PFTL101A-1.0KN 3BSE004166R1模拟量输入模块
11出版物1326-IN030A-EN-P-2007年5月安装说明1326特殊应用电缆目录号1326-CPB1T-L、1326-CPC1T-L关于本出版物本文件包含带有飞线的电缆的安装信息。飞线允许客户确定电缆终端的类型。本表列出了可用的1326根特殊应用电缆及其废弃电缆。此电缆取代此电缆。1326-CPB1T-L-xxx 1326-CPB1-xxx、1326-CPB 1-L-xxx、1326-CPR1T-xxx 1326-CPC1T-L-xxx、132 6-CPC1-xxx、132 6-CPR1-L-xxx注意：输入电源断开后，驱动器上的直流母线电容器会保持危险电压。在开始对任何驱动系统的输出电源电缆进行操作之前，测量驱动上的总线电压，以验证其是否已达到安全水平，或等待驱动前部警告中所示的整个时间间隔。不遵守此预防措施可能导致严重的人身伤害或生命损失。重要事项不要将电源线缠绕在其上。紧密缠绕的电力电缆中可能会积聚热量，并可能导致电缆绝缘退化。出版物1326-IN030A-EN-P-2007年5月2 1326特殊应用电缆电缆布线连接器布线引脚和图表为这些电缆提供。1326-CPB1T-L-xxx接线本表提供了1326-CPB1 T-DEL-xxx电缆的接线信息。1326-CPB1T-L-xxx电缆接线图线号信号线色规mm2（AWG）1326-CPB1 T-DE连接器母触点1电源黑1.29（16）1 2电源黑1.22（16）2 3电源黑1.23（16）4 4电源黑1.24（16）5电源黑1.25（16）7 8 GND）绿色/黄色1.29（17）8 9恒温器黑色1.29（18）9总屏蔽编织N/A连接到外壳电线#1导线#2导线#3导线#4导线#5导线#6绿色/黄色导线#9屏蔽1 2 3 4 5 6 8 9 7连接器引脚出版物1326-IN030A-EN-P-2007年5月1326特殊应用电缆3 1326-CPC1T-L-xxx接线本表提供了1326-CPC2T-EL-xxx电缆的接线信息。1326-CPC1T-EL-xxx电缆接线图线号信号线
Publication 1326-IN030A-EN-P - May 2007 Installation Instructions 1326 Special Application Cables Catalog Numbers 1326-CPB1T-L, 1326-CPC1T-L About This Publication This document contains installation information for cables that have flying leads. The flying leads allow the customer to determine the type of cable terminations. This table lists available 1326 special application cables and the cables they obsolete. This cable replaces this cable. 1326-CPB1T-L-xxx 1326-CPB1-xxx, 1326-CPB1-L-xxx, 1326-CPB1T-xxx 1326-CPC1T-L-xxx 1326-CPC1-xxx, 1326-CPC1-L-xxx, 1326-CPC1T-xxx ATTENTION DC bus capacitors on a drive retain hazardous voltages after input power has been removed. Before beginning work on the output power cable from any drive system, measure the bus voltage at the drive to verify it has reached a safe level or wait the full time interval as indicated in the warning on the front of the drive. Failure to observe this precaution could result in severe bodily injury or loss of life. IMPORTANT Do not coil a power cable on itself. Heat may buildup in a closely coiled power cable and degradation of the cable insulation may result. Publication 1326-IN030A-EN-P - May 2007 2 1326 Special Application Cables Cable Wiring Connector wiring pinouts and diagrams are provided for these cables. 1326-CPB1T-L-xxx Wiring This table provides wiring information for the 1326-CPB1T-DEL-xxx cables. 1326-CPB1T-L-xxx Cable Wiring Diagram Wire Number Signal Wire Color Gauge mm2 (AWG) 1326-CPB1T-DE Connector Female Contact 1 Power Black 1.29 (16) 1 2 Power Black 1.29 (16) 2 3 Power Black 1.29 (16) 3 4 Power Black 1.29 (16) 4 5 Power Black 1.29 (16) 5 Overall shield Shield 1.29 (16) 7 8 GND) Green/Yellow 1.29 (16) 8 9 Thermostat Black 1.29 (16) 9 Overall shield Braid N/A Connected to shell Wire #1 Wire #2 Wire #3 Wire #4 Wire #5 Wire #6 Green/Yellow Wire#9 Shield 1 2 3 4 5 6 8 9 7 Connector Pin Publication 1326-IN030A-EN-P - May 2007 1326 Special Application Cables 3 1326-CPC1T-L-xxx Wiring This table provides wiring information for the 1326-CPC1T-EL-xxx cable. 1326-CPC1T-EL-xxx Cable Wiring Diagram Wire Number Signal Wire
