440F-A3230导丝器可以提供适当的保护。其他电线线路应使用导管或电缆槽。控制单元的密封完整性必须通过使用尺寸正确且紧固的导管配件或电缆密封套（IP65）来保持。从控制单元到垫子的布线可以使用导管埋在地板中，或通过边缘镶边。此类安装建议使用挠性导管。详见第6节。确定接线方法，并确定控制单元接线垫的输入和输出连接点。5.10最终细节准备安装布局和电路的工作计划和图纸。建议将所有测量和计算记录并保存在机器的技术文件中。440F护垫™ Mat Manager用户手册第6节-安装和调试26罗克韦尔自动化出版物95302194/EO:0240发行号：8）第6节：安装和调试安装和调试应由系统设计师监督。需要一名熟悉工业布线实践的机械技术人员和一名电工进行安装。调试应由在安全安装方面有经验的训练有素的电气技术人员进行。6.1垫子安装隔离并锁定机器电源。检查地板是否平整、光滑、干净、无碎屑，埋地管道或其他布线是否正确到位。拆开垫子，小心保持平整，不要拉扯电线。将垫子放置在地板上的计划位置，连接线位于检测区域的外围。主动组合装饰固定安装中使用的所有主动组合装饰部分必须钝斜接至45º，如图24所示。这有助于安装并有助于保持传感区域的整体灵敏度。图25显示了典型的多垫配置的连接。图24图25开始安装前，应完整阅读本手册。开始工作前，请仔细学习本节内容。布线必须符合《国家电气规范》和适用的地方法规和条例。重要事项45°45°Mat 1 Mat 2 Mat 3 Mat 4 Mat 1 Mat 2 Mat2 Mat 2 Rockwell Automation出版物95302194/EO:0240发行号：8 27 440F MatGuard™ Mat Manager用户手册第6节-安装和调试周边装饰件固定如果控制单元的电线未埋置，在电线入口和出口位置对周边装饰件进行开槽，并切割装饰件斜坡，以适合如图26所示选择的导管系统。小心完全开槽，以使周边装饰件的弯曲不会夹住电线。确保没有可能损坏导线的锐边或毛刺。图26标出地板上的边缘装饰件固定位置，使装饰件与垫子重叠。
the 440F-A3230 wire guide can provide suitable protection. Conduit or cable troughs should be used for other wire runs. The sealing integrity of the control unit must be maintained by the use of correctly sized and tightened conduit fittings or cable glands to IP65. Wiring from the control unit to the mat may be buried in the floor using conduit, or pass via the edge trim. Flexible conduit is recommended for this type of installation. See section 6 for further details. Determine the wiring method and determine the input and output connection points for the mat to control unit wiring. 5.10 Final Details Prepare a work schedule and drawings of the installation layout and the electrical circuit. It is recommended that all measurements and calculations are recorded and retained in the technical file for the machine. 440F MatGuard™ Mat Manager User Manual Section 6 - Installation and Commissioning 26 Rockwell Automation Publication 95302194/EO:0240 Issue No: 8) Section 6 - Installation and Commissioning The installation and commissioning should be supervised by the system designer. A mechanical technician and an electrician familiar with industrial wiring practices will be required to undertake the installation. Commissioning should be undertaken by a trained electrical technician experienced in safety installations. 6.1 Mat Installation Isolate and lock off the machine power supply at source. Check that the floor is flat, smooth, clean and free of debris and that buried conduit or other wiring provision is correctly in place. Unpack the mats being careful to keep them flat and not to pull on the wires. Place the mats on the floor in the planned positions with the connecting wires at the periphery of the detection zone. Active Uniting Trim Fixing All active uniting trim sections used in installation must be blunt mitered to 45º as shown in Figure 24. This aids the installation and helps retain overall sensitivity of the sensing area. Figure 25 shows junctions of typical multiple mat configurations. Figure 24 Figure 25 This manual should be read in full before commencing installation. Study this section completely before starting work. Wiring must be in accordance with the National Electric Code and applicable local codes and ordinances. IMPORTANT IMPORTANT 45° 45° Mat 1 Mat 2 Mat 3 Mat 4 Mat 1 Mat 2 Mat 1 Mat 2 Mat 3 Rockwell Automation Publication 95302194/EO:0240 Issue No: 8 27 440F MatGuard™ Mat Manager User Manual Section 6 - Installation and Commissioning Perimeter Trim Fixing Where the wiring to the control unit is not buried, notch the perimeter trim at the wire entry and exit positions and cut the trim slope to suit the conduit system selected as shown in Figure 26. Take care to notch completely so that flexing of the perimeter trim will not trap the wiring. Ensure that there are no sharp edges or burrs which could damage the wires. Figure 26 Mark out the edge trim fixing positions on the floor allowing the trim to overlap the mat.
