本手册中的程序
只有在您有资格且熟悉固态控制设备和出版物NFPA 70E中的安全程序的情况下，才应尝试本手册中的程序。注意：维修任何装置时，请勿将任何螺母、螺栓、垫圈等掉落在装置内，因为它们可能会在通电时造成短路。注意：此驱动系统包含ESD（静电放电）敏感部件和组件。安装、测试或修理此组件时，需要采取静态控制预防措施。如果不遵守ESD控制程序，可能导致部件损坏。如果您不熟悉静电控制程序，请参阅Allen Bradley出版物8000-4.5.2《防止静电损坏》或任何其他适用的ESD保护手册。Belleville W灰烬机（杯面朝向安装表面）夹具W灰烬器出版物2364F-5.17 1999年3月RGU™ 更换预充电电阻器3初步步骤更换任何预充电电阻器之前，请关闭电源；锁定/挂牌RGU；并等待五分钟以使所有电压放电。
预充电电阻器的屏蔽
打开电源结构的隔间门，取下所有Lexan™ 覆盖预充电电阻器的屏蔽。更换预充电电阻器1.使用仪表测试交流线路、直流母线和每个预充电电阻器两端的电压。2.从要更换的电阻器上拆下导线。3.拆下电阻器顶部和底部的安装螺母（或螺钉），然后从总成上拆下电阻器。注：某些电阻器的一端可能拧入展开装置的框架中。对于这些电阻器，从前端拆下螺母，然后从框架上拧下电阻器。4.将新电阻器固定到组件中，并将安装螺母拧紧至14 lb in/1.5 N-m（将螺钉拧紧至10 lb in/1.0 N-m）。5.将导线连接到新电阻器上，并拧紧至75 lb in（8.5 N-m）。对要更换的每个电阻器重复步骤2至5。如有必要，可在出版物2364F-5.01中找到预充电电路接线示意图。
Procedures in this manual
The procedures in this manual should only be attempted if you are qualified and familiar with the safety procedures in solid state control equipment and publication NFPA 70E. Note: When repairing any device, do not drop any nut, bolt, washer, etc. into the device, because they may cause short circuit when energized. Note: This drive system contains ESD (electrostatic discharge) sensitive components and components. Static control precautions are required when installing, testing, or repairing this component. Failure to follow ESD control procedures may result in component damage. If you are unfamiliar with static control procedures, refer to Allen Bradley publication 8000-4.5.2, "Preventing Electrostatic Damage," or any other applicable ESD protection manual. Belleville W Asher (cup facing mounting surface) Fixture W Asher Publication 2364F-5.17 March 1999 RGU ™ Replace the precharge resistor 3 Preliminary steps Turn off the power before replacing any precharge resistor; Lock out/tag out RGU; Wait five minutes to discharge all voltages.
Shielding of precharge resistor
Open the compartment door of the power structure and remove all Lexan ™ Cover the shield of the precharge resistor. Replace the precharge resistor 1. Use the meter to test the voltage on the AC line, the DC bus, and both ends of each precharge resistor. 2. Remove the wire from the resistor to be replaced. 3. Remove the mounting nuts (or screws) at the top and bottom of the resistor, and then remove the resistor from the assembly. Note: One end of some resistors may be screwed into the frame of the deployment device. For these resistors, remove the nuts from the front and unscrew the resistors from the frame. 4. Secure the new resistor to the assembly and tighten the mounting nut to 14 lb in/1.5 N-m (tighten the screw to 10 lb in/1.0 N-m). 5. Connect the wire to the new resistor and tighten to 75 lb in (8.5 N-m). Repeat steps 2 through 5 for each resistor that is to be replaced. If necessary, the precharge circuit wiring diagram can be found in publication 2364F-5.01.
