PFCL201 50.0KN工控备件机器人模块
一个扩展插座：SIM-ETH3模块提供第二个SIM插座。Profinet、Profibus DP或Ethernet/IP的现场总线模块。4个称重传感器的换档调节板（仅限IT3 Blackbox）。一个用于数字输入/输出或模拟输出的插座：2个数字输入和2个数字输出，光电隔离，24 VDC，用于设定点监控或简单填充应用的输出，用于开始称重和计费或开始/停止填充的输入。模拟输出0 20 mA、4 20 mA、0 10 V或2 10 V、15 it、–––b 32000分度，用于重量模拟输出。数据存储日期和时间的电源故障安全存储。应用程序存储器：基本：9个可选皮重，计数：9个参考重量，卡车：99个第一重量，填充：9个产品。更多选项内部W&M批准的数据存档记录最新的1000000称重结果。两个刻度底座DADM的接口，用于连接两个模拟应变计刻度和称重传感器。PC ScaleView PC软件，用于显示称重数据和秤状态信息（零件证书待定）。PC/PC COM+ARCHIVE PC软件，用于W&M批准在PC硬盘上记录称重数据。IT CONFIGURATOR PC软件用于校准、备份、配置用户提示和编辑打印格式。以太网/互联网的RTC Web接口。o通过以太网接口电缆进行远程诊断，带RJ45连接器，5米（20英寸）或10米（40英寸）。防溅防尘罩透明塑料罩，保护显示器和键盘。桌面/墙壁版本面板安装版本结构：IT3–技术数据SysTec Systemtechnik und Industrieautomation GmbH电话：+49（0）2238-9663-0–www.systecnet。com如有更改，恕不另行通知ST.2309.1757 IT3_DBE。PDF.2017 04销售和服务指令：标准：EMI符合FCC第15部分2014/31/EU、2014/30/EU、2013/35/EU EN 45501、OIML R76-1、EN 61000-6-2、EN 61000-63、NAMUR NE21、EN 60950、OIML R61（待定）加拿大计量局：批准作为指示元件（待定）其他认证要求不锈钢外壳，IP69K适用于桌面或墙壁安装安装尺寸W x H x D：225 x 190 x 145 mm（“）8.9 x“x”7.5 5 7不锈钢外壳，面板防护等级IP65面板安装安装尺寸Wx H x D:216 x 156 x 61 mm（”）8.5 x“x.”6.1 2 4面板切口：199 x 139 mm（7.8“x 5.5”）Blackbox型不锈钢外壳，IP69K壁装安装尺寸W x H x D：221 x 171 x 62 mm（“）8.7 x.”x.“6 7 2 4 EC认证为非自动称重仪器EC认证为自动重量填充仪器（待定）NTEP认证为指示元件（待定）ETL认证符合UL 60950-1和CSA C22.2 No.60950-1（待定）
tablet or smartphone. One extension socket for: SIM-ETH3 module providing a second SIM socket. Fieldbus module for Profinet, Profibus DP or Ethernet/IP. Shift adjust board for 4 load cells (IT3-Blackbox only). One socket for digital inputs/outputs or analog output: 2 digital inputs and 2 digital outputs Optoisolated, 24 VDC, outputs for setpoint monitoring or simple filling applications, inputs for start of weighing and taring or start/stop of filling. Analog output 0 20 mA, 4 20 mA, 0 10 V or 2 10 V, 15 it, ––––b 32,000 divisions, for analog output of weight. Data storage Power-fail-safe storage of date and time. Application memory: BASIC: 9 selectable tare weights, COUNT: 9 reference weights, TRUCK: 99 first weights, FILL: 9 products. Further options Internal W&M approved data archive To record the latest 1,000,000 weighing results. Interface for two scale bases DADM to connect two s analog strain gauge scale with load cells. PC ScaleView PC software for the display of weighing data and scale status information (Parts Certificate pending). PC / PC COM+ ARCHIVE PC software for W&M approved recording of weighing data on a PC hard disk. IT CONFIGURATOR PC software for calibration, backup, configuration of user prompts, and editing of print formats. RTC Web Interface f r Ethernet-/Internet. o remote diagnostics via Ethernet interface cable With RJ45 connector, 5 m (20") or 10 m (40"). Splash and dust cover Transparent plastic cover to protect display and keyboard. Desk / wall version Panel-mount version Construction: IT3 – Technical Data SysTec Systemtechnik und Industrieautomation GmbH Tel. +49 (0) 2238 - 9663-0 – www.systecnet.com Subject to change without notice ST.2309.1757 IT3_DBE.PDF .2017 04 Sales and service Directives: Standards: EMI compliance with FCC Part 15 2014/31/EU, 2014/30/EU, 2014/35/EU EN 45501, OIML R76-1, EN 61000-6-2, EN 61000-6-3, NAMUR NE21, EN 60950, OIML R61 (pending) Mesures Canada: Approval as indicating element (pending) Other certificats on demand Stainless steel housing, IP69K Suitable for desk-top or wall-mount installation Dimensions W x H x D: 225 x 190 x 145 mm (" ) 8.9 x " x . " 7.5 5 7 Stainless steel housing, fascia plate protected to IP65 Panel-mount installation Dimensions W x H x D: 216 x 156 x 61 mm (" ) 8.5 x " x . " 6.1 2 4 Cut-out in panel: 199 x 139 mm (7.8" x 5.5") Blackbox version Stainless steel housing, IP69K Wall-mount installation Dimensions W x H x D: 221 x 171 x 62 mm (" ) 8.7 x . " x . " 6 7 2 4 EC approval as non-automatic weighing instrument EC approval as automatic gravimetric filling instrument (pending) NTEP approval as indicating element (pending) ETL certified in accordance with UL 60950-1 and CSA C22.2 No. 60950-1 (pending)
