40.4（1.59）11.5（0.45）1 CH被描述为电缆连接器高度。2 BR（弯曲半径）被描述为标准1326电缆组件的指定弯曲半径。BR可能因用户制造的电缆而异。对于标准电缆，BR是一次性柔性应用。柔性电缆具有更高的BR以承受柔性应用。安装前，所有电缆应悬挂或平放24小时。这将允许导体放松到其自然状态，并防止内部扭曲。10出版物1326A-2.11-1998年5月直角连接器尺寸下表显示了连接器的高度和宽度。对于1326 xxxRAL xxx和1326 xxx RBL xxx电缆，也给出了接头波纹管的直径。电缆高度（英寸）RA或RB直径（英寸）RAL或RBL直径mm（英寸）弯曲半径1326 CCU RA xxx和-RB xxx 65.78（2.59）36.83（1.45）N/A 50.8（2.0）1326 CCUT RA xxx和/RB xxx 66.80（2.63）36.83 6（4.0）1326 CECU RAL xxx和-RBL xxx 66.80（2.63）40.38（1.59）38.61（1.52）115（1.85）45.47（1.79）76.2（3.0）1326-CPB1T-RAL-xxx和-RBL xxx 69.85（2.75）46.99（1.85）45.47（1.79）104.1（4.1）1326-CPC1-RA-xxx和-RB xxx 84.07（3.31）54.36 3.31）57.15（2.25）55.37（2.18）160.2（6.3）高度直径高度波纹管直径1326 xxx RA xxx和1326 xxx RB xxx 1326 xxx RAL xxx和1328 xxx RBL xxx 11出版物1326A-2.11-1998年5月隔板连接器尺寸下表显示了1326 CCU Ex、1326-CPB1x Ex和1326-CPC1x-Ex电缆的尺寸。注意：您不需要将隔板电缆连接到机柜墙上，但需要遵循连接隔板电缆和双端电缆指南中的信息。1326电缆螺钉说明安装孔直径mm（in）安装孔中心之间的距离mm（in
40.4 (1.59) 11.5 (0.45) 1 CH is described as the cable connector height. 2 BR (bend radius) is described as the specified bend radius for standard 1326 cable assemblies. BR may vary on user-fabricated cables. For standard cable, BR is a one-time flex application. Flex cables have a much higher BR to withstand flex applications. All cables should be hung or laid flat for 24 hours prior to installation. This will allow the conductors to relax into their natural state and guards against internal twisting. 10 Publication 1326A-2.11 - May 1998 Right-Angle Connector Dimensions The following table shows connector height and width. For 1326-xxxRAL-xxx and 1326-xxx-RBL-xxx cables, the diameter at the connector bellows is also given. Cable Height mm (in) RA or RB Diameter mm (in) RAL or RBL Diameter mm (in) Bend Radius 1326-CCU-RA-xxx and -RB-xxx 65.78 (2.59) 36.83 (1.45) N/A 50.8 (2.0) 1326-CCUT-RA-xxx and -RB-xxx 66.80 (2.63) 36.83 (1.45) N/A 101.6 (4.0) 1326-CCU-RAL-xxx and -RBL-xxx 66.80 (2.63) 40.38 (1.59) 38.61 (1.52) 50.8 (2.0) 1326-CCUT-RAL-xxx and -RBL-xxx 66.80 (2.63) 40.38 (1.59) 38.61 (1.52) 101.6 (4.0) 1326-CECU-RAL-xxx and -RBL-xxx 66.80 (2.63) 40.38 (1.59) 38.61 (1.52) 115 (4.5) 1326-CECUT-RAL-xxx and -RBL-xxx 66.80 (2.63) 40.38 (1.59) 38.61 (1.52) 120 (4.7) 1326-CPB1-RA-xxx and -RB-xxx 68.58 (2.70) 43.18 (1.70) N/A 76.2 (3.0) 1326-CPB1T-RA-xxx and -RB-xxx 68.58 (2.70) 43.18 (1.70) N/A 104.1 (4.1) 1326-CPB1-RAL-xxx and -RBL-xxx 69.85 (2.75) 46.99 (1.85) 45.47 (1.79) 76.2 (3.0) 1326-CPB1T-RAL-xxx and -RBL-xxx 69.85 (2.75) 46.99 (1.85) 45.47 (1.79) 104.1 (4.1) 1326-CPC1-RA-xxx and -RB-xxx 84.07 (3.31) 54.36 (2.14) N/A 76.2 (3.0) 1326-CPC1T-RA-xxx and -RB-xxx 84.07 (3.31) 54.36 (2.14) N/A 160.2 (6.3) 1326-CPC1-RAL-xxx and -RBL-xxx 84.07 (3.31) 57.15 (2.25) 55.37 (2.18) 76.2 (3.0) 1326-CPC1T-RAL-xxx and -RBL-xxx 84.07 (3.31) 57.15 (2.25) 55.37 (2.18) 160.2 (6.3) Height Diameter Height Diameter Diameter at bellows 1326-xxx-RA-xxx and 1326-xxx-RB-xxx 1326-xxx-RAL-xxx and 1326-xxx-RBL-xxx 11 Publication 1326A-2.11 - May 1998 Bulkhead Connector Dimensions The following tables show dimensions for 1326-CCU-Ex, 1326- CPB1x-Ex, and 1326-CPC1x-Ex cables. Note: You do not need to attach the bulkhead cables to a cabinet wall, but you do need to follow the information in Guidelines for Connecting Bulkhead and Double-Ended Cables. 1326 Cable Screw description Diameter of mounting holes mm (in) Distance between centers of mounting holes mm (in) Diameter of connector mm (in) Diameter of connector opening mm (in) Bend Radius 1326-CCU-E-xxx
