PFTL 301E-1.0系统模块卡件
，工业要求EN 61000-6-2；工业抗扰度EN 61000-6-4；工业排放EN 61131-2；可编程控制器（第8条，A区和B区）RCM澳大利亚无线电通信法，符合AS/NZS CISPR 11；工业排放澳大利亚无线电通信法，符合AS/NZS CISPR 11；工业排放Ex EU 94/9/EC ATEX指令，符合：EN 60079-15；潜在爆炸性环境，防护“n”EN 60079-0；一般要求II 3 G Ex nA IIC T4 X N/A KC韩国广播和通信设备注册，符合：《无线电波法》第58-2条，第3条韩国广播和通讯设备注册，遵守：《无线波法》第585-2条，第3条根据EtherNet/IP规范测试的EtherNet/IP ODVA符合性根据EtherNet/IP规范进行的ODVA符合测试（1）标记时。请参阅产品认证链接http://www.ab.com符合性声明、证书和其他认证详情。罗克韦尔自动化出版物1769-TD007D-EN-P-2014年5月7 CompactLogix通信模块规格附件-以太网网络Stratix交换机为了有效管理整个制造业和IT企业的实时控制和信息流，罗克韦尔自动化提供了全套工业以太网交换机和介质，包括一系列与Cisco技术集成的Stratix交换机。Stratix系列交换机包括模块化管理交换机、固定管理交换机和非管理交换机。猫编号说明规格1585J-M8PBJM-x以太网RJ45跳线x=2（2 m）、5（5 m）或10（10 m）8芯、柚木立管PVC电缆（也可使用挠性电缆）1585J-M8 CC-H RJ45绝缘位移连接器（IDC）0.128…0.325 mm2（26…22 AWG），类别。6，IDC，无需工具1585J-M8CC-C RJ45压接连接器，带护套，数量=50件0.128…0.205 mm2（26…24 AWG，Cat.5e，需要用于装配的压接工具1585A Jcrimp压接工具-9300-RADES远程访问拨入套件56 Kbps调制解调器连接到以太网网络上的设备，包括：预配置的调制解调器通信模块DIN导轨安装硬件相关电缆如果您的应用程序选择需要第3层布线集成企业和制造环境管理多播传输ic需要诊断数据需要安全选项Stratix 8300模块化、托管交换机集成企业和制造环境管理多播流量需要诊断数据要求安全选项Stradix 8000模块化、管理交换机集成车间设备管理多播流量需要诊断数据需要安全选项Straix 6000固定、，受管交换机需要轻松设置和直接更换交换机，隔离网络Stratix 2000非托管交换机8罗克韦尔自动化出版物1769-TD007D-EN-P-2014年5月CompactLogix通信模块规范Stratix托管交换机规范Stratix非托管交换机规范Stratix 8000和8300 Stratix 6000 Base Base Base Base Expansion Feature 1783-MS06T 1783-RMS06T 1783-MS10T 1783-RM S10T 1783-MX08T 1783-MX 08F1783-EMS04T 1783-EMSO8T每个模块的端口6 10 8 4 9第3层路由否是否否否否端口总数，最多可达26（1）（1）个最大端口数需要扩展端口光纤端口0…10（1）-1 10/100铜质端口4…24（1）4 8 100基本LC光纤端口0..8（1）SFP插槽2（2）（2）每个端口可用于SFP或10/100/1000铜质端口。-1 10/100/1000铜端口2（2）
, Industrial Requirements EN 61000-6-2; Industrial Immunity EN 61000-6-4; Industrial Emissions EN 61131-2; Programmable Controllers (Clause 8, Zone A & B) RCM Australian Radiocommunications Act, compliant with: AS/NZS CISPR 11; Industrial Emissions Australian Radiocommunications Act, compliant with: AS/NZS CISPR 11; Industrial Emissions Ex European Union 94/9/EC ATEX Directive, compliant with: EN 60079-15; Potentially Explosive Atmospheres, Protection "n" EN 60079-0; General Requirements II 3 G Ex nA IIC T4 X N/A KC Korean Registration of Broadcasting and Communications Equipment, compliant with: Article 58-2 of Radio Waves Act, Clause 3 Korean Registration of Broadcasting and Communications Equipment, compliant with: Article 58-2 of Radio Waves Act, Clause 3 EtherNet/IP ODVA conformance tested to EtherNet/IP specifications ODVA conformance tested to EtherNet/IP specifications (1) When marked. See the Product Certification link at http://www.ab.com for Declarations of Conformity, Certificates, and other certification details. Rockwell Automation Publication 1769-TD007D-EN-P - May 2014 7 CompactLogix Communication Modules Specifications Accessories - Ethernet Network Stratix Switches To effectively manage real-time control and information flow throughout the manufacturing and IT enterprise, Rockwell Automation offers a full portfolio of industrial Ethernet switches and media, including a line of Stratix switches integrated with Cisco technology. The Stratix line of switches includes modular managed, fixed managed, and unmanaged switches. Cat. No. Description Specifications 1585J-M8PBJM-x Ethernet RJ45 patchcord x = 2 (2 m), 5 (5 m), or 10 (10 m) 8-conductor, teal riser PVC cable (flex rated cable also available) 1585J-M8CC-H RJ45 insulation displacement connector (IDC) 0.128...0.325 mm2 (26…22 AWG), Cat. 6, IDC, no tool required 1585J-M8CC-C RJ45 crimp connector with boot, qty = 50 pieces 0.128...0.205 mm2 (26…24 AWG, Cat. 5e, requires crimp tool for assembly 1585A-Jcrimp Crimp tool — 9300-RADES Remote access dial-in kit 56 Kbps modem connection to devices on an Ethernet network, includes:Pre-configured modemCommunication moduleDIN rail mounting hardwareAssociated cables If your application SelectRequires Layer 3 routingIntegrates enterprise and manufacturing environmentsManages multicast trafficRequires diagnostics dataRequires security options Stratix 8300 modular, managed switchIntegrates enterprise and manufacturing environmentsManages multicast trafficRequires diagnostics dataRequires security options Stratix 8000 modular, managed switchIntegrates plant floor devicesManages multicast trafficRequires diagnostics dataRequires security options Stratix 6000 fixed, managed switchRequires easy set up and direct replacement of switchesIs a small, isolated network Stratix 2000 unmanaged switch 8 Rockwell Automation Publication 1769-TD007D-EN-P - May 2014 CompactLogix Communication Modules Specifications Stratix Managed Switch Specifications Stratix Unmanaged Switch Specifications Stratix 8000 and 8300 Stratix 6000 Base Base Base Base Expansion Expansion Feature 1783-MS06T 1783-RMS06T 1783-MS10T 1783-RMS10T 1783-MX08T 1783-MX08F 1783-EMS04T 1783-EMS08T Ports per module 6 10 8 4 9 Layer 3 routing No Yes No Yes No No No No Total ports, max Up to 26(1) (1) Maximum port counts require expansion ports. — — Fiber ports 0...10(1) — 1 10/100 copper ports 4...24(1) 4 8 100 base LC fiber ports 0...8(1) SFP slots 2 (2) (2) Two ports each can be used for SFP or 10/100/1000 copper. — 1 10/100/1000 copper ports 2 (2)
