通用输入输出
CC-PUIO01功能通用输入输出模块与模拟输入、模拟输出接口，数字输入和数字输出现场设备。值得注意的功能•每个通道用户可配置为：•模拟输入•模拟输出•数字输入•数字输出•脉冲输入（通道15-18）•开路检测•快速扫描（优先输入/输出模块扫描）•电子短路保护1•安全状态（FAILOPT）行为可按通道配置，用于数字/模拟输出•HART 7支持（模拟IO）•扩展温度范围-40至+70°C模块环境参数规范通用过程IO模块CC-PUIO01 IOTA型号CC-TUIO01非冗余12“CC-TUIO 11冗余18”注1：每个信号可在现场短路，不会损坏IOM或IOTA。
AO和DI通道
同一IOM上的其他频道将不受影响。AI、AO和DI通道经过进一步保护和认证，可支持能量受限/非易燃现场接线连接至2区/2区危险位置。Experion Series-C输入/输出规范，EP03-490-520 40版本1.5霍尼韦尔专有2021 12月详细规范-带HART参数规范的模拟输入输入输入输入类型电流（2、3或4线设备）输入通道每个模块最大32个（带或不带开路检测）A/D转换器分辨率16位输入范围0-20 mA或4-20 mA正常模式抑制比，在60 Hz 12 dB正常模式滤波器响应单极、-3 dB@16 Hz串扰时，dc至60 Hz（通道至通道）60 dB输入阻抗250Ω标称最大输入电压（任何参考公共输入，无损坏）+36 VDC至-1.1 VDC（1）输入扫描速率50 ms硬件精度满标度0.1%（23.5±2°C）满标度0.17%（-40至+70°C）变送器现场功率调节电流限制为24 mA输入滤波器一阶低通16 Hz注1：返回端子为直接连接到公共（接地）详细规范-脉冲输入参数规范通道15、16、17、18频率0-10KHz最小脉冲宽度50µs占空比满足上述最小脉冲宽度规范的任何占空比。
Universal I/O
CC-PUIO01 function general input and output module and analog input, analog output interface, digital input and digital output field equipment. Notable functions • Users can configure each channel as follows: • Analog input • Analog output • Digital input • Digital output • Pulse input (channels 15-18) • Open circuit detection • Fast scan (priority input/output module scan) • Electronic short circuit protection 1 • Safe state (FAILOPT) behavior can be configured by channel, For digital/analog output • HART 7 support (analog IO) • Extended temperature range - 40 to+70 ° C Module Environmental Parameter Specification General Process IO Module CC-PUIO01 IOTA Model CC-TUIO01 Non redundant 12 "CC-TUIO 11 Redundant 18" Note 1: Each signal can be short circuited in the field without damaging the IOM or IOTA.
AO and DI channels
Other channels on the same IOM will not be affected. AI, AO and DI channels are further protected and certified to support energy limited/non incendive field wiring to Zone 2/Zone 2 hazardous locations. Experion Series-C input/output specification, EP03-490-520 40 version 1.5 Honeywell proprietary December 2021 detailed specification - analog input input input type current (2, 3 or 4-wire device) input channel with HART parameter specification Maximum 32 per module (with or without open circuit detection) A/D converter resolution 16 bit input range 0-20 mA or 4-20 mA normal mode rejection ratio, 12 dB normal mode filter response unipolar, - 3 dB@16 Hz crosstalk, Dc to 60 Hz (channel to channel) 60 dB input impedance 250 Ω nominal maximum input voltage (any reference common input, no damage)+36 VDC to - 1.1 VDC (1) input scanning rate 50 ms hardware accuracy full scale 0.1% (23.5 ± 2 ° C) full scale 0.17% (- 40 to+70 ° C) transmitter field power regulation current is limited to 24 mA input filter first-order low-pass 16 Hz Note 1: the return terminal is directly connected to the common (grounded) Detailed specification - pulse input parameter specification Channel 15, 16, 17, 18 frequency 0-10KHz Minimum pulse width 50 µ s duty cycle Any duty cycle that meets the minimum pulse width specification above.
