PFTL 301E-0.1模拟量输入模块
Mbs光纤支持是否否1 G光纤支持是不是是CompactFlash存储器是否否电源要求24/48V DC 8…48V DC Stratix 2000功能1783-US03T01F 1783-US05T 1783-US06T01F 783-US08T每个模块的端口4 5 7 8光纤端口1-1-10/100铜质端口3 5 6 8 100基本LC光纤端口1-1-100 Mb光纤支持是-是-CompactFlash内存否否无电源要求810…35V DC罗克韦尔自动化出版物1769-TD007D-EN-P-2014年5月9 CompactLogix通信模块规范ControlNet网络ControlNet网络是用于实时、高通量应用的开放式控制网络。ControlNet网络使用通用工业协议（CIP）将I/O网络和对等网络的功能结合起来，为这两种功能提供高速性能。除了支持非时间关键数据的传输外，ControlNet网络还为您提供所有任务关键控制数据的确定性、可重复传输。I/O更新和控制器到控制器的联锁始终优先于程序上传、下载和消息传递。有关控制器规范，请参阅CompactLogix控制器规范，出版物1769-TD005。DeviceNet网络使用经验证的通用工业协议（CIP）为工业设备提供控制、配置和数据采集功能。如果您的应用程序选择与其他DeviceNet设备（I/O和消息）通信需要显式消息使用控制器作为主机或从机使用控制器串行端口进行其他通信需要比1769-NET-DNI接口1769-SDN DeviceNet扫描仪更高的性能使用任何CompactLogix控制器访问多达30个远程Compact I/O模块发送远程I/O数据返回到扫描仪或控制器1769 DeviceNet适配器表7-技术规范-1769 DeviceNet模块属性1769-SDN（1）（1）1769-SDN不支持CIP安全（安全通信）。1769-ADN DeviceNet通信速率125 Kbps（500 m max）250 Kbps（250 m max）500 Kbps（100 m max）节点数量，最大64 30电流汲取@5V DC 440 mA A系列450 mA B系列500 mA电流汲取@24V DC 0 mA DeviceNet电流范围11…25V DC DeviceNet电流汲取110 mA@24V DC Class 2/SELV 90 mA@24V直流Class 2/SELV功耗4.7 W 4.7 W隔离电压30V（连续），基本绝缘类型，DeviceNet至背板类型，在710V DC下测试60 s重量，约0.280 kg（0.61 lb）尺寸（HxWxD），约118 x 50 x 87 mm（4.65 x 1.97 x 3.43 in.）插槽宽度1模块位置DIN
Mbs fiber support Yes No No 1 G fiber support Yes No Yes CompactFlash memory Yes No No Power requirements 24/48V DC 8...48V DC Stratix 2000 Feature 1783-US03T01F 1783-US05T 1783-US06T01F 1783-US08T Ports per module 4 5 7 8 Fiber ports 1 — 1 — 10/100 copper ports 3 5 6 8 100 base LC fiber ports 1 — 1 — 100 Mbs fiber support Yes — Yes — CompactFlash memory No No No No Power requirements 810...35V DC Rockwell Automation Publication 1769-TD007D-EN-P - May 2014 9 CompactLogix Communication Modules Specifications ControlNet Network The ControlNet network is an open, control network for real-time, high-throughput applications. The ControlNet network uses the Common Industrial Protocol (CIP) to combine the functionality of an I/O network and a peer-to-peer network providing high-speed performance for both functions. The ControlNet network gives you deterministic, repeatable transfers of all mission-critical control data in addition to supporting transfers of non-time-critical data. I/O updates and controller-to-controller interlocking always take precedence over program uploads and downloads and messaging. For controller specifications, see CompactLogix Controllers Specifications, publication 1769-TD005. The DeviceNet network uses the proven Common Industrial Protocol (CIP) to provide the control, configure, and data collection capabilities for industrial devices. If your application SelectCommunicates with other DeviceNet devices (I/O and messages)Requires explicit messagingUses the controller as a master or slaveUses the controller serial port for other communicationRequires higher performance than the 1769-NET-DNI interface 1769-SDN DeviceNet scannerUses any CompactLogix controllerAccesses as many as 30 remote Compact I/O modulesSends remote I/O data back to a scanner or controller 1769 DeviceNet adapter Table 7 - Technical Specifications - 1769 DeviceNet Modules Attribute 1769-SDN(1) (1) The 1769-SDN does not support CIP Safety (safety communication). 1769-ADN DeviceNet communication rate 125 Kbps (500 m max) 250 Kbps (250 m max) 500 Kbps (100 m max) Number of nodes, max 64 30 Current draw @ 5V DC 440 mA Series A 450 mA Series B 500 mA Current draw @ 24V DC 0 mA DeviceNet current range 11…25V DC DeviceNet current draw 110 mA @ 24V DC Class 2/SELV 90 mA @ 24V DC Class 2/SELV Power dissipation 4.7 W 4.7 W Isolation voltage 30V (continuous), basic insulation type, DeviceNet to backplane Type tested at 710V DC for 60 s Weight, approx. 0.280 kg (0.61 lb) Dimensions (HxWxD), approx. 118 x 50 x 87 mm (4.65 x 1.97 x 3.43 in.) Slot width 1 Module location DIN
