螺栓圈
孔，在直径101.6（4.00）的孔上等距分布3处。螺栓圈。1+0.000/–0.0127（+0.0000/–0.0005）公差。2+0.000/–0.0762（+0.0000/–0.003）公差。3解析器反馈安装套件中提供的所有安装硬件。4 Cannon内螺纹连接器CA3102R20–29P或安装在包装上的同等产品。Cannon公配合连接器CA3106F–20–295–A95或同等产品。5有关更多信息，请参阅1326AB解析器反馈包产品数据。6（0.38）2（3.62）3 17针连接器5产品数据1326AB AC伺服电机25解析器反馈安装适配器套件（1326AB MOD Mx）解析器反馈安装套件提供了将1326AB解析器安装到B和C系列电机的方法。
A系列电机不需要适配器
使用此选项时，电机的IP 65额定值不会保持不变。图16 1326AB解析器安装套件尺寸1326AB–Bxx或Cxx交流伺服电机M22–5.88（149.4）M23–7.63（193.8）1326AB-MOD–M22或1326AB—MOD–M23适配器，用于安装到1326AB？Bxx或1326AB-Cxx电机，分别（1326AB–Axx电机不需要适配器）0.38（9.7）电机接线盒套件（1326AB-MOD RJxx）电机接线箱套件提供轴向安装的连接器。连接器版本允许电机连接器轴向引出至电机，无需进一步布线。使用该接线盒时，电机的防护等级保持在IP65。接线盒尺寸如下图所示。产品数据1326AB交流伺服电机26图17电机接线盒尺寸尺寸A B C，带连接器4.13（105.0）2.44（62.0）2.50（190.5）交替位置盖和垫片C A B鼓风机套件（1326AB-MOD-G3，G4）有两个鼓风机套件可用于1326AB“C”系列交流伺服电机。“G3”套件专为“C2E”和“C4B”伺服电机设计。
Bolt ring
Holes, 3 equally spaced on 101.6 (4.00) diameter holes. Bolt ring. 1+0.000/– 0.0127 (+0.0000/– 0.0005) tolerance. 2+0.000/– 0.0762 (+0.0000/– 0.003) tolerance. 3 All the installation hardware provided in the parser feedback installation kit. 4 Cannon female connector CA3102R20 – 29P or equivalent installed on the package. Cannon male mating connector CA3106F – 20 – 295 – A95 or equivalent. 5 For more information, see 1326AB parser feedback package product data. 6 (0.38) 2 (3.62) 3 17 pin connector 5 product data 1326AB AC servo motor 25 resolver feedback installation adapter kit (1326AB MOD Mx) The resolver feedback installation kit provides a method for installing the 1326AB resolver to B and C series motors.
A series motors do not require adapters
With this option, the IP 65 rating of the motor does not remain unchanged. Figure 16 1326AB Resolver Mounting Kit Size 1326AB – Bxx or Cxx AC Servo Motor M22 – 5.88 (149.4) M23 – 7.63 (193.8) 1326AB-MOD – M22 or 1326AB – MOD – M23 Adapter for Mounting to 1326AB? Bxx or 1326AB Cxx motors, respectively (1326AB – Axx motors do not require adapters) 0.38 (9.7) motor junction box kit (1326AB MOD RJxx) motor junction box kit provides axial mounted connectors. The connector version allows the motor connector to be axially led out to the motor without further wiring. When the terminal box is used, the protection level of the motor shall be kept at IP65. The size of the junction box is shown in the figure below. Product data 1326AB AC servo motor 26 Figure 17 Motor junction box dimensions A B C, with connector 4.13 (105.0) 2.44 (62.0) 2.50 (190.5) Alternate position cover and gasket C A B Blower kit (1326AB-MOD-G3, G4) There are two blower kits available for 1326AB "C" series AC servo motors. The "G3" kit is designed for "C2E" and "C4B" servomotors.
