整体保持制动器
（选项-Ax或-Kx）当目录号包含后缀“-Ax”（90V DC输入）或“-Kx”（24V DC输入）时，1326AB伺服电机包含整体保持制动器。制动器为盘式制动器，在断电时弹簧固定。制动器设计用于将负载保持在静止状态，并为紧急停止提供有限的制动扭矩。制动器不能用作定位制动器（制动器齿隙最大值为0.8弧分），也不能连续循环以帮助停止负载。当用作停车制动器时，制动器的通电/断电不得超过每小时90次。驻车制动器仅用于固定负载，不用于停止电机运动，除非发生电源中断。有关更多信息，请参阅表B和公告1391说明手册。
保持制动数据
电机目录号1326AB-A-11、21 1326AB-B-11、21 132 6AB-C-11、21保持扭矩lb.-in。（N-m）72（8.1）120（13.6）400（45.1）通电制动响应时间吸合/释放时的电流消耗120ms/20ms 150ms/25ms 120ms/30ms重量加至电机重量lbs.（kg）3.0（1.36）9.0（4.08）13.0（5.90）耐寒惯性加至电机惯性lb.-in-s2（kg-cm-s2）0.001（0.001）0.0027（0.0031）0.0046（0.0053）-Ax（90V）0.26A 0.37A 0.32A-Kx（24V）0.88A 1.20A 1.20A-Ax（90 V）382欧姆270欧姆306欧姆-Kx（24 V）28欧姆21欧姆21欧姆90V DC制动器（1326-MOD-BPS）制动电源将120V AC转换为90V DC制动所需的电压。一个电源最多可连接四个制动器。但是，如果需要对多个电机进行独立控制，则必须为每个电机使用一个电源。
Overall holding brake
(Option - Ax or - Kx) When the catalog number contains the suffix "- Ax" (90V DC input) or "- Kx" (24V DC input), the 1326AB servo motor contains an integral holding brake. The brake is a disc brake, and the spring is fixed when the power is off. The brake is designed to hold the load at rest and provide limited braking torque for emergency stop. The brake cannot be used as a positioning brake (maximum brake backlash is 0.8 minutes of arc), nor can it be cycled continuously to help stop the load. When used as a parking brake, the brakes must not be energized/de energized more than 90 times per hour. The parking brake is only used to fix the load, not to stop the motor movement, unless the power supply is interrupted. For more information, refer to Table B and Bulletin 1391 Instruction Manual.
Keep braking data
Motor catalog numbers 1326AB-A-11, 21 1326AB-B-11, 21 132 6AB-C-11, 21 holding torque lb. - in. (N-m) 72 (8.1) 120 (13.6) 400 (45.1) Current consumption when the response time of energized braking is engaged/released 120ms/20ms 150ms/25ms 120ms/30ms weight is added to the motor weight lbs. (kg) 3.0 (1.36) 9.0 (4.08) 13.0 (5.90) Cold resistant inertia is added to the motor inertia lb.in-s2 (kg-cm-s2) 0.001 (0.001) 0.0027 (0.0031) 0.0046 (0.0053) - Ax (90V) 0.26A 0.37A 0.32A-Kx (24V) 0.88A 1.20A 1.20A 1.20A-Ax (90V) 382 ohm 270 ohm 306 ohm Kx (24 V) 28 ohm 21 ohm 21 ohm 90V DC Brake (1326-MOD-BPS) Brake power converts 120V AC to the voltage required for 90V DC braking. Up to four brakes can be connected to one power supply. However, if independent control of multiple motors is required, one power supply must be used for each motor.
