PFTL201DE 50.0KN 3BSE008922R51库存备件
按下启动按钮为负载通电。踩在任何垫子上都会导致安全输出打开并切断负载的电源。接触器K1断开并打开闭锁电路。踏下垫子后，必须按下启动按钮以关闭安全输出并重新给负载通电。12 34+ue 5 6 7 8 63 54 64 K1 K1 K2 K2案例-ue 53 81 MCa 82 MCb L1 L2 L3 NO L2 PB L1 115 230+24V DC 440F-C28013 AC电源重置M A保险丝重置电机辅助输出DC接地PE接地最多8个传感器垫备用电源115V/230V AC罗克韦尔自动化出版物95302194/EO:0240发行号：8 21 440F MatGuard™ Mat Manager用户手册第5节-安装设计图18图19显示了440F-C28021和440F-C2802 3的示例连接图。电路条件如下：电源打开；传感器垫上不存在，常开安全输出打开，负载断电。控制单元配置为监控手动复位。按下并释放复位按钮，为负载通电。踩在任何垫子上都会导致安全输出打开并切断负载的电源。离开垫子后，必须按下并释放重置按钮，以重新给负载通电。+电源电压440F-C28021（24V DC）重置M A保险丝K1辅助触点辅助输出电源接地PE接地最多8个传感器垫交流电源115 230 440F-C2803（115/230V AC）启动停止负载负载负载负载440F MatGuard™ Mat Manager用户手册第5节-安装设计22罗克韦尔自动化出版物95302194/EO:0240发行号：8）图19图20显示了440F-C28024的示例连接图。电路条件如下：电源开启；传感器垫上不存在，常开安全输出打开，负载断电。控制单元配置为监控手动复位。按下并松开位于控制单元前部的复位按钮，以给负载通电。踩在任何垫子上都会导致安全输出打开并切断负载的电源。离开垫子后，必须按下并释放重置按钮，以重新给负载通电。图20 12 34 1 5 6 7 8 3 5 4 6 7 9 2 8 10 11 13 17 12 14 16 18+电源电压440F-C28021（24V DC）重置M A保险丝辅助输出电源接地PE接地至8个传感器垫交流电源115 230 440F-C2802 3（115/230V AC）负载负载负载重置2 3 7 5 8 12 34 5 6 8 1 6 K1 K1 K2 L1 L3+24V DC 440F-C2804重置M A熔断器直流接地PE至8个传感垫电机罗克韦尔自动化
Press the start button to energize the loads. Stepping on any of the mats will cause the safety outputs to open and remove power to the loads. Contactor K1 drops out and opens the latching circuit. After stepping off the mats, the start button must be pressed to close the safety outputs and re-energize the loads. 12 34 +ue 5 6 7 8 63 54 64 K1 K1 K2 K2 Case -ue 53 81 MCa 82 MCb L1 L2 L3 NO L2 PB L1 115 230 +24V DC 440F-C28013 AC Power Reset M A Fuse Reset Motor Auxiliary Output DC Ground PE Ground Up to 8 Sensor Mats Alternate Supply 115V/230V AC Rockwell Automation Publication 95302194/EO:0240 Issue No: 8 21 440F MatGuard™ Mat Manager User Manual Section 5 - Installation Design Figure 18 Figure 19 shows an example connection diagram for the 440F-C28021 and the 440F-C28023. The circuit conditions are as follows: supply power is ON; no presence on the sensor mats, the normally open safety outputs are open and the loads are deenergized. The control unit is configured for monitored manual reset. Press and release the reset button to energize the loads. Stepping on any of the mats will cause the safety outputs to open and remove power to the loads. After stepping off the mat, the reset button must be pressed and released to re-energize the loads. + Supply Voltage 440F-C28021 (24V DC) Reset M A Fuse K1 Aux Contact Auxiliary Output Supply Ground PE Ground Up to 8 Sensor Mats AC Power 115 230 440F-C28023 (115/230V AC) Start Stop Load Load Load Load Load Load 440F MatGuard™ Mat Manager User Manual Section 5 - Installation Design 22 Rockwell Automation Publication 95302194/EO:0240 Issue No: 8) Figure 19 Figure 20 shows an example connection diagram for the 440F-C28024. The circuit conditions are as follows: supply power is ON; no presence on the sensor mats, the normally open safety outputs are open and the loads are de-energized. The control unit is configured for monitored manual reset. Press and release the reset button, located on the front of the control unit, to energize the loads. Stepping on any of the mats will cause the safety outputs to open and remove power to the loads. After stepping off the mat, the reset button must be pressed and released to re-energize the loads. Figure 20 12 34 1 5 6 7 8 3 5 4 6 7 9 2 8 10 11 13 15 17 12 14 16 18 + Supply Voltage 440F-C28021 (24V DC) Reset M A Fuse Auxiliary Output Supply Ground PE Ground Up to 8 Sensor Mats AC Power 115 230 440F-C28023 (115/230V AC) Load Load Load Load Load Load Reset 2 3 7 5 8 12 34 5 6 7 8 1 6 K1 K1 K2 K2 L1 L2 L3 + 24V DC 440F-C28024 Reset M A Fuse DC Ground PE Ground Up to 8 Sensor Mats Motor Rockwell Automation
