PM510V16/3BSE008358R1工控模块系统备件
市场上的大多数其他并联系统使用自上而下的配置，其中当任何辅助模块发生故障时，主模块会发生故障。凭借伊顿独特的方法，每个UPS都是独立的，但与其他UPS同步，以防止任何单点故障，并帮助消除成本高昂的停机时间。其他并联优势包括：•可扩展性，使用一个并联连接柜从10到120 kVA•N+3、N+2或N+1冗余，占地面积小，从10到90 kVA，通常比单个大型UPS占地面积小•冗余电池系统，每个并联UPS都包含自己的内部电池最多可并联四个9355 UPS，以实现容量或冗余-通常比单个大型UPS并联连接柜的占地面积更小。与同类UPS解决方案相比，9355 UPS提供了业界领先的功率密度和75%的占地面积。所有标准9355配置均采用内置电池，以提供高达350%的运行时间，并在同等VA额定值下提供13%的容量。延长的运行时间允许9355在无需额外硬件的情况下为这一额外容量供电近四倍，从而消除了对昂贵且占用空间的外部电池柜的需求。标准的10 kVA和20 kVA容量型号也可以分别升级到15 kVA和30 kVA，无需额外的硬件和占地面积即可提供50%的电力。9355占地面积小，仅需3至6平方英尺的占地面积，便于数据中心空间规划和保存宝贵的活动地板房地产。最大运行时间，最小占地面积伊顿优势尺寸占地面积电池（英寸）（平方运行时间（分钟）W D H英寸）10 kVA 15 kVA 9355 12 34 32 408 9 5竞争对手A 21 33 59 693 5 5竞争对手B 24 36 82 864 5 5竞争竞争对手C 33 40 63 1320 5 5尺寸占地面积（英寸）竞争对手B 24 36 82 864 5 5竞争对手C 33 40 63 1320 5 5在20 kVA时，9355的占地面积减少了48%，电池运行时间增加了三倍以上。在15 kVA时，与竞争对手相比，9355占地面积减少70%
Most other paralleling systems on the market use a top-down configuration in which the master fails when any subsidiary module fails. With Eaton’s unique approach, each UPS is independent, yet synchronized with the others to prevent any single point of failure and help eliminate costly downtime. Additional paralleling benefits include: • Scalability, from 10 to 120 kVA using one parallel tie cabinet • N+3, N+2 or N+1 redundancy, from 10 to 90 kVA in a compact footprint—often in a smaller footprint than a single large UPS • Redundant battery systems, with each parallel UPS containing its own internal batteries Up to four 9355 UPSs can be paralleled for capacity or redundancy— often in a smaller footprint than a single large UPS Parallel tie cabinet Front Rear The 9355 UPS provides industry-leading power density and a 75 percent footprint reduction versus comparable UPS solutions. All standard 9355 configurations incorporate internal batteries to provide up to 350 percent more runtime and offer 13 percent more capacity at equivalent VA ratings. Extended runtime allows the 9355 to power this extra capacity nearly four times longer without additional hardware, eliminating the need for costly and space-consuming external battery cabinets. Standard 10 kVA and 20 kVA capacity models can also be upgraded to 15 kVA and 30 kVA, respectively, providing 50 percent more power with no additional hardware and no increase in footprint. The 9355’s small footprint requires only three to six square feet of floor space, enabling easy data center spaceplanning and preserving valuable raised-floor real estate. Maximum runtime, minimum footprint The Eaton advantage Dimensions Footprint Battery (inches) (square Runtime (minutes) W D H inches) 10 kVA 15 kVA 9355 12 34 32 408 9 5 Competitor A 21 33 59 693 5 5 Competitor B 24 36 82 864 5 5 Competitor C 33 40 63 1320 5 5 Dimensions Footprint Battery (inches) (square Runtime (minutes) W D H inches) 20 kVA 30 kVA 9355 20 34 66 680 18 11 Competitor A 21 33 59 693 5 5 Competitor B 24 36 82 864 5 5 Competitor C 33 40 63 1320 5 5 At 20 kVA, the 9355 occupies 48% less footprint and delivers over three times the battery runtime At 15 kVA, the 9355 occupies 70% less footprint than competitor
