互连表•弯曲半径和安装说明2出版物1326A-2.11-1998年5月伺服电机电缆B系列电力电缆（目录号1326-CPB1和1326-CPC1）和换向电缆（目录编号1326-CCU和1326-CECU）可用于标准一次性挠性应用，长度可达90米（295英尺）。（PLTC 90°C 300V，AWM 90°C 300 V，适用于1326-CCU和1326-CECU，TC型90°C 600V，适用于13.26-CPB1和1326-CPC1。）每根电缆均具有：•UL认证（文件编号E88699）电缆组件。•编织电缆屏蔽，具有卓越的电磁噪声抗扰性。•电机端的模压推拉连接器便于安装和维护。1394运动控制系统的电缆系统：•标准单连接器电缆。•直角连接器电缆。•使用隔板和双端电缆的在线系统。•恶劣的环境电缆。•高分辨率反馈电缆。Allen-Bradley还为电力轨道应用提供高弯曲等级电缆。电力电缆（目录号1326-CPB1T和1326-CPC1T）和换向电缆（目录编号1326-CCUT和1326-CECUT）的长度可达到90米（295英尺）。除了为标准电缆列出的功能外，每根柔性电缆都具有优异的最小弯曲半径额定值和优异的弯曲循环寿命。3出版物1326A-2.11-1998年5月电机电力电缆类型公告编号1326功能电机尺寸用于柔性电缆选件连接器附件C=连接器和电缆组件P=电源连接B1=1326AB-B4xx和1326AB-B5xx的电力电缆C1=1326AB-B7xx的电力线T=高柔性应用的柔性额定电缆空白=无选项，标准电缆空白=单标准连接器D=双头，标准连接器E=隔板连接器EE=双头，隔板连接器RA=直角连接器RB=直角连接器IP额定电缆长度空白=IP65 L=IP67，恶劣环境005=5m（16.4 ft.）015=15m（49.2 ft.）030=30m（98.4 ft.）060=60m（196.8 ft.）084=84m（275.5 ft.）090=90m（295.2 ft.）4出版物1326A-2.11-1998年5月电机反馈电缆类型公告编号1326用于柔性电缆选件连接器的功能电机尺寸附件C=连接器和电缆组件C=解析器反馈EC=高分辨率U=换向和所有系列电机的编码器电缆。T=高挠性应用的挠性额定电缆空白=无选项，标准电缆空白=单标准连接器D=双头，标准连接器E=隔板连接器EE=双头，隔板连接器RA=直角连接器RB=直角连接器IP额定电缆长度空白=IP65 L=IP67，恶劣环境005=5米（16.4英尺）015=15米（49.2英尺）030=30米（98.4英尺）060=60米（196.8英尺）084=84米（275.5英尺）090=90米（295.2英尺）
Interconnection tables • Bend radius and installation instructions 2 Publication 1326A-2.11 - May 1998 Servomotor Cable Series B Power cables (catalog number 1326-CPB1 and 1326-CPC1) and commutation cables (catalog number 1326-CCU and 1326- CECU) are available in lengths up to 90 m (295 ft) for standard, onetime flex applications. (PLTC 90° C 300V, AWM 90° C 300V for 1326-CCU and 1326-CECU, type TC 90° C 600V for 1326-CPB1 and 1326-CPC1.) Each cable features: • UL Listed (file #E88699) cable assemblies. • A braided cable shield for superior electromagnetic noise immunity. • Molded push/pull connectors at the motor end for easy installation and maintenance. Cable systems for 1394 Motion Control System: • Standard single-connector cables. • Right-angle connector cables. • In-line system that uses bulkhead and double-ended cables. • Harsh environment cables. • High-resolution feedback cables. Allen-Bradley also offers high flex-rated cable for power-track applications. Power cables (catalog number 1326-CPB1T and 1326- CPC1T) and commutation cables (catalog number 1326-CCUT and 1326-CECUT) are available in lengths up to 90 m (295 ft). In addition to the features listed for standard cables, each flex-cable features excellent minimum bend radius ratings and a superior flex cycle life. 3 Publication 1326A-2.11 - May 1998 Motor Power Cables Type Bulletin Number 1326 Function Motor Size Used On Flex Cable Option Connector Accessory C = Connector and cable assembly P = Power connection B1 = Power cable for 1326AB-B4xx and 1326AB-B5xx C1 = Power cable for 1326AB-B7xx T = Flex-rated cable for high-flex applications Blank = No option, standard cable Blank = Single-standard connector D = Double-ended, standard connector E = Bulkhead connector EE = Double-ended, bulkhead connector RA = Right-angle connector RB = Right-angle connector IP Rating Cable Length Blank = IP65 L = IP67, harsh environment 005 = 5m (16.4 ft.) 015 = 15m (49.2 ft.) 030 = 30m (98.4 ft.) 060 = 60m (196.8 ft.) 084 = 84m (275.5 ft.) 090 = 90m (295.2 ft.) 4 Publication 1326A-2.11 - May 1998 Motor Feedback Cables Type Bulletin Number 1326 Function Motor Size Used On Flex Cable Option Connector Accessory C = Connector and cable assembly C = Resolver feedback EC = High-resolution U = Commutation and encoder cable for all series motors. T = Flex-rated cable for high-flex applications Blank = No option, standard cable Blank = Single-standard connector D = Double-ended, standard connector E = Bulkhead connector EE = Double-ended, bulkhead connector RA = Right-angle connector RB = Right-angle connector IP Rating Cable Length Blank = IP65 L = IP67, harsh environment 005 = 5m (16.4 ft.) 015 = 15m (49.2 ft.) 030 = 30m (98.4 ft.) 060 = 60m (196.8 ft.) 084 = 84m (275.5 ft.) 090 = 90m (295.2 ft.)
