PFTL 201CE-20.0处理器模块
带护套的压接连接器，数量=50件0.128…0.205 mm2（26…24 AWG，Cat.5e，需要用于装配的压接工具1585A Jcrimp压接工具-9300-RADES远程访问拨入套件56 Kbps调制解调器连接到以太网网络上的设备，包括：预配置的调制解调器通信模块DIN导轨安装硬件相关电缆如果您的应用程序选择需要第3层布线集成企业和制造环境管理多播传输ic需要诊断数据需要安全选项Stratix 8300模块化、托管交换机集成企业和制造环境管理多播流量需要诊断数据要求安全选项Stradix 8000模块化、管理交换机集成车间设备管理多播流量需要诊断数据需要安全选项Straix 6000固定、，受管交换机需要轻松设置和直接更换交换机，隔离网络Stratix 2000非托管交换机8罗克韦尔自动化出版物1769-TD007D-EN-P-2014年5月CompactLogix通信模块规范Stratix托管交换机规范Stratix非托管交换机规范Stratix 8000和8300 Stratix 6000 Base Base Base Base Expansion Feature 1783-MS06T 1783-RMS06T 1783-MS10T 1783-RM S10T 1783-MX08T 1783-MX 08F1783-EMS04T 1783-EMSO8T每个模块的端口6 10 8 4 9第3层路由否是否否否否端口总数，最多可达26（1）（1）个最大端口数需要扩展端口光纤端口0…10（1）-1 10/100铜质端口4…24（1）4 8 100基本LC光纤端口0..8（1）SFP插槽2（2）（2）每个端口可用于SFP或10/100/1000铜质端口。-1 10/100/1000铜质端口2（2）--100 Mbs光纤支持是否否1 G光纤支持是不是CompactFlash内存是否否电源要求24/48V DC 8…48V DC Stratix 2000功能1783-US03T01F 1783-US05T 1783-US06T01F 783-US08T每个模块4 5 7 8光纤端口1-1-10/100铜质端口3 5 6 8 100基本LC光纤端口1-1-100 Mb光纤支持是-是-CompactFlash存储器无无无电源要求810…35V DC罗克韦尔自动化出版物1769-TD007D-EN-P-2014年5月9 CompactLogix通信模块规范ControlNet网络ControlNet网络是一个开放的控制网络，用于实时、高吞吐量应用。ControlNet网络使用通用工业协议（CIP）将I/O网络和对等网络的功能结合起来，为这两种功能提供高速性能。除了支持非时间关键数据的传输外，ControlNet网络还为您提供所有任务关键控制数据的确定性、可重复传输。I/O更新和控制器到控制器的联锁始终优先于程序上传、下载和消息传递。有关控制器规格，请参阅CompactLogix控制器规格，出版物1769-TD005。通过ControlNet网络连接到其他设备RSLogix 5000企业系列软件支持通用ControlNet模块，该模块允许连接到当前编程软件中没有特定支持的ControlNet节点。配置为通用ControlNet模块的模块以输入、输出、状态和配置标签的形式与控制器通信。例如，使用通用模块配置在控制器和1203-CN1 ControlNet通信模块之间建立通信。然后使用CIP通用MSG指令类型发送和接收来自1203-CN1模块的消息。如果您的应用程序对1769-L3x控制器使用Select对1769-L4x使用Select，1769-L4xS控制器带集成ControlNet端口1768-CNB桥的单介质1769-L32C控制器带集成Control Net端口1768-CNBR桥的冗余介质1769-L3 5CR控制器10罗克韦尔自动化出版物1769-TD007D-EN-P-2014年5月CompactLogix通信模块规格表5-技术规格-1768 ControlNet模块属性1768-CNB1768-CNBR配置标准冗余ControlNet通信速率5 Mbps Logix通信连接48节点数量，最大99电流消耗@5.2V DC 1 A电流消耗@24V DC 0 A功耗5.14 W散热17.5 BTU/hr隔离电压30V（连续），功能绝缘型，ControlNet到背板NAP和背板之间无隔离型，在500V AC下测试60秒，ControlNet网络至系统重量，约。
crimp connector with boot, qty = 50 pieces 0.128...0.205 mm2 (26…24 AWG, Cat. 5e, requires crimp tool for assembly 1585A-Jcrimp Crimp tool — 9300-RADES Remote access dial-in kit 56 Kbps modem connection to devices on an Ethernet network, includes:Pre-configured modemCommunication moduleDIN rail mounting hardwareAssociated cables If your application SelectRequires Layer 3 routingIntegrates enterprise and manufacturing environmentsManages multicast trafficRequires diagnostics dataRequires security options Stratix 8300 modular, managed switchIntegrates enterprise and manufacturing environmentsManages multicast trafficRequires diagnostics dataRequires security options Stratix 8000 modular, managed switchIntegrates plant floor devicesManages multicast trafficRequires diagnostics dataRequires security options Stratix 6000 fixed, managed switchRequires easy set up and direct replacement of switchesIs a small, isolated network Stratix 2000 unmanaged switch 8 Rockwell Automation Publication 1769-TD007D-EN-P - May 2014 CompactLogix Communication Modules Specifications Stratix Managed Switch Specifications Stratix Unmanaged Switch Specifications Stratix 8000 and 8300 Stratix 6000 Base Base Base Base Expansion Expansion Feature 1783-MS06T 1783-RMS06T 1783-MS10T 1783-RMS10T 1783-MX08T 1783-MX08F 1783-EMS04T 1783-EMS08T Ports per module 6 10 8 4 9 Layer 3 routing No Yes No Yes No No No No Total ports, max Up to 26(1) (1) Maximum port counts require expansion ports. — — Fiber ports 0...10(1) — 1 10/100 copper ports 4...24(1) 4 8 100 base LC fiber ports 0...8(1) SFP slots 2 (2) (2) Two ports each can be used for SFP or 10/100/1000 copper. — 1 10/100/1000 copper ports 2 (2) — — 100 Mbs fiber support Yes No No 1 G fiber support Yes No Yes CompactFlash memory Yes No No Power requirements 24/48V DC 8...48V DC Stratix 2000 Feature 1783-US03T01F 1783-US05T 1783-US06T01F 1783-US08T Ports per module 4 5 7 8 Fiber ports 1 — 1 — 10/100 copper ports 3 5 6 8 100 base LC fiber ports 1 — 1 — 100 Mbs fiber support Yes — Yes — CompactFlash memory No No No No Power requirements 810...35V DC Rockwell Automation Publication 1769-TD007D-EN-P - May 2014 9 CompactLogix Communication Modules Specifications ControlNet Network The ControlNet network is an open, control network for real-time, high-throughput applications. The ControlNet network uses the Common Industrial Protocol (CIP) to combine the functionality of an I/O network and a peer-to-peer network providing high-speed performance for both functions. The ControlNet network gives you deterministic, repeatable transfers of all mission-critical control data in addition to supporting transfers of non-time-critical data. I/O updates and controller-to-controller interlocking always take precedence over program uploads and downloads and messaging. For controller specifications, see CompactLogix Controllers Specifications, publication 1769-TD005. Connect to Other Devices via a ControlNet Network The RSLogix 5000 Enterprise Series software supports a generic ControlNet module that allows connections to ControlNet nodes for which there is no specific support currently available in the programming software. A module configured as a generic ControlNet module communicates with the controller in the form of input, output, status, and configuration tags. For example, use the generic module configuration to set up communication between a controller and a 1203-CN1 ControlNet communication module. Then use the CIP generic MSG instruction type to send and receive messages from the 1203-CN1 module. If your application uses Select for a 1769-L3x controller Select for a 1769-L4x, 1769-L4xS controllerSingle media 1769-L32C controller with integrated ControlNet port 1768-CNB bridgeRedundant media 1769-L35CR controller with integrated ControlNet port 1768-CNBR bridge 10 Rockwell Automation Publication 1769-TD007D-EN-P - May 2014 CompactLogix Communication Modules Specifications Table 5 - Technical Specifications - 1768 ControlNet Modules Attribute 1768-CNB 1768-CNBR Configuration Standard Redundant ControlNet communication rate 5 Mbps Logix communication connections 48 Number of nodes, max 99 Current draw @ 5.2V DC 1 A Current draw @ 24V DC 0 A Power dissipation 5.14 W Thermal dissipation 17.5 BTU/hr Isolation voltage 30V (continuous), functional insulation type, ControlNet to backplane No isolation between NAP and Backplane Type tested at 500V AC for 60 s, ControlNet network to system Weight, approx.
