并且具有更高的压力范围-1…689 bar（-14.5至10000 psi）和IO Link 1.1通信协议（仅显示型号）。836P功能和优点显示•压力范围：-1…551巴（-14.5磅/平方英寸至8000磅/平方英尺）•嵌入式IO链路通信协议有助于减少停机时间并提高生产率•可用于各种工艺连接以满足您的应用需求•可旋转外壳（320°）和头部（330°）提供应用灵活性•IP67外壳等级非显示•坚固，微型尺寸–市场上最小的尺寸之一•可用于各种工艺连接以满足您的应用需求•-1…689 bar（-30 in.Hg至10000 psi）836E显示器836E非显示器836P显示器836P非显示器•活动：产品类别中最新的产品。•主动成熟：产品完全受支持，但存在更新的产品或系列。通过迁移获得价值。•生命结束：宣布终止日期–积极执行迁移和上次购买。产品通常可在停产日期前订购。1•停产：不再生产或采购新产品。2可能提供维修/更换服务。1-特定项目的停机可能发生在停产日期之前。2-有限的库存可能在区域内以耗尽模式提供。主动主动成熟终止生命周期中断产品生命周期使用web上的产品生命周期状态搜索工具按目录号查找特定的生命周期信息。*终止日期可能会更改。规范836E 836P认证cULus、CE、3A**cULus，CE、EMC、RoHS、，3A**电源电压12…30V DC 15…35V DC输出双PNP和模拟4…20 mA双PNP及模拟4…20mA电源电流1000万>1亿过压极限1.5倍最大工作压力2倍1.7倍压力范围1000 psi和1500 psi响应时间开关输出：≤20 ms模拟输出≤200 ms开关输出：带IO链路模拟输出≤20 ms过程连接件1/4“NPT公/母、G 1/4 BSPP公/母，SAE 7/16…20 UNF公/母1/4”NPT公/女，G 1/4 BSP公/母，SAE 7/16…20 UNF公/母传感器配置ReadWin 2000软件使用Studio 5000 Logix Designer®836E显示压力传感器与836P显示压力传感器相比，通过IO链路通过USB配置进行连接**卫生连接在836P压力传感器的产品路线图中。旧836E的卫生接头目前已停产。836E显示器836P显示器直径：38.5 mm直径：38 mm 141 mm（近似值）92 mm（近似）836E目录号更换目录号836P注释836E-DC1EN1-D4 836P-D2NFGB20PA-D4迁移指南列出了库存零件的所有首选目录号。如果您需要与特定压力范围或工艺连接相对应的表中未列出的零件/目录号，请参阅我们的网站了解更多配置。http://rockwellautomation.com/传感器开关/压力传感器/固态图目录号迁移下表列出了停用的836E目录号，并与推荐的836P目录号进行了交叉引用。注意：新旧压力传感器的接线图相同。836P显示器836E显示器双PNP模拟规格836E非显示器836P非显示器认证CE cULus，CE电源电压12…30V DC 8…30V直流输出模拟4…20mA模拟4…20 mA电源电流<30 mA<25 mA重复性<0.2%压力上限<0.1%压力上限长期漂移<每年0.15%<0.1%压力下限精度<0.5%压力上限<量程压力的0.3%
and feature higher pressure ranges -1…689 bar (-14.5 to 10,000 psi) and IO-Link 1.1 communications protocol (display model only). 836P Features and Benefits Display • Pressure ranges: -1...551 bar (-14.5 psi to 8,000 psi) • Embedded IO-Link communication protocol helps minimize downtime and increase productivity • Available in various process connections to fit your application needs • Rotatable housing (320°) and head (330°) provide application flexibility • IP67 enclosure rating Non-display • Tough, miniature form factor – one of the smallest on the market • Available in various process connections to fit your application needs • -1...689 bar (-30 in. Hg to 10,000 psi) 836E Display 836E Non-display 836P Display 836P Non-display • ACTIVE: Most current offering within a product category. • ACTIVE MATURE: Product is fully supported, but a newer product or family exists. Gain value by migrating. • END OF LIFE: Discontinued date announced – actively execute migrations and last time buys. Product generally orderable until the discontinued date.1 • DISCONTINUED: New product no longer manufactured or procured.2 Repair/exchange services may be available. 1 - Outages on specific items may occur prior to the Discontinued date. 2 - Limited stock may be available in run-out mode, regionally. ACTIVE ACTIVE MATURE END OF LIFE DISCONTINUED Product Lifecycle Use the Product Lifecycle Status search tool on the web to find specific lifecycle information by catalog number. * Discontinued date may be subject to change. Specifications 836E 836P Certifications cULus , CE , 3A** cULus , CE , EMC , RoHS, 3A** Supply Voltage 12…30V DC 15…35V DC Output Dual PNP and Analog 4…20 mA Dual PNP and Analog 4…20 mA Supply Current 10 million >100 million Over Pressure Limit 1.5 times Maximum working presure 2 times 1.7 times for pressure ranges 1,000 psi and 1,500 psi Response Time Switch Output : ≤20 ms Analog Output ≤200 ms Switch Output : ≤20 ms with IO-Link Analog Output 3 ms Process Connections 1/4” NPT male / female, G 1/4 BSPP male /female, SAE 7/16…20 UNF male / female 1/4” NPT male / female, G 1/4 BSPP male /female, SAE 7/16…20 UNF male /female Sensor Configuration ReadWin 2000 software connected via USB Configuration through IO-Link using Studio 5000 Logix Designer® 836E Display Pressure Sensor Compared to the 836P Display Pressure Sensor **Sanitary connections are in the product roadmap for the 836P pressure sensors . The sanitary connections for the old 836E are currently discontinued. 836E Display 836P Display Dia : 38.5 mm Dia : 38 mm 141 mm (approx.) 92 mm (approx.) 836E Catalog Number Replacement Catalog Number 836P Note 836E-DC1EN1-D4 836P-D2NFGB20PA-D4 The migration guide lists all the preferred catalog numbers that are stocked parts. If you need a part/catalog number that is not listed in the table corresponding to specific pressure ranges or process connections, please refer to our website for additional configurations. http://rockwellautomation.com/ Sensors-Switches/Pressure-Sensors/Solid-State Diagrams Catalog Number Migration The 836E catalog numbers being discontinued are listed in the table below with a cross reference to the recommended 836P catalog numbers. Note : The wiring diagrams are the same for the old and the new pressure sensors. 836P Display 836E Display Dual PNP Analog Specifications 836E Non-display 836P Non-display Certifications CE cULus , CE Supply Voltage 12…30V DC 8…30V DC Output Analog 4…20 mA Analog 4…20 mA Supply Current <30 mA < 25 mA Repeatability <0.2 % upper pressure limit <0.1 % upper pressure limit Long Term Drift <0.15% per year <0.1 % upper pressure limit Accuracy <0.5% of upper pressure range limit <0.3% of span Pressure
