增强功能本节介绍此版本
固件中提供的增强功能。•改进了动态内存分配HEAP管理器，以消除由于网络负载过重或广播网络消息突发导致的潜在缓冲区溢出。•向EtherNet/IP UDP服务器添加了重试检测。•将最大服务数据大小从160字节增加到256字节，从而提高了数据缓冲容量。•添加了检测、忽略和正确排序丢失的I/O数据包的逻辑，当这些数据包被接收到时，这些数据包会出现故障。主题页增强功能1纠正异常2确定固件版本2固件闪烁4限制7兼容版本7自动化支持8产品满意度返回8自动化出版物20COME-RN003A-EN-P-2012年5月2 20-COMM-E EtherNet/IP适配器固件版本4.002纠正异常本节描述了此版本中纠正的异常固件。•当到驱动器的DPI连接出现问题时，EtherNet/IP UDP服务器出现异常。这导致RSLinx®在查看设备属性屏幕时显示设备的错误信息。确定固件版本本节描述了确定20-COMM-E EtherNet/IP适配器固件版本的步骤。
步骤示例屏幕
使用LCD HIM步骤示例屏幕1.在主菜单中，按或键滚动至设备选择。2.按（Enter）键进入此选择。3.按或键滚动到20-COMM-E适配器。4.按（Enter）键显示适配器主菜单。5.在适配器主菜单中，按或键滚动至诊断。6.按（Enter）键进入此选择。7.按或键滚动至设备版本。8.按（Enter）键显示产品数据屏幕。F->停止的自动0.0 Hz主菜单：参数设备选择内存存储F->停止自动端口5:20-COMM-E主菜单：诊断参数设备选择F->停止停止的自动端口5:20 COMM-E诊断：事件设备项目设备版本F->停止了自动端口5:20-COMM-上一个20-COMM-E-FW:4.001
Enhancements This section describes this version
Enhancements provided in firmware. • The dynamic memory allocation HEAP manager has been improved to eliminate potential buffer overflow caused by heavy network load or broadcast network message burst. • Added retry detection to the EtherNet/IP UDP server. • Increase the maximum service data size from 160 bytes to 256 bytes, thereby increasing the data buffer capacity. • Added logic to detect, ignore, and correctly sort lost I/O packets. When these packets are received, they will fail. Topic Page Enhancements 1 Correct Exceptions 2 Determine Firmware Version 2 Firmware Flashing 4 Limit 7 Compatible Version 7 Automation Support 8 Product Satisfaction Return 8 Automation Publication 20COME-RN003A-EN-P-2012 May 2 20-COMM-E EtherNet/IP Adapter Firmware Version 4.002 Correct Exceptions This section describes the abnormal firmware corrected in this version. • When there is a problem with the DPI connection to the drive, an exception occurs to the EtherNet/IP UDP server. This results in RSLinx ® The error message of the device is displayed when viewing the device properties screen. Determining the Firmware Version This section describes the steps to determine the firmware version of the 20-COMM-E EtherNet/IP adapter.
Step Example Screen
Use the LCD HIM step example screen 1. From the main menu, press the or keys to scroll to Device Selection. 2. Press the (Enter) key to enter this selection. 3. Press or to scroll to the 20-COMM-E adapter. 4. Press the (Enter) key to display the adapter main menu. 5. In the adapter main menu, press or to scroll to Diagnostics. 6. Press the (Enter) key to Enter this selection. 7. Press or to scroll to the device version. 8. Press the (Enter) key to display the product data screen. F ->Auto stop 0.0 Hz main menu: parameter device selects memory storage F ->Auto stop port 5: 20-COMM-E main menu: diagnostic parameter device selects F ->Auto stop port 5: 20 COMM-E diagnostic: event device item device version F ->Auto stop port 5: 20-COMM - previous 20-COMM-E-FW: 4.001
