能力IDD 5.2 mA电源，用于串行I/O引脚VDD_325 2.25 2.5 2.75 V输入电压低高VIL VIH--0.7*VDD_325--0.25*VDD_325--V V输出电压低高VOL VOH--1.85--0.4--V V表8-2eVDD_325@1.8V串行I/O引脚参数符号最小类型最大单位输出驱动能力IDD 4.4 mA电源用于串行I/O引脚VDD_325 1.65 1.8 1.95 V输入电压低高VIL VIH--0.7*VDD_325--0.25*VDD_325--V V输出电压低高VOL VOH--1.25--0.4--V V 8.3温度特性表8-3温度特性参数符号最小典型最大单位操作温度--0-70°C结操作温度TJ-40 25 80°C发布日期：2013年3月27日，2018 DS_PL2303SA_d20180327_1.2.0.doc PL2303SA产品数据表-14-文件版本1.2.0 8.4泄漏电流和电容表8-4泄漏电流和容量参数符号最小典型最大单位输入泄漏电流（1）IL-10±1 10 mA三态泄漏电流Ioz-10±1 10mA输入电容CIN-2.8-pF输出电容COUT 2.7-4.9 pF双向缓冲器电容CBID 2.7-4.9 pF（1）–无上拉或下拉电阻器。发布日期：2018年3月27日DS_PL2303SA_d20180327_v1.2.0.doc PL2303SA产品数据表-15-文档版本1.2.0 9.0 SOP8大纲图图9-1 SOP8包装大纲图发布日期：2013年3月26日，2018 DS_PL2303SA_d20180327_v1.2.0.doc PL2303SA产品数据表-16-文档版本1.2.0 10.0订购信息表10-1订购信息零件号包装类型PL-2303SA LF 8针SOP无铅图10-1芯片零件号信息表10-2芯片标记信息线标记描述第一行PL2303SA芯片产品名称第二行（GYYWXXX）G绿色复合包装材料（无铅）YY制造年份WW最后两位数字制造年份XXX芯片版本（2D）第三行TXXXXXXXX制造批次代码示例：“G11462D”–表示绿色包装+2011年+第46周+2D芯片版本。revents inrus8针USB至UART Bridge Controller IC Prolific Technology Inc.7F，No.48，Sec，No.4，No.4 of Nan Kang Rd，Nan Kang115，Taiwan电话：+886-2-2654-6363；传真：886-2-22654-6161网址：http://www.prolific.com.tw/©2018 Prolific Inc.保留所有权利。专有和机密产品数据表PL2303GL PL2303GL8针USB到UART桥接控制器IC USB接口·完全符合USB 2.0规范（全速模式）。·USB-IF认证（符合USB标志），TID 40001839。·UHCI/OHCI（USB 1.1）、EHCI（USB 2.0）、xHCI（USB3.1）主机控制器兼容。·为Windows、Mac、Linux和Android提供免版税的USB到虚拟通信端口（VCP）驱动程序。·高度集成的USB 1.1 FS收发器。集成终端电阻器和上拉电阻器，以减少PCB外部组件。·支持USB设备描述符的OTPROM（一次性可编程ROM）。
Capability IDD 5.2 mA Power Supply for Serial I/O Pins VDD_325 2.25 2.5 2.75 V Input Voltage Low High VIL VIH -- 0.7* VDD_325 -- -- 0.25* VDD_325 -- V V Output Voltage Low High VOL VOH -- 1.85 -- -- 0.4 -- V V Table 8-2e VDD_325@1.8V Serial I/O Pins Parameter Symbol Min Typ Max Unit Output Driving Capability IDD 4.4 mA Power Supply for Serial I/O Pins VDD_325 1.65 1.8 1.95 V Input Voltage Low High VIL VIH -- 0.7* VDD_325 -- -- 0.25* VDD_325 -- V V Output Voltage Low High VOL VOH -- 1.25 -- -- 0.4 -- V V 8.3 Temperature Characteristics Table 8-3 Temperature Characteristics Parameter Symbol Min Typ Max Unit Operating Temperature -- 0 -- 70 o C Junction Operation Temperature TJ -40 25 80 o C Released Date: March 27, 2018 DS_PL2303SA_d20180327_v1.2.0.doc PL2303SA Product Datasheet - 14 - Document Version 1.2.0 8.4 Leakage Current and Capacitance Table 8-4 Leakage Current and Capacitance Parameter Symbol Min Typ Max Unit Input Leakage Current(1) IL -10 ±1 10 mA Tri-state Leakage Current Ioz -10 ±1 10 mA Input Capacitance CIN -- 2.8 -- pF Output Capacitance COUT 2.7 -- 4.9 pF Bi-directional Buffer Capacitance CBID 2.7 -- 4.9 pF (1) – No pull-up or pull-down resistor. Released Date: March 27, 2018 DS_PL2303SA_d20180327_v1.2.0.doc PL2303SA Product Datasheet - 15 - Document Version 1.2.0 9.0 SOP8 Outline Diagram Figure 9-1 SOP8 Package Outline Diagram Released Date: March 27, 2018 DS_PL2303SA_d20180327_v1.2.0.doc PL2303SA Product Datasheet - 16 - Document Version 1.2.0 10.0 Ordering Information Table 10-1 Ordering Information Part Number Package Type PL-2303SA LF 8-pin SOP Lead Free Figure 10-1 Chip Part Number Information Table 10-2 Chip Marking Information Line Marking Description First Line PL2303SA Chip Product Name Second Line (GYYWWXXX) G Green compound packing material (Pb-free) YY Last two digits of the manufacturing year WW Week number of the manufacturing year XXX Chip Version (2D) Third Line TXXXXXXXX Manufacturing LOT code Example: “G11462D” – means Green packing + Year 2011 + Week no. 46 + 2D chip version.revents inrus8-Pin USB to UART Bridge Controller IC Prolific Technology Inc. 7F, No.48, Sec. 3, Nan Kang Rd., Nan Kang, Taipei 115, Taiwan Tel：+886-2-2654-6363; Fax：886-2-22654-6161 Website：http://www.prolific.com.tw/ © 2018 Prolific Inc. All rights reserved. Proprietary and Confidential Product Data Sheet PL2303GL PL2303GL 8-Pin USB to UART Bridge Controller IC USB Interface · Fully Compliant with USB 2.0 specification (Full-Speed Mode). · USB-IF certified (USB logo compliant) with TID 40001839. · UHCI/OHCI (USB 1.1), EHCI (USB 2.0), xHCI (USB 3.1) Host Controller Compatible. · Provides royalty-free USB to Virtual Com Port (VCP) drivers for Windows, Mac, Linux, and Android. · Highly integrated USB 1.1 FS Transceiver. Integrated termination resistors and pull-up resistor to reduce PCB external components. · Supports OTPROM (One-Time Programmable ROM) for USB device descriptors.
