出版物预充电电阻器
更换内容本文档介绍了如何拆卸和更换再生直流母线电源单元（RGU）中的预充电电阻器。本套件包含的内容使用下表，确认您已收到套件中的相应项目：其他需要的项目在开始之前，请确保您还拥有以下工具：测量电压–拆卸、松开和拧紧螺钉–拆卸、松动、，和拧紧螺母–拧紧螺钉和螺母（10至75 lb in/1.0至8.5 N-m）文档：–您的驱动系统示意图–出版物2364F-5.01，再生直流母线电源装置（RGU）-用户手册对于本部分：您应该收到以下数量：预充电电阻器一个6欧姆电阻器（2364-SPK03B）或两个27欧姆电阻器（3664-SPK02A）**只有带27欧姆电阻器的旧J代码RGU才会使用套件2364-SPK02A。
注意事项适用：
预充电电阻器更换安全注意事项维修RGU或驱动系统时，以下一般注意事项适用：特殊说明重要：您需要重新使用从装置上拆下的零件。将零件按拆下的顺序放在干净的表面上。重要：一些垫圈，如卡箍和贝氏垫圈，只有一个正确的方向！注意：只有熟悉驱动系统、系统中使用的产品和相关机械的人员才能计划或实施系统的安装、启动和未来维护。不遵守规定可能导致人身伤害和/或设备损坏。注意：根据ANSI/NFPA 70E第二部分的要求，确认所有交流和直流电源均已断电、锁定或挂牌。注意：系统可能包含储能装置。为避免触电危险，在尝试维修、修理或拆卸驱动系统或其部件之前，请确认电容器上的所有电压已放电。
Publication precharge resistor
Replacement content This document describes how to remove and replace the precharge resistor in the Regenerative DC Bus Power Supply Unit (RGU). Contents of this kit Use the following table to confirm that you have received the corresponding items in the kit: Before starting other required items, make sure that you also have the following tools: Measure voltage – Remove, loosen and tighten screws – Remove, loosen, and tighten nuts – Tighten screws and nuts (10 to 75 lb in/1.0 to 8.5 N-m) Document: – Schematic diagram of your drive system – Publication 2364F-5.01, Regenerative DC Bus Power Supply Unit (RGU) - User's Manual For this section: You should receive the following quantities: precharge resistor One 6 ohm resistor (2364-SPK03B) or two 27 ohm resistors (3664-SPK02A) * * Only old J code RGUs with 27 ohm resistors will use kit 2364-SPK02A.
Notes apply:
Safety Precautions for Replacement of Precharge Resistor When repairing the RGU or drive system, the following general precautions apply: Special instructions Important: You need to reuse the parts removed from the device. Place the parts on a clean surface in the order they were removed. IMPORTANT: Some washers, such as clamps and Belleville washers, have only one correct orientation! Note: Only personnel familiar with the drive system, products used in the system and related machinery can plan or implement the installation, startup and future maintenance of the system. Failure to comply may result in personal injury and/or equipment damage. NOTE: Confirm that all AC and DC power supplies are de energized, locked out, or tagged out in accordance with ANSI/NFPA 70E, Part II. Note: The system may contain energy storage devices. To avoid the danger of electric shock, before attempting to repair, repair or disassemble the drive system or its components, please confirm that all voltages on the capacitor have been discharged.
