YPK110E燃机模块
试运行前检查以下几点：
注意：仅在压力开关处于完美安全状态时使用。试运行前检查以下几点：•液体泄漏表示损坏。•由于本产品是安全相关部件，请检查隔膜是否有任何可见损坏。所需工具：扳手规格27开口扳手和螺丝刀。罗克韦尔自动化出版物836P-IN001B-EN-P-2017年12月5显示带IO连接类型密封的固态压力开关图1-平行螺纹锥形螺纹（NPT）必须使用合适的平垫圈和密封圈对密封面上具有平行螺纹的工艺连接进行正确密封。锥形螺纹（例如NPT螺纹）的密封是通过为螺纹提供额外的密封材料，例如PTFE胶带（EN 837-2）来实现的。进行电气连接•仪器必须通过工艺连接接地。•根据UL/EN/I第9.3节，压力开关的电源必须通过能量限制电路供电UL/EN/IEC 61010-1的3级或UL/EN/IEC60950-1的LPS或UL1310/UL1585（NEC或CEC）的2级。
确保电缆端
如果在该海拔高度使用压力开关，电源必须适用于2000米（6561.6英尺）以上的操作。•对于电缆出口，确保电缆端没有湿气进入。断开和处理断开：仅在系统减压后断开压力变送器。处置：不正确的处置会使环境面临风险。以环境兼容的方式并按照国家特定的废物处理法规处理仪器和包装材料。注意：拆卸后的压力变送器中残留的介质可能会对人员、环境和设备造成危险。采取足够的预防措施。根据EN 837、DIN 3852-E NPT 6罗克韦尔自动化出版物836P-IN001B-EN-P-2017年12月显示固态压力开关，带IO链路编程图2-键和功能键（同时按下信息和菜单键退出编程模式并返回显示模式）功能显示模式编程模式（按下菜单键5秒进入编程模式。)短按：显示单元长按：显示设置参数短按：向上切换参数（逐步）短按：上切换参数SP1/SP2滞后功能：开关点切换输出
Check the following points before commissioning:
Note: Only use when the pressure switch is in perfect safety state. Check the following points before commissioning: • Liquid leakage indicates damage. • As this product is a safety related component, please check the diaphragm for any visible damage. Tools required: wrench size 27, open-end wrench and screwdriver. Rockwell Automation Publication 836P-IN001B-EN-P-2017, December 5, shows that the solid state pressure switch with IO connection type seal Figure 1 - Parallel thread tapered thread (NPT) must properly seal the process connection with parallel thread on the sealing surface with suitable flat washer and sealing ring. Sealing of tapered threads (such as NPT threads) is achieved by providing additional sealing materials for threads, such as PTFE tape (EN 837-2). Make electrical connections • The instrument must be grounded through a process connection. • According to UL/EN/I Section 9.3, the power supply of the pressure switch must supply power to UL/EN/IEC 61010-1 Class 3 or UL/EN/IEC60950-1 LPS or UL1310/UL1585 (NEC or CEC) Class 2 through the energy limiting circuit.
Ensure cable ends
If the pressure switch is used at this altitude, the power supply must be suitable for operation above 2000 meters (6561.6 feet). • For cable outlets, ensure that no moisture enters the cable ends. Disconnection and process disconnection: Disconnect the pressure transmitter only after the system is depressurized. Disposal: Improper disposal will put the environment at risk. Dispose of instruments and packaging materials in an environmentally compatible manner and in accordance with national specific waste disposal regulations. Note: The residual medium in the disassembled pressure transmitter may cause danger to personnel, environment and equipment. Take adequate precautions. According to EN 837, DIN 3852-E NPT 6, Rockwell Automation Publication 836P-IN001B-EN-P-2017, the solid state pressure switch is displayed in December 2017, with the IO link programming diagram 2-key and function key (press the information and menu keys at the same time to exit the programming mode and return to the display mode) function display mode programming mode (press the menu key for 5 seconds to enter the programming mode.) Short press: long press of display unit: display setting parameters Short press: switch parameters up (step by step) Short press: switch parameters up SP1/SP2 hysteresis function: switch point switch output
