PFTL101A-0.5KN 3BSE004166R1工控模块备件
公告280E/281E、284E ArmorStart®分布式电机控制器产品概述产品线描述功能压盖板入口ArmorStart产品提供了两种不同的方法，用于将输入的三相和控制电源连接到设备。提供的一种方法是传统的导管入口，其提供3/4和1英寸。用于三相接线和控制电源的导管孔开口。第二种方法提供与ArmorConnect电源介质的连接。工厂安装的插座用于连接三相和控制电源介质。LED状态指示LED状态指示提供四个状态LED和一个重置按钮。LED提供以下状态指示：电源LED运行LED网络LED故障LED重置按钮这用作本地跳闸重置。电机电缆每个ArmorStart分布式电机控制器都配有一个3米非屏蔽的4芯线组。操作模式公告280或281全电压/反向起动器此方法用于需要跨线起动的应用。ArmorStart公告280提供全电压启动，公告281提供反转应用的全电压启动。公告284变频驱动无传感器矢量控制（SVC）无传感器矢量控制器在整个驱动速度范围内提供卓越的速度调节和极高的扭矩水平。优化性能：可拆卸MOV在不接地配电系统上使用时提供无故障运行。继电器预充电限制涌入电流。集成制动晶体管使用低成本的IP20制动电阻器或IP67即插即用电阻器提供动态制动能力。150%过载60秒或200%过载3秒，提供强大的过载保护。可调PWM频率高达16 kHz，确保安静运行。出版物280E-SG001B-EN-P ArmorStart分布式电机控制器是一种用于机器应用的集成、预先设计的电机起动器解决方案。ArmorStart作为标准提供了坚固的IP67/NEMA 4型外壳设计，适用于水冲洗环境。其模块化设计为I/O、通信和电机连接提供了快速断开连接的简单接线。可选的快速断开控制和三相电源，完全集成了即插即用解决方案。作为标准，ArmorStart提供四个输入和两个输出，用于传感器和执行器。ArmorStart分布式电机控制器通过结合Bulletin 140M手动电机保护器，作为标准提供了一种就地电机断开装置。这消除了在每个电机分支电路中需要的额外部件的需要。ArmorStart分布式电机控制器被列为适用于集团电机安装。
Bulletin 280E/281E, 284E ArmorStart® Distributed Motor Controller Product Overview Product Line Description Features Gland Plate Entrance The ArmorStart product offers two different methods for connecting incoming three-phase and control power to the device. One method offered is the traditional conduit entrance which provides a 3/4 and 1 in. conduit hole opening for wiring three-phase and control power. The second method offers connectivity to the ArmorConnect power media. Factory installed receptacles are provided for connectivity to both three-phase and control power media. LED Status Indication The LED Status Indication provides four status LEDs and a Reset button. The LEDs provide status indication for the following: POWER LED RUN LED NETWORK LED FAULT LED Reset Button This is used as a local trip reset. Motor Cable A 3-meter unshielded, 4-conductor cordset is provided with every ArmorStart Distributed Motor Controller. Modes of Operation Bulletin 280 or 281 Full Voltage/Reversing Starter This method is used in applications requiring across-the-line starting. The ArmorStart Bulletin 280 offers full-voltage starting, and the Bulletin 281 offers full-voltage starting for reversing applications. Bulletin 284 Variable Frequency Drive Sensorless Vector Control (SVC) Sensorless vector control provides exceptional speed regulation and very high levels of torque across the entire speed range of the drive. Optimized Performance: Removable MOV provides trouble-free operation when used on ungrounded distribution systems. A relay pre-charge limits inrush current. Integral brake transistor provides dynamic braking capability using low cost IP20 brake resistors or IP67 plug and play resistors. 150% overload for 60 seconds or 200% overload for 3 seconds provides robust overload protection. Adjustable PWM frequency up to 16 kHz ensures quiet operation. Publication 280E-SG001B-EN-P The ArmorStart Distributed Motor Controller is an integrated, preengineered, motor starter solution for On-Machine applications. The ArmorStart offers as standard, a robust IP67/NEMA Type 4 enclosure design, which is suitable for water wash-down environments. Its modular design offers simplicity in wiring using quick disconnects for the I/O, communications, and motor connection. Optional quick disconnects for control and three-phase power, fully integrates the plug-n-play solution. As standard, the ArmorStart offers four inputs and two outputs to be used with sensors and actuators. The ArmorStart Distributed Motor Controller offers as standard, a local at-motor disconnect means by incorporating the Bulletin 140M Manual Motor Protector. This eliminates the need for additional components that would otherwise be required in each motor branch circuit. The ArmorStart Distributed Motor Controllers are listed as suitable for Group Motor installations.
