DS200TCTGG1AEE燃机工控模块
远程冷端补偿
毫伏输入规格项目规格线性化误差±0.003%满量程冷端补偿精度±1.0°C冷端补偿类型关闭、本地、，远程冷端补偿范围-40至85°C温标ITS90开路检测（仅热电偶）0.4µA DC检测时间1秒DeltaV M系列传统I/O 2022年10月www.emerson.com/DeltaV 11热电偶传感器类型规格传感器类型25°C参考精度温度漂移标称分辨率满量程工作范围 隔离输入卡、热电偶、mV、V、4通道DeltaV M系列传统I/O的简化电路图2022年10月 12隔离输入卡，RTD、欧姆输入规格项目规格测量配置2、3、 和4线励磁电流100µA DC温标ITS90开路传感器检测时间1秒短路检测时间1秒钟Pt 100和Pt 200 Alpha 0.00385检测时间1s隔离输入卡、RTD、
欧姆输入规格
传感器类型25°C参考精度温度漂移分辨率传感器输入范围Pt100±0.5°C±0.018°C/°C 0.05°C-200至850°C Pt200±0.5°C/±0.012°C 0.05℃-200至85°C Ni120±0.2°C±0.006°C 0.02°C-70至300°C Cu10±2.0°C±0.076°C/℃0.23°C-30至140°C电阻±0.5欧姆±0.018欧姆/℃0.02欧姆1至1000欧姆用户定义*±0.4欧姆±0.009欧姆/°C ~ 0.05欧姆0至1000欧姆隔离输入卡，电压输入范围规格传感器类型传感器范围25°C参考精度温度漂移最大分辨率 模拟输出I/O卡项目规格通道数八隔离每个通道与系统进行光学隔离，并在工厂进行1500V DC测试。标称信号范围（量程）4至20 mA全信号范围1至23 mA本地总线电流（12V DC标称）每卡100 mA典型值，150 mA最大现场电路功率每卡300 mA最大值@24V DC（+/-10%）精度超过量程的0.25%分辨率12位输出符合性20 mA在21.6V DC电源下输入700欧姆负载校准信息存储在卡上。
Remote cold junction compensation
Millivolt input specification Item specification linearization error ± 0.003% Full scale cold junction compensation accuracy ± 1.0 ° C Cold junction compensation type Closed, local, remote cold junction compensation range - 40 to 85 ° C Temperature scale ITS90 open circuit detection (thermocouple only) 0.4 µ A DC detection time 1 second DeltaV M series traditional I/O October 2022 www.emerson Com/DeltaV 11 Thermocouple Sensor Type Specification Sensor Type 25 ° C Reference Accuracy Temperature Drift Nominal Resolution Full Scale Operating Range Isolated Input Card, Thermocouple, mV, V, 4-Channel DeltaV M Series Traditional I/O Simplified Circuit Diagram Isolated Input Card, RTD, Ohm Input Specifications Project Specifications Measurement Configuration 2, 3 And 4-wire excitation current 100 µ A DC temperature scale ITS90 open circuit sensor detection time 1s Short circuit detection time 1s Pt 100 and Pt 200 Alpha 0.00385 detection time 1s Isolated input card, RTD
Ohm input specification
Sensor type 25 ° C Reference accuracy Temperature drift resolution Sensor input range Pt100 ± 0.5 ° C ± 0.018 ° C/° C 0.05 ° C-200 to 850 ° C Pt200 ± 0.5 ° C/± 0.012 ° C 0.05 ℃ - 200 to 85 ° C Ni120 ± 0.2 ° C ± 0.006 ° C 0.02 ° C-70 to 300 ° C Cu10 ± 2.0 ° C ± 0.076 ° C/℃ 0.23 ° C-30 to 140 ° C Resistance ± 0.5 ohm ± 0.018 ohm/℃ 0.02 ohm 1 to 1000 ohm User defined * ± 0.4 ohm ± 0.009 ohm/° C~0.05 ohm 0 to 1000 ohm Isolated input card, Voltage input range specification Sensor type Sensor range 25 ° C Reference accuracy Temperature drift Maximum resolution Analog output I/O card Project specification Number of channels Eight isolation Each channel is optically isolated from the system, and 1500V DC test is carried out in the factory. Nominal signal range (measuring range) 4 to 20 mA Full signal range 1 to 23 mA Local bus current (12V DC nominal) 100 mA typical value per card, 150 mA maximum field circuit power 300 mA maximum value per card @ 24V DC (+/- 10%) Accuracy exceeds 0.25% of measuring range Resolution 12 bit output compliance 20 mA Input 700 ohm load calibration information under 21.6V DC power supply and store it on the card.
