调整电压
将C支路的PT出口连接到端子3。调整电压互感器的尺寸，以产生100–240 Vac。电流互感器电源电流互感器的尺寸应能产生5 A的二次电流和最大发电机电流（可接受满载时的3–7 A二次电流）。CT负载为0.1 VA。为了防止终端引线上产生致命的高压，负载共享模块包含内部负载，当装置运行时，该负载必须连接到电源电流互感器两端。电流表可安装在电流互感器的引线上。将相位“A”CT连接到端子4和5。将相位“B”CT连接至端子6和7。将“C”CT连接端子8和9。观察如图1-3所示的设备接线图所示的正确相位，和辅助触点用于选择下垂或同步操作的下垂触点与端子13和14之间的断路器辅助触点串联连接。当下垂触点和断路器辅助触头都闭合时，负载共享模块处于同步负载共享模式。
继电器通电
在此模式下，内部负载共享线路继电器通电，下垂信号被禁用，负载匹配电路连接到负载共享线路，允许同步负载共享。当下垂触点或断路器辅助触点断开时，负载共享模块处于下垂模式。如果下垂触点断开，即使断路器辅助触点闭合，负载共享模块仍保持在下垂模式。如果辅助触点断开时不需要下降，则逆时针完全转动下降电位计。使用最小额定值为0.1 a的单极单掷开关，用于“下垂打开”开关。负载共享模块手册26011 10输出至发动机转速控制使用扭曲的0.5 mm²（20 AWG）或更大的屏蔽线将端子19、20和21的输出信号连接至发动机转速控制器。仅将护罩连接到最近的机箱螺钉。请勿连接接线速度控制端的屏蔽。同步连接如果使用SPM-A同步器，请将0.5 mm²（20 AWG）或更大的双绞线从同步器连接到端子24（+）和25（–）。将护罩系在最近的机箱螺钉上。不要将护罩连接到导线的同步器端。手册26011负载共享模块11 。
Adjust voltage
Connect the PT outlet of branch C to terminal 3. Adjust the size of the voltage transformer to produce 100 – 240 Vac. Current transformer power The current transformer shall be sized to produce a secondary current of 5 A and a maximum generator current (3 – 7 A secondary current at full load is acceptable). CT load is 0.1 VA. In order to prevent fatal high voltages on the terminal leads, the load sharing module contains internal loads that must be connected to both ends of the power current transformer when the device is operating. Ammeter can be installed on the lead of current transformer. Connect the phase "A" CT to terminals 4 and 5. Connect the phase "B" CT to terminals 6 and 7. Connect the "C" CT to terminals 8 and 9. Observe the correct phase as shown in the equipment wiring diagram shown in Figure 1-3, and the auxiliary contact is used to select the sagging or synchronous operation of the sagging contact and the circuit breaker auxiliary contact between terminals 13 and 14 in series connection. When both the droop contact and the auxiliary contact of the circuit breaker are closed, the load sharing module is in synchronous load sharing mode.
Relay energized
In this mode, the internal load sharing line relay is energized, the droop signal is disabled, and the load matching circuit is connected to the load sharing line, allowing synchronous load sharing. The load sharing module is in droop mode when the droop contact or the circuit breaker auxiliary contact is open. If the droop contact is open, the load sharing module remains in droop mode even if the auxiliary contact of the circuit breaker is closed. If lowering is not required when the auxiliary contacts are open, turn the lowering potentiometer fully counterclockwise. Use a single pole, single throw switch with a minimum rating of 0.1 a for the "droop open" switch. Load sharing module manual 26011 10 Output to engine speed control using twisted 0.5 mm ² (20 AWG) or larger shielded wire connects the output signal of terminals 19, 20 and 21 to the engine speed controller. Connect the shield to the nearest chassis screw only. Do not connect the shield at the wiring speed control end. Synchronous connection If SPM-A synchronizer is used, please connect 0.5 mm ² (20 AWG) or larger twisted pairs are connected from the synchronizer to terminals 24 (+) and 25 (–). Attach the shield to the nearest chassis screw. Do not connect the shield to the synchronizer end of the wire. Manual 26011 Load Sharing Module 11.
