注：所示二极管可以是带有内置二极管（1492-JD3DF或1492-JD3D R）的接线板。版权所有©2015 Rockwell Automation，Inc。版权所有。MatGuard压敏安全垫系统安装和用户手册安装前请阅读本手册。安装后，应将本手册保存在安全、易接近的地方。R 1 2 MatGuard-压敏安全垫安装和使用手册第1节存储和搬运第4页第2节系统说明第5页第3节应用第8页第4节规范第10页第5节安装设计第14页第6节安装和调试第26页第7节使用第36页第8节维护第37页传感器垫标记本手册参考了以下标准：EN 292-1和2：机械安全-基本概念-设计总则-第1和2部分EN 294：机械安全–安全距离以防止上肢触及危险区域。EN 811：机械安全-防止下肢触及危险区域的安全距离。EN 953：机械安全-防护结构的一般要求。EN 954-1：机械安全-控制系统的安全相关部件-第1部分：一般设计原则。EN 999：（标准草案）机械安全-根据人体各部分的接近速度定位防护设备。EN 1050：机械安全-风险评估。EN 1760-1：机械安全-压敏保护装置-第1部分：压敏垫和地板。EN 60204-1：机械安全-机械电气设备-第1部分：一般要求规范。有关这些标准可用性的信息，可从BSI销售电话：+44（0）20 8996 9001传真：+44）20 8999 7001。MATGUARD压敏安全垫系统控制单元电源电压230/110VAC（见选择器）50-60Hz或24VAC/DC IP65防水防尘安全触点250V 2A N/O辅助触点250V 2AN/C MATGUARD垫电压24VDC EN 954-1类别3，系统响应时间35ms有关更多信息，请参阅用户手册自动重置模式机器启用电源手动重置模式按下重置12345678 MAT状态在打开之前隔离所有电源，英国制造。MatGuard型号：440F-C28013 R，美国制造。请参考用户手册型号。
Note: The diodes shown can be terminal blocks with built-in diodes (1492-JD3DF or 1492-JD3DR). Copyright © 2015 Rockwell Automation, Inc. All Rights Reserved.MatGuard PRESSURE SENSITIVE SAFETY MAT SYSTEM INSTALLATION & USER MANUAL READ THIS MANUAL IN FULL BEFORE INSTALLATION After installation this manual should be retained in a safe and accessible place R 1 2 MatGuard - Pressure sensitive safety mat system Installation and user manual Section 1 STORAGE AND HANDLING page 4 Section 2 SYSTEM DESCRIPTION page 5 Section 3 APPLICATIONS page 8 Section 4 SPECIFICATIONS page 10 Section 5 INSTALLATION DESIGN page 14 Section 6 INSTALLATION and COMMISSIONING page 26 Section 7 USE page 36 Section 8 MAINTENANCE page 37 Sensor mat marking The following Standards are referred to in this manual: EN 292 - 1&2: Safety of machinery - Basic concepts - General principles for design - Parts 1 and 2 EN 294: Safety of machinery - Safety distances to prevent danger zones being reached by upper limbs. EN 811: Safety of machinery - Safety distances to prevent danger zones being reached by lower limbs. EN 953: Safety of machinery - General requirements for the construction of guards. EN 954-1: Safety of machinery - Safety related parts of control systems - Part 1: General principles for design. EN 999:(Draft Standard) Safety of machinery - Positioning of protective equipment in respect of approach speeds of parts of the human body. EN 1050: Safety of machinery - Risk assessment. EN 1760-1: Safety of machinery - Pressure sensitive protective devices - Part 1: Pressure sensing mats and floors. EN 60204-1: Safety of machinery - Electrical equipment of machines - Part 1: Specification for general requirements. Information on the availability of these standards can be obtained from BSI Sales Tel: +44 (0) 20 8996 9001 Fax: +44 (0) 20 8996 7001. MATGUARD PRESSURE SENSITIVE SAFETY MAT SYSTEM CONTROL UNIT Supply Voltage 230/110VAC (see selector) 50-60Hz or 24VAC/DC IP65 Hoseproof, Dust tight Safety Contacts 250V 2A N/O Aux Contacts 250V 2A N/C MatGuard Mat Voltage 24VDC EN 954-1 Category 3, System Response Time 35ms See user manual for further information AUTO RESET MODE MACHINE ENABLED POWER MANUAL RESET MODE PRESS TO RESET 12345678 MAT STATUS ISOLATE ALL POWER SUPPLIES BEFORE OPENING MADE IN THE UK. MatGuard Type No: 440F-C28013 R MADE IN U.S.A. REFER TO USER MANUAL Model No.
