PFCL301E 0.5KN 3BSE016580R500 DCS工控模块备件
应用。适用于所有2“、3”、4“和5”工业温度计和LT-225/LT-225R。建议在最低-50°F（-45°C）至最高500°F（260°C）的工艺温度范围内使用硅填充温度计。如果存在强氧化剂，如氧气、氯气、硝酸和过氧化氢，则应避免使用硅酮填料。应用：堆肥/料堆测试土壤/沥青测试肉类加工蘑菇种植可用于1/2“NPT连接。杆直径.250”或.375“（推荐）。杆直径.375”和.250可提供锥形杆。重型温度计符合3A标准编号74-06 Tri-Clamp®卫生配件是温度计的组成部分，由316L SS润湿部件和304SS非接触部件构成。配置包括背面连接、底部连接和可调角度型号，具有各种刻度盘尺寸和阀杆长度，根据ASME B40.3进行密封，非常适合乳品加工g行业，以及食品和饮料加工和制药行业。有关更多规格，请访问www.teltru.com/s-59-sanitary-bimetal.aspx Tri-Clamp是Tri-Clover，Inc.的注册商标。卫生双金属温度计特殊应用温度计5“可调角度或背面连接发光表盘是发光涂层铝铝反光指针。两个304SS反光夹卡在表盘边缘。您可以决定每个反光夹的设置位置，可以指定最小和最大限制，这允许现场定制发光表盘，AD-10R和AD-44R型号（无夹）这种非常简单的解决方案允许任何人在白天近距离或夜晚远距离观察温度计，以轻松地查看过程是否在指定的安全区域内运行。在低光条件下，可以从远处读取温度计；你只需要一个手电筒！发光表盘和反射温度计量程°/分度。代码0/250°F 0/300°F 0/500°F 20/240°F 50/300°F 50/400°F 50/500°F 50/550°F 150/750°F 200/1000°F-50/120°F，-45/50°C-40/160°F、-40/70°C 0/250°C、-20/120°C 50/500°F、0/250°A 0/100°C 0/150°C 0/200°C 0/25°C 2°5°2°5 5°5°5 10°2°1°2°、2°5°，2°1°1°2°67 57 58 59 62 63 64 68 65 25 02 14 09 76 77 79第24页UT-500背面连接，型号代码621T UT-575可调角度，型号代码641T 5“GLOW DIAL RANGES PT-50R辉光表盘选项，带1”表盘。尺寸和范围见第19页。尺寸见第9页（UT-575）或第11页（UT-500）。欲了解更多规格，请访问www.teltru.com/s-16-glow-dial-reflective.aspx MINIMUM AND MAXIMUM THERMETERS（最低和最高温度计）。用户可以轻松设置红色和/或蓝色懒人指针，以便显示工艺达到的最低和/或最高温度。MM型号表示最大值和最小值。MX型号仅表示最大值或最小值。直径3“或直径5”。与重新校准功能反向连接。MM-525R（带5英寸表盘）MX-325R（带3英寸表盘）特殊
applications. Available on all 2", 3", 4" and 5" industrial thermometers and LT-225/LT-225R. Silicone filled thermometers are recommended for use with process temperatures ranging from a minimum of -50°F (-45°C) to a maximum of 500°F (260°C). Use of silicone fill should be avoided where strong oxidizing agents such as oxygen, chlorine, nitric acid, and hydrogen peroxide are present. APPLICATIONS: Compost/Windrow Testing Soil/Asphalt Testing Meat Processing Mushroom Growing Can be used with 1/2" NPT connection. Stem diameter .250" or .375" (recommended). Stem diameter .375" with .250" tapered rod available. Heavy duty thermometers meet 3A Standard Number 74-06 Tri-Clamp® sanitary fittings are integral to the thermometers Constructed of 316L SS wetted parts and 304SS non-contact parts Configurations include back connected, bottom connected, and adjustable angle models in a variety of dial sizes and stem lengths Hermetically sealed per ASME B40.3 Ideal for the dairy processing industry, as well as food and beverage processing and pharmaceutical industries For additional specifications, go to www.teltru.com/s-59-sanitary-bimetal.aspx Tri-Clamp is a registered trademark of Tri-Clover, Inc. SANITARY BIMETAL THERMOMETERS Special Application Thermometers 5" Adjustable Angle or Back Connect Glow dial is luminescent coated aluminum Aluminum Reflective Pointer Two 304SS Reflective Clips snap onto the dial rim. You decide where you want to set each reflective clip--minimum and maximum limits can be indicated, which allows for on the spot customization Glow dials also available on models AD-10R and AD-44R (without clips) This remarkably easy solution permits anyone viewing the thermometer, up close in the light of day or far away at night, to easily see if the process is operating within a designated safe zone. The thermometer can be read from a distance in low light conditions; all you need is a flashlight! GLOW DIAL AND REFLECTIVE THERMOMETERS Range °/Div. Code 0/250°F 0/300°F 0/500°F 20/240°F 50/300°F 50/400°F 50/500°F 50/550°F 150/750°F 200/1000°F -50/120°F, -45/50°C -40/160°F, -40/70°C 0/250°F, -20/120°C 50/500°F, 0/250°C 0/100°C 0/150°C 0/200°C 0/250°C 2° 5° 5° 2° 2° 5° 5° 5° 10° 10° 2°, 1° 2°, 1° 2°, 2° 5°, 2° 1° 1° 2° 2° 67 57 58 59 62 63 64 68 65 66 25 02 14 09 76 77 78 79 Page 24 UT-500 Back Connect, Model Code 621T UT-575 Adjustable Angle, Model Code 641T 5" GLOW DIAL RANGES PT-50R Glow dial option, with 1" dial For dimensions and ranges, see page 19. For dimensions, see page 9 (UT-575) or page 11 (UT-500). For additional specifications, go to www.teltru.com/s-16-glow-dial-reflective.aspx MINIMUM AND MAXIMUM THERMOMETERS User can easily set red and/or blue lazy hands so that minimum and/or maximum temperatures reached by a process will be indicated. MM models indicate both maximum AND minimum. MX models indicate maximum OR minimum only. 3" dia. or 5" dia. back connected with recalibration feature. MM-525R (With 5" dial) MX-325R (With 3" dial) Special
