•一个连接器必须有公插脚，与之配合的连接器必须有母触点。•带有L选项的电缆可以连接到没有该选项的电缆或电机，但最终的连接不提供L选项。•电缆线路长度不得超过90米（295英尺）。警告：所有B系列电缆连接器均采用黑色高导电钴涂层处理。不要刮这个涂层。艾伦-布拉德利艾伦-布拉德利推拉式连接器隔板连接器出版物电缆的隔板连接9安装隔板连接器组件该图显示了隔板连接器。侧视图显示了隔板连接器的紧固螺钉从其法兰伸出，并穿过导电金属柜。前视图显示了隔板接头上的销和紧固螺钉的方向所需工具安装隔板接头需要这些工具：•十字螺丝刀•钻头和钻头安装尺寸表提供了五个安装孔的孔尺寸。AB配套导电（金属）壁连接器外形二次成型，黑色pvc B ED C I 18-1 A G F J H前视图侧视图1326电缆螺钉说明安装孔直径，安装孔中心之间的距离约为mm（in.），连接器直径约为mm，连接器开口直径约为毫米 系列1326电缆的10个隔板连接通过机柜壁安装隔板连接器推荐的连接方法将使机柜壁上的连接器密封等级达到IP65。
安装隔板连接器
按照这些步骤准备机柜壁以安装隔板连接器。重要事项：您不需要将隔板电缆连接到机柜壁上，“使用推拉式和隔板连接器连接电缆的指南”中的信息。安装直径孔安装孔中心之间的距离连接器开口的直径壁面4.623 mm（0.182 in）机柜壁的最大宽度AB隔板连接器直径用于连接器直径的壁开口出版物1326-IN025B-EN-P-2007年5月B系列1326电缆的隔板连接11 1.确定机柜壁的安装隔板连接器的区域。2.标记四个安装孔和中心连接器开口（总共五个孔）的位置。3.钻四个安装孔和大中心孔。4.刮电缆的隔板法兰将接触的机柜壁内表面上的任何油漆。5.从1326 CCUx、1326-CPB1x-Ex-xxx和1326-CPC1x-Ex-xxx电缆的连接器表面拆下氟橡胶密封，为机柜壁留出间隙。6.通过墙壁连接隔板连接器，如图所示。注意：为避免电击危险，在安装或拆卸电缆之前，先断开电机控制器和电机的电源。
Male pin
• A connector must have a male pin, and the mating connector must have a female contact. • Cables with L option can be connected to cables or motors without this option, but the final connection does not provide L option. • The length of cable route shall not exceed 90 meters (295 feet). Warning: All B series cable connectors are coated with black highly conductive cobalt. Don't scratch the coating. Allen Bradley Push Pull Connector Bulkhead Connector Publication Cable Bulkhead Connection 9 Installing Bulkhead Connector Assembly This figure shows the Bulkhead connector. The side view shows the fastening screws of the bulkhead connector protruding from its flange and passing through the conductive metal cabinet. The front view shows the direction of the pins and fastening screws on the bulkhead joint Tools required to install the bulkhead joint These tools are required: • Phillips screwdriver • Drill bit and drill bit installation dimension table provides the hole dimensions of five mounting holes. The shape of the AB mating conductive (metal) wall connector is shaped for the second time. The black pvc B ED C I 18-1 A G F J H front view side view 1326 cable screws indicate the diameter of the installation holes. The distance between the centers of the installation holes is about mm (in.), and the diameter of the connector is about mm, The connector opening diameter is about mm. The 10 partitions of the 1326 series cable are connected through the cabinet wall. The recommended connection method of the bulkhead connector will make the sealing grade of the connector on the cabinet wall reach IP65.
Install the bulkhead connector
Follow these steps to prepare the cabinet walls for installation of bulkhead connectors. IMPORTANT: You do not need to connect the bulkhead cable to the cabinet wall, the information in "Guidelines for Connecting Cables Using Push Pull and Bulkhead Connectors.". Installation diameter holes The distance between the center of the installation holes and the diameter of the connector opening is 4.623 mm (0.182 in) The maximum width of the cabinet wall AB The diameter of the bulkhead connector The diameter of the wall opening for the connector diameter Publication 1326-IN025B-EN-P-May 2007 The bulkhead connection of B series 1326 cables 11 1. Determine the area of the cabinet wall where bulkhead connectors are installed. 2. Mark the positions of the four mounting holes and the central connector opening (five holes in total). 3. Drill four mounting holes and large center holes. 4. Scrape any paint on the inner surface of the cabinet wall that the diaphragm flange of the cable will contact. 5. Remove the fluororubber seal from the connector surface of 1326 CCUx, 1326-CPB1x Ex xxx and 1326-CPC1x Ex xxx cables to leave a gap for the cabinet wall. 6. Connect the bulkhead connector through the wall, as shown in the figure. Note: To avoid electric shock hazard, disconnect the power supply of motor controller and motor before installing or removing cables.
