IS200VCRCH1BBB系统模块卡件
该特性与广泛的用户提供的负载设备兼容，例如：电机起动器、定子和指示器。操作现场设备的电源必须由用户提供。LED指示灯位于模块顶部，指示每个点的开/关状态。该LED块有两个水平行，每行有八个绿色LED。该模块仅使用标有A1至8的顶行（点1至8）。右侧的红色LED（标记为“F”）位于两排绿色LED中间，用作保险丝熔断指示灯；当任何保险丝熔断时，它将打开。该模块有两个5安培保险丝，每个保险丝保护四个；第一保险丝保护A1-A4，第二保险丝保护A5-A8。保险丝与保险丝电气连接。铰链门的内外表面之间有一个插件。朝向模块内部的表面（当铰链门关闭时）具有接线信息，并且识别信息可以记录在外表面上。插件的左外边缘为蓝色，表示低压模块。该模块可安装在Series 90-30 PLC系统中5或10插槽基板的任何I/O插槽中。表7-8。IC693MDL731额定电压12/24伏DC电压范围12至24伏DC（+20%，-15%）s每个模块8（一组八个）场侧和逻辑侧之间的隔离1500伏电流2每点4 50 C（122 F）时每个保险丝2 60 C（140 F）时每保险丝2特性电压降0.75伏关断状态漏电1接通响应时间2 ms关断响应时间2毫秒功耗55如图2-27所示，底板上5伏母线的负载电流取决于环境温度。产品标准和一般规范参见附录B。7 7-16 Series 90-30 PLC I/O模块规格–2000 GFK-0898F IC693MDL731模块现场接线信息下图提供了将用户提供的负载设备和电源连接到12/24伏直流负逻辑2安培模块的接线信息。TERMILS现场布线1 3 5 7 9 11 13 15 17 19 4 8 10 14 16 18 12 2 6 a3099模块RY A1 A2 A3 1 f OTHER S A4 A5 A6 A7 A8 5Aµ保险丝用于S A1–A4 OTHER 5A S保险丝用于S A5–A8 OTHER图7-13。IC693MDL731模块现场接线10 20 30 50 60总模块负载电流环境温度3836 2A每点40 4 1A每点8 6 4 2（）图7-14。IC693MDL731分立模块7 GFK-0898F第7章-分立模块7-17安装和拆卸带固定螺钉的IC693MDL 731端子板分立模块IC693ML 730F（及更高版本）和IC693MD 731F（及更新版本）具有配备固定螺钉的特殊端子板，如下图所示。在PLC受到严重振动的应用中，这些螺钉可防止端子板与模块的连接恶化。a3082C IC693MDL731F A1 A6可拆卸端子板铰链盖固定螺钉A3 A4 A7 A8+–模块目录号图7-15。带固定螺钉的端子板拆卸：要拆卸这些端子板，首先松开端子板前部的两个固定螺钉，然后按照第2章中的标准拆卸说明进行操作。固定螺钉固定在接线板中，无需完全拆除。安装：要安装这些端子板，请遵循第2章中的标准安装说明，然后将两个固定螺钉拧紧至8至10英寸磅（1牛顿米）的扭矩。7 7-18 Series 90-30 PLC I/O模块规格–2000 GFK-0898F 12/24 V DC正极逻辑-0.5 Amp，8点IC693MDL732 Series 90-30可编程逻辑控制器的12/24 V直流正极逻辑0.5 Amp模块在一组8个点中提供8个点，带有电源端子。该模块设计为具有正逻辑特性，因为它从用户或正电源总线向负载提供电流。该设备连接在负电源总线和模块之间。该特性与广泛的用户提供的负载设备兼容，例如：电机起动器、定子和指示器。操作现场设备的电源必须由用户提供。LED指示灯位于模块顶部，指示每个点的开/关状态。该LED块有两个水平行，每行有八个绿色LED，顶行标记为A1至
The characteristics are compatible with a wide range of user-supplied load devices, such as: motor starters, soleids, and indicators. Power to operate the field devices must be supplied by the user. LED indicators which provide the ON/OFF status of each point are located at the top of the module. This LED block has two horizontal rows with eight green LEDs in each row. This module uses only the top row labeled A1 through 8 (points 1 through 8). A red LED (labeled “F”)on the right and centered between the two rows of green LEDs functions as a blown fuse indicator; it turns ON when any fuse is blown. The module has two 5 amp fuses with each fuse protecting four s; the first fuse protects A1 - A4, the second fuse protects A5 - A8. The fuses are electrically connected to the same . An insert goes between the inside and outside surface of the hinged door. The surface towards the inside of the module (when the hinged door is closed) has wiring infortion, and identification infortion can be recorded on the outside surface. The outside left edge of the insert is color-coded blue to indicate a low-voltage module. This module can be installed in any I/O slot of a 5 or 10-slot baseplate in a Series 90-30 PLC system. Table 7-8. Specifications for IC693MDL731 Rated Voltage 12/24 volts DC Voltage Range 12 to 24 volts DC (+20%, –15%) s per Module 8 (one group of eight s) Isolation 1500 volts between field side and logic side Current 2 per point 4 per fuse at 50 C (122 F) 2 per fuse at 60 C (140 F) Characteristics Voltage Drop 0.75 volts Off-state Leakage 1 On Response Time 2 ms Off Response Time 2 ms Power Consumption 55 (all s on) from 5 volt bus on backplane load current is dependent upon ambient temperature as shown in figure 2-27. Refer to Appendix B for product standards and general specifications. 7 7-16 Series 90-30 PLC I/O Module Specifications – 2000 GFK-0898F IC693MDL731 Module Field Wiring Infortion The following figure provides wiring infortion for connecting user supplied load devices and power source to the 12/24 volt DC negative logic 2 amp module. TERMILS FIELD WIRING 1 3 5 7 9 11 13 15 17 19 4 8 10 14 16 18 20 12 2 6 a43099 MODULE RY A1 A2 A3 1 f OTHER S A4 A5 A6 A7 A8 5A µ Fuse for s A1 – A4 OTHER 5A S Fuse for s A5 – A8 OTHER S Figure 7-13. IC693MDL731 Module Field Wiring 10 20 30 50 60 TOTAL MODULE LOAD CURRENT AMBIENT TEMPERATURE a43836 2A PER POINT 40 4 1A PER POINT 8 6 4 2 () Figure 7-14. Load Current vs. Temperature for IC693MDL731 Discrete Modules 7 GFK-0898F Chapter 7 – Discrete Modules 7-17 Installing and Removing IC693MDL731 Termil Boards with Holding Screws Discrete modules IC693MDL730F (and later) and IC693MDL731F (and later) have a special termil board that is equipped with holding screws, as shown in the figure below. These screws prevent the termil board-to-module connections from deteriorating in applications where the PLC is subjected to severe vibration . a43082C IC693MDL731F A1 A6 Removeable Termil Board Hinged Cover Holding Screw Holding Screw A3 A4 A7 A8 + – Module Catalog Number Figure 7-15. Termil Board with Holding Screws Removing: To Remove these termil boards, first loosen the two holding screws on the front of the termil board, then follow the standard remol instructions in Chapter 2. The holding screws are held captive in the termil board and do t have to be completely removed. Installing: To install these termil boards, follow the standard installation instructions in Chapter 2, then tighten the two holding screws to 8 to 10 inch pounds (1 Newton-meter) of torque. 7 7-18 Series 90-30 PLC I/O Module Specifications – 2000 GFK-0898F 12/24 Volt DC Positive Logic - 0.5 Amp, 8 Point IC693MDL732 This 12/24 volt DC Positive Logic 0.5 Amp module for the Series 90-30 Programble Logic Controller provides 8 points in one group of eight with a power termil. This module is designed to have positive logic characteristics in that it sources current to the loads from the user or positive power bus. The device is connected between the negative power bus and the module . The characteristics are compatible with a wide range of user-supplied load devices, such as: motor starters, soleids, and indicators. Power to operate the field devices must be supplied by the user. LED indicators which provide the ON/OFF status of each point are located at the top of the module. This LED block has two horizontal rows with eight green LEDs in each row with the top row labeled A1 through
