最大mm 2 x（10 x 50）10 x 40 2 x（80 x 10）2 x（50 x 10）端子容量技术数据LZM…注1）已确定的额定电流In符合IEC/EN 60947（开关设备标准），通常与最大定义横截面相关，并用于定向。必须遵守适用于每种情况的工程标准。2） 取决于电缆制造商，最多可连接240mm2。3） 取决于电缆制造商，最多可连接95mm2。注1）已确定额定电流In符合IEC/EN 60947（开关设备标准），通常与最大定义横截面相关，并用于定向。必须遵守适用于每种情况的工程标准。2） 取决于电缆制造商，最多可连接240mm2。3） 取决于电缆制造商，最多可连接95mm2。59伊顿公司CA012002EN辅助触点技术数据M22-K…AC=50/60 Hz M22-K..NZM-CK…辅助触点额定工作电压AC Ue V AC 500 230 DC Ue V DC 220 220常规热电流Ith=Ie A 4 4额定工作电流AC–15 115 V Ie A 44 230 V Ie 4 4 400 V Ie A2–500 V I IN欠压脱扣器、分流器脱扣器技术数据NZM…-XU，NZM…-XA…NZM1（2/3）-XU…NZM4-XU…欠压释放额定控制电压50/60 Hz交流电压Us V AC 24…440 24…440 DC Us V DC 24 24工作范围压降x Us 0.35–0.7 0.35–0.7拾取电压x Us 0.85–1.1 0.85–1.1功耗AC拾取AC VA 1.5 3.6 DC拾取DC W 0.8 2.5密封DC W 0.8.5最大打开延迟ms 19 23（主电路断开前的响应时间）最小命令时间ms 10–15 10…15端子容量带金属箍的实心或柔性导体mm2 1 x（0.75…2.5）2 x（0.75..2.5）2 x（0.75…1.5）2 xDC 24 24频率范围Hz 0–400 0–400工作范围AC x Us 0.7…1.1 0.7…1.1 DC x Us 0.7.1.1 0.7……1.1功耗拾取AC/DC VA/W 2.5 2.5密封AC/DC VA/W 2.5 2.5最大打开延迟（响应时间至ms 20 22主电路打开）占空因数ms∝ ∝ 最小命令时间ms 10…15 10…15终端容量带金属箍的实心或柔性导体mm²21 x（0.75…2.5）1 x电压AC Us V AC 208…440 208…440 20…440 DC Us V DC 24 24 24工作范围AC Us 0.85…1.1 0.85…1.1 0.85…1.1 DC Us 0.85..1.1 0.85…1.10.85…1.1 0.8…1.1 1.1电机额定值AC 208…240 V AC VA 350 350 380…440 V AC VA 350350 350 DC 24…30 V DC W 250 250线圈额定功率AC 208…240V AC VA 270 270 270 380…440V AC VA 270270 DC 24…30V DC W 210 210总计闭合时间ms 60 80 100总打开延迟ms 300 1000 3000最小信号持续时间ms 30 30 30关闭ms 150 250 500寿命，机械操作-20000 15000 10000次最大操作频率Ops/h 120 60 20端子容量带套管的实心或柔性导体mm²0.75…2.5 0.75…2.5 0.75…2.5 AWG 18…14 18…14…14 63伊顿公司CA012002EN尺寸1：基本单元尺寸LZM1、LN1断路器3极LZMB1 LZMC1 LZMN1 LN1断路断路器4极LZMB1-4 LZMC1-4 LZMN1-4 LN1-4盖子
max. mm 2 x (10 x 50) 10 x 40 2 x (80 x 10) 2 x (50 x 10) Terminal capacities Technical data LZM... Notes 1) The rated currents In have been determined conform to IEC/EN 60947 (switchgear standard) and generally relate to the max. defined cross-sections and are intended for the purpose of orientation. The engineering standards which apply in each case must be observed. 2) depending on the cable manufacturer up to 240 mm2 can be connected. 3) depending on the cable manufacturer up to 95 mm2 can be connected. Notes 1) The rated currents In have been determined conform to IEC/EN 60947 (switchgear standard) and generally relate to the max. defined cross-sections and are intended for the purpose of orientation. The engineering standards which apply in each case must be observed. 2) depending on the cable manufacturer up to 240 mm2 can be connected. 3) depending on the cable manufacturer up to 95 mm2 can be connected. 59 EATON CORPORATION CA012002EN Auxiliary contacts Technical Data M22-K… at AC = 50/60 Hz M22-K… NZM-CK... Auxiliary contacts Rated operational voltage AC Ue V AC 500 230 DC Ue V DC 220 220 Conventional thermal current Ith = Ie A 4 4 Rated operational current AC–15 115 V Ie A 4 4 230 V Ie A 4 4 400 V Ie A 2 – 500 V I IN) a b c Time differences ON-OFF 61 EATON CORPORATION CA012002EN Undervoltage releases, shunt releases Technical Data NZM…-XU, NZM…-XA… NZM1(2/3)-XU... NZM4-XU… Undervoltage release Rated control voltage Alternating voltage at 50/60 Hz Us V AC 24…440 24…440 DC Us V DC 24 24 Operating range Drop-out voltage x Us 0.35 – 0.7 0.35 – 0.7 Pick-up voltage x Us 0.85 – 1.1 0.85 – 1.1 Power consumption AC Pick-up AC VA aling AC VA 1.5 3.6 DC Pick-up DC W 0.8 2.5 Sealing DC W 0.8 2.5 Max. opening delay ms 19 23 (response time until the main circuits open) Minimum command time ms 10 – 15 10 … 15 Terminal capacities Solid or flexible conductor with ferrule mm2 1 x (0.75 … 2.5) 2 x (0.75 … 2.5) 2 x (0.75 … 2.5) 2 x (0.75 … 2.5) AWG 1 x (18 … 14) 1 x (18 … 14) 2 x (18 … 14) 2 x (18 … 14) NZM1(2/3)-XA... NZM4-XA... Shunt release Rated control voltage AC Us V AC 24…440 24…440 DC Us V DC 24 24 Frequency range Hz 0 – 400 0 – 400 Operating range AC x Us 0.7…1.1 0.7…1.1 DC x Us 0.7…1.1 0.7…1.1 Power consumption Pick-up AC/DC VA/W 2.5 2.5 Sealing AC/DC VA/W 2.5 2.5 Max. opening delay (response time until ms 20 22 the mein circuits open) Duty factor ms ∝ ∝ Minimum command time ms 10 … 15 10 … 15 Terminal capacities Solid or flexible conductor with ferrule mm² 21 x (0.75 … 2.5) 1 x (0.75 … 2.5) 2 x (0.75 … 2.5) 2 x (0.75 … 2.5) AWG 1 x (18 … 14) 1 x (18 … 14) 2 x (18 … 14) 2 x (18 … 14) 62 EATON CORPORATION CA012002EN Remote operator Technical data NZM…-XR… NZM2-XR... NZM3-XR... NZM4-XR… Remote operator Rated control voltage AC Us V AC 208…440 208…440 208…440 DC Us V DC 24 24 24 Operating range AC Us 0.85…1.1 0.85…1.1 0.85…1.1 DC Us 0.85…1.1 0.85…1.1 0.85…1.1 Motor rating AC 208 … 240 V AC VA 350 350 350 380 … 440 V AC VA 350 350 350 DC 24 … 30 V DC W 250 250 250 Rated power of coil AC 208 … 240 V AC VA 270 270 270 380 … 440 V AC VA 270 270 270 DC 24 … 30 V DC W 210 210 210 Total make time ms 60 80 100 Total opening delay ms 300 1000 3000 Minimum signal duration with switch on ms 30 30 30 with switch off ms 150 250 500 Lifespan, mechanical Opera- 20000 15000 10000 tions Maximum operating frequency Ops./h 120 60 20 Terminal capacities Solid or flexible conductor with ferrule mm² 0.75 … 2.5 0.75 … 2.5 0.75 … 2.5 AWG 18 … 14 18 … 14 18 … 14 63 EATON CORPORATION CA012002EN Size 1: basic units Dimensions LZM1, LN1 Circuit-breaker 3 pole LZMB1 LZMC1 LZMN1 LN1 Circuit-breaker 4 pole LZMB1-4 LZMC1-4 LZMN1-4 LN1-4 Covers
