站或Genius总线控制器（GBC）的任何Genius网络。在网络上的任何点连接HHM的能力提供了对任何设备的远程监控。监视器/配置键开关允许手持式监视器的配置限制或允许HHM访问某些功能，如清除故障、更改块或模块配置以及强制电路。HHM显示器由菜单驱动，使用四个功能键选择菜单项。通过更换定义其功能的插槽PROM，可以轻松升级HHM。F1 F2 F3 F4 7 8 9 Home 4 5 6菜单1 2 3 Clear+0 D On s-Off HHM Cable GENIUS GE Fanuc手持式监视器模式选择钥匙开关功能键十进制键操作键充电器/适配器连接46619 GENIUS手持式监视器系统初始化后，HHM是一个通用的启动和维护工具。在任何时候，HHM本身都可以被配置和锁定，以便功能可以被限制到预设参数。
failure of a block or circuit results in both the appropriate block diagnostic LED indication and the fault being logged into fault tables of each PLC. TMR analog inputs continue to operate with the remaining blocks or “legs” of the input group. Failed TMR analog input blocks may replaced hot (power on) without disturbing the functioning portion of the input group or any other part of the system. All analog input blocks provide a variety of diagnostic capabilities. In addition, the blocks perform automatic self–calibration of internal circuitry. Please refer to the Genius user’s manuals for more details. AC MODEL # (IC660) BBA100 BBA104 BBA106 BBA101 BBA103 DC MODEL # (IC660) (BBA020) (BBA024) (BBA026) (BBA021) (BBA023) Number of 4In/2Out 4In/2Out 6 In 6 In R.T.D. 6 In T.C. Operating Modes TMR/HSB SIMPLEX TMR/HSB SIMPLEX TMR/ SIMPLEX TMR/ SIMPLEX TMR/ SIMPLEX Input Range(s) or Linearization (RTD) or T.C. Types (T.C.) 4–20ma 0–10Vdc –10–+10Vdc 0–5Vdc –5–+5Vdc 4–20ma 4–20ma Platinum Nickel Copper Linear Type J, K, T, E, B, R, S, N Nominal P.S. Voltage (AC) 115 115 115 115 115 Nominal P.S. Voltage (DC) (24/48) 125 (24/48) 125 (24/48) 125 (24/48) 125 (24/48) AC Voltage Range (47–63Hz) 98–132 93–132 93–132 93–132 93–132 DC Voltage Range (18–56) 105–145 (18–56) 105–145 (18–56) 105–145 (18–56) 105–145 (18–56) P.S. Dropout Time 1 Cycle 10ms DC 1 Cycle 10ms DC 1 Cycle 10ms DC 1 Cycle 10ms DC 1 Cycle 10ms DC Block Isolation 1500V 1500V 1500V 1500V 1500V Common Mode Rejection 60dB 0–1Khz 45dB 50,60Hz 45dB 50,60Hz Common Mode Voltage +/– 170V Input Resolution 12 bits (+ sign) 1µa 1µa 0.1°C 2000ohms n/a n/a Output Load (Current Mode) 0–300ohms 0–850ohms 0–850ohms Diagnostic LEDs –Unit OK (Block or Point Fault Indication)– – Enabled (On–Line and Forced Point Indication) Diagnostics Available: Loss of Block Under/Overrange Feedback Error Yes Yes No Yes Yes Yes Yes Yes Yes Weight 4 lbs. (1.8 kg)– 4-26 Genius® Modular Redundancy Flexible Triple Modular Redundant (TMR) System GFT-177A Technical Product Overview – February 1998 4 Genius Hand-Held Monitor The Hand-Held Monitor (HHM) is a convenient maintenance, configuration and operator interface tool for use with Genius blocks, Field Control Stations, and networks. Its main functions in a GMR system are to initially configure each Genius block and Field Control Station, to assist in verifying wiring and the operation of each point, and to monitor the performance of an network. Longerterm, it can be used as a maintenance and troubleshooting tool to track down faults and read detailed fault information from any block or Field Control module. It is typically used temporarily and not permanently-connected to a system. The HHM connects to any Genius network at any block, Field Control Station, or Genius Bus Controller (GBC). The ability to connect the HHM at any point on a network provides remote monitoring of any device. A Monitor/Configure keyswitch allows the configuration of the Hand-Held Monitor to either restrict or allow the HHM to access certain functions such as clearing faults, making block or module configuration changes, and forcing of circuits. The HHM display is menu– driven and utilizes four function keys to select menu items. The HHM can be easily upgraded by replacing a socketed PROM which defines its functions. F1 F2 F3 F4 7 8 9 Home 4 5 6 Menu 1 2 3 Clear + 0 D On s - Off HHM Cable GENIUS GE Fanuc Hand Held Monitor Mode Select Keyswitch Function Keys Decimal Keys Operation Keys Connection for Charger/Adapter 46619 Genius Hand-held Monitor After system initialization, the HHM is a versatile startup and maintenance tool. At any time, the HHM itself can be configured and locked so that functionality may be restricted to preset parameters.
