VMIVME-2540-000自动化工控模块
连续额定输出扭矩
•失速时100%连续额定输出扭矩（零rpm）。•总峰峰值位移0.0005“（0.0127 mm）的精密天平。•垂直轴上下安装。•TENV结构。•IP65等级（与轴封选项一起使用时），可承受恶劣环境。电机防尘，能够承受脉动水射流，而不会有液体进入电机。重要提示：当使用外部安装的编码器/分解器反馈或鼓风机组件时，1326AB电机失去IP 65额定值。•电机绕组中的常闭热开关（1A时额定115V AC，1A时额定24V DC）提供热过载指示。•环保密封电源和反馈电缆组件。电源和分解器fe反馈电缆可按标准（柔性）、轨道（多柔性）或延长长度（ES）订购。•MIL规格连接器为标准连接器。•铁氧体磁体，实现经济高效的性能。•UL认可的绝缘系统（文件编号E57948）。1326AB可用的伺服电机选项包括（括号中的选项代码名称或目录号）：•带有90V直流线圈（-A4、-A5、-A7）或24V直流线圈（-K4、-K5、-K7）的整体弹簧组固定制动器。
制动电源
（1326-MOD-BPS）将115V AC转换为90V DC制动器（-A4、-A5和-A7）所需的电压。•用于现场安装氟橡胶轴封的轴封套件（1326AB MOD SSV xx）。无需拆卸电机。•NEMA英寸（-11）或IEC公制法兰安装（-21），带公制轴。产品数据1326AB交流伺服电机3图1交流伺服电机配置和选项解析器/编码器次级反馈包反馈安装套件接线盒套件氟橡胶轴油封鼓风机冷却套件一体式制动器（电机内部）90V直流制动电源•解析器反馈包（1326AB MOD Vxxxx）提供4.25“（108 mm）传感器，可提供绝对/游标或单个无刷旋转变压器反馈，用于Allen-Bradley 8600GP、IMC机架和S级运动控制器。•接线盒套件（1326AB MOD RJxx）可用于轴向安装连接器。
Continuous rated output torque
• 100% continuous rated output torque at stall (zero rpm). • Precision balance with a total peak to peak displacement of 0.0005 "(0.0127 mm). • Vertical shaft mounted up and down. • TENV construction. • IP65 rating (when used with shaft seal option) It can withstand harsh environment. The motor is dustproof and can withstand pulsating water jet without liquid entering the motor. Important: When using externally mounted encoder/resolver feedback or blower components, the 1326AB motor loses its IP 65 rating. • The normally closed thermal switch in the motor winding (rated 115V AC at 1A and 24V DC at 1A) provides thermal overload indication. • Environmentally sealed power and feedback cable assemblies. Power supply and resolver fe feedback cable can be ordered as standard (flexible), rail (flexible) or extended length (ES). • MIL connectors are standard connectors. • Ferrite magnets for cost-effective performance. • UL approved insulation system (document number E57948). The available servo motor options for 1326AB include (option code name or catalog number in brackets): • Integral spring set fixed brake with 90V DC coils (- A4, - A5, - A7) or 24V DC coils (- K4, - K5, - K7).
Brake power supply
(1326-MOD-BPS) The voltage required to convert 115V AC to 90V DC brakes (- A4, - A5 and - A7). • Shaft seal kit (1326AB MOD SSV xx) for field installation of fluoroelastomer shaft seals. There is no need to disassemble the motor. • NEMA inch (- 11) or IEC metric flange mount (- 21) with metric shaft. Product data 1326AB AC servo motor 3 Figure 1 AC servo motor configuration and options Resolver/encoder secondary feedback package Feedback installation kit Junction box kit Viton shaft oil seal blower cooling kit Integrated brake (inside the motor) 90V DC brake power supply • Resolver feedback package (1326AB MOD Vxxxx) provides 4.25 "(108 mm) Sensors that provide absolute/vernier or single brushless resolver feedback for Allen Bradley 8600GP, IMC racks, and S-class motion controllers. • The terminal box kit (1326AB MOD RJxx) can be used for axial mounting of connectors.
