DS200TCQCG1BGFDCS控制模块
注1：
取决于模块和环境的实际通道配置。有关计算方法，请参阅《用户指南》。注2：如果负载电流小于20mA，为数字输出配置的通用IO通道可能会错误报告线路监测或“OP故障”故障。注3：短路将在2微秒内限制为小于1.4安培，在10微秒内将限制为750 mA。如果短时间持续超过10毫秒，DO通道将关闭注4：请参考《用户指南》中的计算方法，以确定通道使用与工作温度的关系。5.20.通用输入输出–CC-PUIO31功能通用输入输出模块与模拟输入、模拟输出、数字输入和数字输出现场设备接口。
可配置为
值得注意的功能•每个通道用户可配置为：•模拟输入•模拟输出•数字输入•DISOE-事件序列（1ms分辨率SOE，20ms PV扫描）•数字输出•脉冲输入（任何四个通道）•开路检测•电子短路保护1•快速扫描（优先I/O模块扫描）•安全状态（FAILOPT）行为数字/模拟输出的信道基础•HART 7支持（模拟输入/输出）•每个信道的HART调制解调器实现快速性能•扩展温度范围-40至+70°C模块环境模型规范参数规范通用过程IO模块CC-PUIO31 IOTA型号CC-TUIO31非冗余9“CC-TUIO 41冗余12”注1：每个信号可以在现场短路IOM或IOTA损坏。
Note 1:
Depends on the actual channel configuration of the module and environment. For calculation methods, refer to the User Guide. Note 2: If the load current is less than 20mA, the general IO channel configured for digital output may incorrectly report line monitoring or "OP fault" fault. Note 3: Short circuit will be limited to less than 1.4 amperes in 2 microseconds and 750 mA in 10 microseconds. If the short time lasts for more than 10 milliseconds, the DO channel will be closed Note 4: Please refer to the calculation method in the User's Guide to determine the relationship between channel use and operating temperature. 5.20. Universal I/O – CC-PUIO31 function universal I/O module interfaces with analog input, analog output, digital input and digital output field devices.
Configurable as
Notable functions • Users can configure each channel as follows: • Analog input • Analog output • Digital input • DISOE event sequence (1ms resolution SOE, 20ms PV scan) • Digital output • Pulse input (any four channels) • Open circuit detection • Electronic short circuit protection 1 • Fast scan (priority I/O module scan) • Safety status (FAILOPT) behavior Digital/analog output channel basis • HART 7 support (analog input/output) • HART modem for each channel achieves fast performance • Extended temperature range - 40 to+70 ° C Module environment model specification parameter specification General process IO module CC-PUIO31 IOTA model CC-TUIO31 non redundant 9 "CC-TUIO 41 redundant 12" Note 1: Each signal can be short circuited in the field IOM or IOTA damaged.
